Femi Spare Parts for Band Saw ABS 105
€19.11
Tax included
Femi Spare Parts for Band Saw ABS 105
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Electric Band Saw for metals ABS 105 - 8484681.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw ABS 105
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Electric Band Saw for metals ABS 105 - 8484681.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saw ABS 105 - 8484681 | ||
| # | Part Num. | Description |
| 2 | 5182837 | CAP MOTOR 782 |
| 3 | 5112021 | FAN MOTOR D.65 |
| 7 | 5182005 | FLAP FAN |
| 8 | 0801211 | END-RUN MICROSWITCH QK7S - 0801216 |
| 9 | 5850005 | BRUSH HOLDER 901519 MOTOR H38 |
| 10 | 5061038 | RID.GOMMA CUSC.607 (H38-50 side collett) |
| 11 | 0816005 | REACTOR NOISE COD. 921642 |
| 12 | 5850109 | BRUSH WITH INSERT MOT.H38 |
| 13 | 7013130 | ARMATURE ROTOR AVV.A COLL.MOT.D93xH38 230V "201441" |
| 14 | 0130502 | Thermostat holder X D.93 -800249- 800249 |
| 15 | 7801612 | MOTOR ASS'Y 93 H38 230 Hz50 FEMI 100863 |
| 16 | 5024111 | FIELD ASS'Y D.93xH38 MF V230 50/60 HZ |
| 17 | 0816003 | THERMOSTAT BIM. 100oC CABL.C / CAV. 10A |
| 18 | 5061039 | RID.GOMMA SILIC.CUSC.608 H38 side flangi |
| 20 | 5182522 | COVER GEAR BOX WITH BUSH |
| 21 | 0155013 | CIRCLIP OND.LMKAS 22 SPESS.0,3 |
| 22 | 0570627 | BEARING 627 7x22x 7 OPEN |
| 23 | 7213003 | PRIMARY GEAR ASSEMBLY |
| 24 | 0606202 | 15x35x11 BEARING 6202 2RS |
| 25 | 0155136 | WASHER D.11x8,2xO, 5 (ACC.C.70 TEMP.) |
| 26 | 0730810 | CASE NEEDLE HK0810 (8X12X10) |
| 27 | 5100090 | SCREW LOCKING ROTATING ARM |
| 28 | 0129004 | WASHER INOX D.4,3X8X0,5 DIN 433 A2 |
| 29 | 0590624 | BEARING 624 ZZ 4x13x 5 |
| 30 | 0174022 | ROLLER D.4X19,8 |
| 31 | 5120638 | DISTANCE FOR BEARING D.6X12 H.1,5 |
| 32 | 0600607 | BEARING 607 2RS 7x19x 6 |
| 33 | 0155142 | RING RAM 22 D.21,8X14 SPESS.0,5 |
| 34A | 5214016 | Include in code 5214019 |
| 34 | 5214019 | DRIVING WHEEL W / INSERT |
| 35 | 5181623 | CARTER PROTECTION BLACK |
| 38 | 5100065 | ECCENTRIC SCREW REGISTRAZ.CUSCINETTI |
| 39 | 5100064 | LOCKING SCREW BEARING |
| 40 | 5130951 | BRACKET LOCKING PROTEZ.CUSCINETTI |
| 41 | 5181016 | FELT TERGILAMA |
| 42 | 5154103 | GLAND PLATE |
| 43 | 0120206 | WASHER GROWER O6 ZN UNI 1751 |
| 44 | 0102106 | NUT M 6 UNI 5721 ZN |
| 45 | 0102106 | RING RAM 10 D.9,8X6,2 SPESS.0,5 |
| 46 | 0730609 | CASE ROLLER HK0609B (6X10X9) |
| 47 | 7213001 | GEAR ASSEMBLY HELICOIDAL |
| 48 | 7213007 | GEAR ASSEMBLY LAW |
| 50 | 0120706 | FLAT WASHER D.6,5X18 SP.1,5 ZN |
| 51 | 5130932 | BLADE GUIDE |
| 52 | 5181848 | FRONT PROTECTION blade guide |
| 55 | 0400604 | TTQ ZN SCREW M 6X30 UNI 5732 |
| 56 | 0179901 | ROLLER D.10X10 |
| 59 | 0155152 | THICK THICK WASHER PS 15x22. 1 |
| 60 | 0596002 | BEARING 6002 ZZ 15x32x 9 |
| 61 | 5120663 | RING |
| 63 | 5124062 | SEALING WASHER |
| 66 | 5130734 | HELP SUPPORT PULLEY NEUTRAL |
| 67 | 5081005 | SPRING TENSION BELT |
| 72 | 5042873 | ARM SEG.1330 BLACK BUCCIATO RAL 9005 ABS |
| 73 | 5142070 | LEVER |
| 74 | 5870847 | CABLE PVC H05 VV-F 2X0,75X910 C / PUN. + FST. |
| 77 | 5050152 | COVER HANDLE ABS 105 RAL 3020 |
| 78 | 0802317 | INTERRUTT.BIP.A BUTTON 8A |
| 79 | 5050151 | BASE, HANDLE ABS 105 RAL 3020 |
| 84 | 0802314 | SINGLE SWITCH 250 VOLT 10A 1-2 |
| 87 | 5870843 | CA.H05 3XO, 75X1800 C / PUNT.SP / EUR.2 / EARTH |
| 88 | 5154501 | GLAND |
| 90 | 7820130 | FILTER |
| 92 | 0120710 | FLAT WASHER D.10X30 ZN |
| 93 | 0151409 | BENZING D.6 UNI 7434-75 |
| 94 | 5138058 | SUPP.GIREVOLE 1330 BLACK RAL 9005 Bucc |
| 95 | 5171091 | THREADED STUD X ABS |
| 96 | 0411006 | WHEAT CEPP M10X10 |
| 97 | 5171043 | LOCKING PIN |
| 98 | 0222021 | SEAL OR 2021 |
| 99 | 0140076 | LOBE HANDWHEEL 3 C / BOCC.FIL.THF D.25 M8 |
| 101 | 0063042 | SLEEVE FE 5x8x16 |
| 103 | 5124029 | LOG ECCENTRIC |
| 104 | 0402905 | RIVETTO AUT.ELIC.D.2,9X5 |
| 105 | 5401319 | GRADUATED PLATE SEG.1330 |
| 106 | 7130535 | STOP BAR COMPLETE X SEGATR. 1330 |
| 107 | 0401001 | TTQ ZN SCREW M10x40 UNI 5732 |
| 108 | 5134017 | FOOT FOR BASE |
| 111 | 0080261 | SPRING CUP D.5 X 10 X 0.5 |
| 114 | 0155143 | WASHER THICKNESS PS 45x55 SPESS.0,5 |
| 115 | 5080180 | SPRING JOINT LONG STEM |
| 116 | 0063027 | BUSH AUT.FERRO SINTERED 10X14X20 |
| 117 | 0802606 | SWITCH START / STOP A PULS. V <V230-Hz50 / 60 |
| 118 | 0101408 | SELF LOCK NUT M8 UNI 7474 LOW |
| 119 | 0155150 | WASHER THICKNESS PS 8x14 SPESS.0,3 |
| 120 | 5130416 | PLATE |
| 121 | 5130428 | FLAT SLIDING VICE |
| 123 | 5152613 | JAW PLATES FIXED NG120 |
| 126 | 0150701 | PLUG 6X14 CENTRAL CIL.INTAGLIO S80 |
| 127 | 5042849 | BASE VICE RAL 9005 SMOOTH |
| 128 | 5150005 | STOPPED FOR PIN VICE |
| 130 | 5142014 | LEVER SCREW CLAMP |
| 131 | 5130426 | SLED DX |
| 132 | 5130427 | SLED SX |
| 133 | 5063034 | BUSH COVER SCREW |
| 134 | 5100320 | SCREW CLAMP |
| 136 | 5042850 | SLIDE VICE RAL 9005 SMOOTH |
| 138 | 0063041 | BUSH FE SINT.D.8x12x16x2 H6 |
| 139 | 7130670 | G.PO VICE ALU L120 x 1330 AND 1440 |
| 140 | 5150005 | STOPPED FOR PIN VICE |
| 143 | 0181018 | PASSACORDONE PVC 6235/6/5 BLACK |
| 144 | 0181019 | PASSACORDONE PVC 6203/7 BLACK |
| 146 | 0120720 | FLAT WASHER SPEC.d22xD40xsp3 mm ZN |
| 150 | 5181004 | CABLE PROTECTION RUBBER |
| 153 | 0880013 | GLAND ANTICREASE PG9 1500.09N |
| 154 | 5130491 | BRACKET PORTAFARFALLA C / PIN BRUNITA |
| 155 | 5080129 | SPRING OPENING CARTER |
| 156 | 5171090 | PIN SWITCH 1330 |
