Femi Spare Parts for Band Saw for Metal 785XL/8486026
€6.82
Tax included
Femi Spare Parts for Band Saw for Metal 785XL/8486026
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Electric Band Saw for Metal 785XL - 8486026.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw for Metal 785XL/8486026
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Electric Band Saw for Metal 785XL - 8486026.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saw 785XL/8466026 | ||
| # | Part Num. | Description |
| 3 | 0063040 | BUSHING |
| 79 | 0080259 | SPRING WASHER |
| 71 | 0102005 | FLANGE NUT |
| 13 | 0120718 | PLAIN WASHER |
| 102 | 0120718 | PLAIN WASHER |
| 106 | 0129004 | INOX STEEL WASHER |
| 21 | 0144003 | HANDGRIP |
| 5 | 0147003 | HAND LEVER |
| 103 | 0147006 | HAND LEVER |
| 56 | 0150149 | FEATHER |
| 49 | 0150701 | CYLINDRIC PIN WITH SLOT |
| 67 | 0155116 | THICKNESS WASHER |
| 119 | 0155140 | THICKNESS WASHER |
| 65 | 0155149 | THICKNESS WASHER |
| 136 | 0168507 | PLASTIC CAP |
| 105 | 0174016 | NEEDLE |
| 95 | 0179901 | NEEDLE |
| 20 | 0402905 | RIVET |
| 121 | 0424060 | SCREW |
| 77 | 0590624 | BALL BEARING |
| 110 | 0600607 | BALL BEARING |
| 51 | 0606005 | BALL BEARING |
| 66 | 0606204 | BALL BEARING |
| 154 | 0730609 | CAGE BEARING |
| 152 | 0731012 | CAGE BEARING |
| 124 | 0802314 | SWITCH |
| 90 | 0802317 | SWITCH |
| 133 | 0802606 | SWITCH |
| 138 | 0816003 | THERMOSTAT |
| 145 | 0816004 | RADIO INTERFERENCE SUPPRESSOR |
| 63 | 5001558 | SHAFT |
| 150 | 5024111 | STATOR |
| 54 | 5042793 | BANDSAW BODY |
| 92 | 5050117 | HANDLE |
| 2 | 5080132 | SPRING |
| 83 | 5081005 | SPRING |
| 116 | 5100064 | SCREW |
| 117 | 5100065 | SCREW |
| 82 | 5100504 | BLADE TENSIONING SCREW |
| 125 | 5112021 | MOTOR FAN |
| 76 | 5120638 | SPACER |
| 80 | 5122024 | SPACER |
| 18 | 5124029 | ECCENTRIC |
| 73 | 5124047 | WASHER |
| 4 | 5124050 | WASHER |
| 85 | 5130734 | WHEEL GUIDE |
| 118 | 5130771 | GUIDE |
| 29 | 5137778 | BRACKET |
| 30 | 5137793 | REST FOOT |
| 64 | 5137808 | SLIDING DEVICE |
| 19 | 5138042 | GRADUATE PLATE |
| 7 | 5138043 | SWIVEL SUPPORT |
| 42 | 5140002 | HANDLE |
| 75 | 5140026 | HANDWHEEL |
| 93 | 5142079 | LEVER |
| 28 | 5142105 | LEVER |
| 57 | 5154103 | CABLE LOCKING DEVICE |
| 129 | 5154501 | CABLE LOCKING DEVICE |
| 11 | 5159503 | CUTTING ANGLE INDEX |
| 94 | 5159504 | BLADE TENSION INDEX |
| 36 | 5171087 | JOINT PIN |
| 69 | 5181736 | PROTECTION |
| 88 | 5181737 | CABLE PROTECTION |
| 148 | 5182509 | GEAR COVER |
| 135 | 5182517 | SWITCH COVER |
| 122 | 5182519 | MOTOR COVER |
| 146 | 5182823 | SWITCH BOX |
| 47 | 5182828 | VICE SCREW COVER |
| 151 | 5182839 | MOTOR COVER |
| 53 | 5183066 | BLADE TENSION INDEX COVER |
| 59 | 5214022 | DRIVING WHEEL |
| 132 | 5850005 | BRUSHES SUPPORT |
| 137 | 5850109 | BRUSHES |
| 126 | 5871047 | CABLE |
| 89 | 5871048 | CABLE |
| 149 | 7013130 | ROTOR |
| 15 | 7130552 | ROD STOP GROUP |
| 6 | 7130678 | COMPLETE VICE |
| 153 | 7213018 | GEAR GROUP |
| 50 | 7213019 | GEAR GROUP |
| 120 | 7213021 | GEAR GROUP |
| 127 | 7801614 | MOTOR ASSEMBLY |
| 500 | 3280046 | BAND 1735x19x0,9 mm PITCH 6/10 |
