FIAC New Silver 3-90 Parts
€472.98
Tax included
FIAC New Silver 3/90 9-bar Spare Parts
Fiac Genuine spare parts or replacement parts for to Fix New Silver 3/90 9-bar / V230-50 Hz 1121680814.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC New Silver 3/90 9-bar Spare Parts
Fiac Genuine spare parts or replacement parts for to Fix New Silver 3/90 9-bar / V230-50 Hz 1121680814.
In the following table, look for the type of the Compressor and the respective parts of the code.
| FIAC New Silver 3/90 9-bar / V230-50 Hz 1121680814 Parts List Pag.1 | ||
| # | Part Num. | Description |
| 1 | 1124010139 | Stator |
| 2 | 1124280094 | Rotor kit |
| 3 | 1125140010 | Handle |
| 4 | 1125150258 | Tank |
| 5 | x | Screw |
| 6 | x | Screw |
| 7 | x | Screw |
| 8 | x | Screw |
| 9 | x | Screw |
| 10 | x | Screw |
| 11 | x | Screw |
| 12 | x | Screw |
| 13 | x | Screw |
| 14 | x | Tension rod |
| 15 | x | Nut |
| 16 | x | Nut |
| 17 | x | Nut |
| 18 | x | Nut |
| 19 | x | Nut |
| 20 | x | Washer |
| 21 | x | Washer |
| 22 | 1127200059 | Fan |
| 23 | x | Washer |
| 24 | x | Washer |
| 25 | 1127040327 | Clamp |
| 26 | 1127040334 | Clamp |
| 27 | 1127060065 | Bearing |
| 28 | 1127080016 | Joint |
| 29 | 1127080081 | Joint |
| 30 | 1127080100 | Joint |
| 31 | 1127080134 | Joint |
| 32 | 1127080219 | Joint |
| 33 | 1127080425 | Joint |
| 34 | 1127090003 | Plug |
| 35 | 1127090007 | Plug |
| 36 | 1127110018 | Pressure gauge |
| 37 | 1127130016 | Discharge tap |
| 38 | 1127130057 | Universal Tap |
| 39 | 1120011397 | Plastic schroud kit |
| 39,1 | 1127150598 | Upper cover |
| 39,2 | 1127150030 | Side plastic schroud |
| 39,3 | 1127150031 | Side plastic schroud |
| 39,4 | 1127150595 | Instruments support |
| 40 | 1127150596 | Sheet metal Kit |
| 40,1 | 1125160082 | Base |
| 40,2 | 1120004645 | Press. reducer sup. |
| 40,3 | 1125160024 | Instruments support |
| 40,4 | 1125160085 | Front cover |
| 40,5 | 1125160104 | Conveyor |
| 40,6 | 1125160139 | Pressure switch Support |
| 40,7 | 1125160143 | Support |
| 40,8 | 1125160145 | Rear cover |
| 40,9 | 1125160190 | Support |
| 41 | 1127190209 | Safety valve |
| 42 | 1127200157 | Fan |
| 43 | 6211472650 | Oil filter |
| 44 | 1127210451 | Soundprof Kit |
| 45 | 1127210292 | Intake filter kit |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 47 | 1127230001 | Rilsan hose |
| 48 | 1127230003 | Rilsan hose |
| 49 | 1127230882 | Rubber hose |
| 50 | 1127230883 | Rubber hose |
| 51 | 1127230884 | Rubber hose |
| 52 | 1127250002 | Pressure switch |
| 53 | 1127080210 | Joint |
| 54 | x | Wheel |
| 55 | 1127300046 | Main switch |
| 56 | 1127310053 | Capacitor |
| 57 | 1127320626 | Infeed cable |
| 58 | x | Wheel pin |
| 59 | 1127380234 | Terminal cover |
| 60 | 1127380670 | Fun Cover |
| 61 | 1127410566 | Elettric board |
| 61,1 | 1120004647 | Electric box |
| 62 | 1127420343 | Screw pump unit |
| 63 | 1125160081 | Motor Flange |
| 64 | 1127480850 | Thermostat Capsule |
| 65 | 1127500105 | Cable clamp |
| 66 | 1127500106 | Cable clamp |
| 67 | 1127510674 | Radiator |
| 68 | 1127560002 | Hour meter |
| 69 | 1127560446 | Oil Thermostat |
| 70 | 1127640016 | Covering |
| 71 | 1129701523 | Distributor |
| 72 | 1127560103 | Heather |
| 73 | 1127090008 | Plug |
| 74 | x | Rubber Foot |
| 101 | 1124080315 | Wheel kit |
| 102 | 1124080376 | Rubber Foot Kit |
| Maintenance programs Pag.2 | ||
| # | Part Num. | Description |
| A | Maintenance program 500 Hours (3 months - 3 months) | |
| 43 | 6211472650 | Oil filter |
| 200 | 1127120034 | Maintenance oil |
| B | . | Maintenance program 2500 Hours (1 Year - 1 year) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| C | . | Maintenance program 5000 Hours (2 Years - 2 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| 206 | 1124090527 | Oil recovery hose kit |
| 205 | 1124090205 | Intake valve kit |
| D | . | Maintenance program 7500 Hours (3 Years - 3 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 27 | 1127060065 | Bearing |
| 200 | 1127120034 | Maintenance oil |
| 203 | 1124090524 | Minimun valve kit |
| 209 | 1127420073 | Thermostatic valve kit |
| 41 | 1127190209 | Safety valve |
| 208 | 1127190292 | Safety valve |
| E | . | Maintenance program 10000 Hours (4 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| 206 | 1124090527 | Oil recovery hose kit |
| 205 | 1124090205 | Intake valve kit |
| 49 | 1127230882 | Rubber hose |
| 50 | 1127230883 | Rubber hose |
| 51 | 1127230884 | Rubber hose |
| 201 | 1124090522 | Gasket kit |
| F | . | Maintenance program 12500 Hours (5 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| G | . | Maintenance program 15000 Hours (6 Years - 6 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| 206 | 1124090527 | Oil recovery hose kit |
| 205 | 1124090205 | Intake valve kit |
| 203 | 1124090524 | Minimun valve kit |
| 209 | 1127420073 | Thermostatic valve kit |
| 27 | 1127060065 | Bearing |
| 41 | 1127190209 | Safety valve |
| 208 | 1127190292 | Safety valve |
| H | . | Maintenance program 17500 Hours (7 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| I | . | Maintenance program 20000 Hours (8 years) |
| 43 | 6211472650 | Oil filter |
| 45,1 | 1127210607 | Intake filter |
| 46 | 1127210608 | Oil separator filter |
| 200 | 1127120034 | Maintenance oil |
| 49 | 1127230882 | Rubber hose |
| 50 | 1127230883 | Rubber hose |
| 51 | 1127230884 | Rubber hose |
| 201 | 1124090522 | Gasket kit |
| 202 | 1124090201 | Bearing kit |
| 203 | 1124090524 | Minimun valve kit |
| 204 | 1124090203 | Oil seal Kit |
| 205 | 1124090205 | Intake valve kit |
| 206 | 1124090527 | Oil recovery hose kit |
| 207 | 1120002646 | Flange kit |
| 208 | 1127190292 | Safety valve |
| 209 | 1127420073 | Thermostatic valve kit |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
