FIAC Parts for Compressor Stratos 24 1129990382-2011
FIAC genuine spare parts or replacement parts for to repair Air Compressor 225 - STRATOS_24_230-50_2011-06-06_StandAlone 1129990382-2011.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Parts for Compressor Stratos 24 1129990382-2011
FIAC genuine spare parts or replacement parts for to repair Air Compressor 225 - STRATOS_24_230-50_2011-06-06_StandAlone 1129990382-2011.
In the following table , look for the type of the Air Compressor and the respective parts of the code .
| 225 - STRATOS_24_230-50_2011-06-06_StandAlone | ||
| # | Part Num. | Description |
| 1 | 7011340000 | Screw |
| 2 | 7031030000 | Washer |
| 3 | 9993820050 | Head |
| 4 | 9993820060 | Joint |
| 5 | 9993820070 | Cylinder/head gasket Guarnizione cilindro testa |
| 6 | 9993820080 | Valve plate |
| 7 | 9993820090 | Flap Valve |
| 8 | 9993820100 | Gasket |
| 9 | 9993820110 | Piston |
| 10 | 9993820120 | Cylinder/valve p. ga Guarnizione cilindro pastra v. |
| 11 | 9993820130 | Cylinder |
| 12 | 7010090000 | Screw |
| 13 | 7031010000 | Washer |
| 14 | 9993820140 | Cylinder/crankcase Gasket |
| 15 | 9993820150 | Piston ring |
| 16 | 9993820160 | Oil Scraper Ring |
| 17 | 9993820170 | Piston pin |
| 18 | 7041010000 | Internal snapring |
| 19 | 9993820180 | Connecting rod |
| 20 | 9993820190 | Counter weight |
| 21 | 7010050000 | Screw |
| 22 | 9993820200 | Oil sprinkle guard |
| 23 | 7011040000 | Screw |
| 24 | 7180100000 | Oil level gauge |
| 25 | 7180100000 | Oil level gauge |
| 26 | 9993820210 | Carter cover |
| 27 | 9993820220 | Gasket |
| 28 | 7071290000 | Oil seal |
| 29 | 9993820230 | Crankcase |
| 30 | 9993820240 | Capacitor |
| 31 | 7020070000 | Nut |
| 32 | 7031010000 | Washer |
| 33 | 9993820250 | Screw |
| 34 | 7030220000 | Washer |
| 35 | 7030520000 | Washer |
| 36 | 7060200000 | Bearing |
| 37 | 9993820260 | Rotor |
| 38 | 7060710000 | Bearing |
| 39 | 9993820270 | Stator |
| 40 | 9993820280 | Gasket |
| 41 | 9993820290 | Covering |
| 42 | 9993820300 | Tension rod |
| 43 | 7030330000 | Washer |
| 44 | 9993820310 | Fan |
| 45 | 9993820320 | Internal snapring |
| 46 | 9993820330 | Plastic schroud |
| 47 | 7012080000 | Screw |
| 48 | 7030700000 | Screw |
| 49 | 7130010000 | Discharge tap |
| 50 | 7110280000 | Pressure gauge |
| 51 | 7110300000 | Pressure gauge |
| 52 | 9995270045 | Pressure reducer |
| 53 | 7081090000 | Joint |
| 54 | 9700000388 | Pressure switch |
| 55 | 9993820340 | Joint |
| 56 | 9993820350 | Nut |
| 57 | 7030680000 | Washer |
| 58 | 7192020000 | Safety valve |
| 59 | 9993820360 | Nut |
| 60 | 7230010000 | Rilsan hose |
| 61 | 7326450000 | Infeed cable |
| 64 | 9993820370 | Tank |
| 65 | 7280070000 | Handle |
| 66 | 9993820380 | Non return valve |
| 67 | 7130160000 | Discharge tap |
| 68 | 7020050000 | Nut |
| 69 | 7030010000 | Washer |
| 70 | 7270010000 | Rubber Sucking Foot |
| 71 | 7014510000 | Screw |
| 72 | 7020080000 | Nut |
| 73 | 7030360000 | Washer |
| 74 | 7018290000 | Wheel pin |
| 75 | 7260160000 | Wheel |
| 76 | 9993820390 | Infeed hose |
| 77 | 7030470000 | Washer |
| 78 | 9993820400 | Nut |
| 79 | 7210090000 | Intake filter |
| 80 | 7030180000 | Washer |
| 81 | 7012070000 | Screw |
