We are FIAC original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Air Compressor AIR CLICK.
In the following table , look for the type of the air compressor and the respective parts of the code .
| Compressor Air Click | ||
| # | Part Num. | Description |
| 1 | 7012060000 | Screw M4X12 UNI-8112 |
| 2 | 7151430000 | plastic top Motor Cover |
| 3 | 7570620000 | Head |
| 4 | 7012790000 | Screw M6X35 UNI-8112 |
| 5 | 7078670000 | Gasket |
| 6 | 7199160000 | Flap Valve |
| 7 | 7459360000 | Valve plate |
| 8 | 7070420000 | O-Ring 476 |
| 9 | 5062040008 | Cylinder |
| 10 | 7670070000 | Sump |
| 11 | 7018500000 | PIVOT ROD 203 F. |
| 12 | 4082900000 | ROD KIT F-203 X AIRCLIK |
| 13 | 7060420000 | 6201 2RS1 bearing 12X32X10 - SKF |
| 14 | 7020240000 | Nut M8 DIN-6923 |
| 15 | 7585050000 | Crank BRASS F-203 AIRCLIK |
| 16 | 7012490000 | Screw M6X40 UNI-7686 |
| 17 | 7020200000 | Nut M6 UNI-5587 |
| 18 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 19 | 7584020000 | GROUP TREE + ROTOR F-203 H 50- |
| 20 | 4013490000 | Stator |
| 21 | 7310320000 | Capacitor MF.30 V450 |
| 22 | 7640130000 | Cover |
| 23 | 7012240000 | Screw M5X15 UNI-8112 |
| 24 | 7013060000 | Screw M4X8 UNI-8112 |
| 25 | 7459590000 | SUPPORT PLASTIC H50-CAREN.AIRCLIK |
| 26 | 7199170000 | Flap Valve |
| 27 | 7012090000 | Screw M5X12 UNI-8112 |
| 28 | 7201280000 | Fan raff. |
| 29 | 7012880000 | Screw M6x90 UNI-5739 |
| 30 | 7459400000 | Support |
| 50 | 5152830008 | Tank 24lt |
| 51 | 7091240000 | Plastic stopper |
| 52 | 7360020000 | Rubber Ø16 |
| 53 | 7130160000 | Bleeding tap M3 / 8 " |
| 54 | 7260380000 | Wheel Ø125X35 F10 |
| 55 | 7012780000 | Screw M10x60 UNI-5737 |
| 56 | 7327540000 | Power cable |
| 57 | 7020080000 | Nut M10 UNI-5588 |
| 58 | 7090030000 | cap 1/2 |
| 59 | 7190240000 | Check valve M3 / 8 "-Pipe Ø8 |
| 60 | 7230010000 | Rilsan tube Ø6X4 |
| 61 | 7230670000 | Tube feeding |
| 62 | 7192020000 | Valve Sic. M1 / 4-8,5Bar |
| 63 | 7250740000 | Pressure Switch |
| 64 | 7023040000 | Nut 1/4 " |
| 65 | 7081140000 | Fitting 1/4 "MM |
| 66 | 7110300000 | Manometer Ø50-1 / 4 " |
| 67 | 7100640000 | Pressure reducer |
| 68 | 7130010000 | Tap M1 / 4 " |
| 69 | 7081090000 | Fitting 1/4 "MM |
| 70 | 7110240000 | Manometer Ø40-1 / 8 " |
| 71 | 7210810000 | Suction filter |
| 100 | 4230150000 | GR.TESTA-PLATE F-203 / GM-203 |
| 501 | 4082830000 | SET CONROD+CYLINDER+CRANK |
