Femi Spare Parts for 400V Band Saw N310 DA DG
€799.70
Tax included
Femi Spare Parts for 400V Band Saw N310 DA DG
We have the original FEMI parts and tool repair help you need to get your tools running like new again.Fix Your Stationary Band Saw N310 DA DG Three Phase - 8489028. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for 400V Band Saw N310 DA DG
Fix Your Stationary Band Saw N310 DA DG Three Phase - 8489028. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of Band Saw and the respective parts of the code.
| Stationary Band Saw N310 DA DG Three Phase - 8489028 | ||
| # | Part Num. | Description |
| 2 | 5133818 | TANK BASE |
| 3 | 7130736 | |
| 4 | 7113535 | ELECTRIC PUMP |
| 6 | 5042912 | |
| 8 | 5152631 | |
| 9 | 5131005 | SLIDING VICE |
| 10 | 5042913 | |
| 11 | 5131006 | |
| 15 | 5100157 | LEVER NUT |
| 16 | 5133819 | |
| 17 | 5182596 | |
| 18 | 5063072 | |
| 19 | 5100355 | |
| 20 | 5142111 | LEVER |
| 21 | 0711831 | CAGE BEARING |
| 23 | 5100356 | |
| 24 | 5214041 | DRIVING WHEEL |
| 25 | 5124094 | WASHER |
| 26 | 5131007 | |
| 27 | 5181947 | |
| 28 | 5124095 | |
| 29 | 0551204 | |
| 30 | 5100159 | |
| 31 | 5100357 | |
| 32 | 5181925 | |
| 34 | 0801213 | SAFETY SWITCH |
| 38 | 5080185 | SPRING |
| 39 | 5064031 | |
| 42 | 5173038 | TENSIONING ROD |
| 43 | 5080184 | SPRING KIT |
| 44 | 0140120 | COMPLETE TENSIONING HANDLE |
| 46 | 0140124 | KNOB |
| 47 | 5214240 | FREE WHEEL |
| 48 | 5100160 | |
| 49 | 0551203 | BALL BEARING 32006 |
| 50 | 3280056 | |
| 52 | 0100116 | HEX NUT M16 |
| §3 | 5100358 | |
| 54 | 5130987 | BLADE TENSIONONG PLATE |
| 55 | 0140121 | HANDLE |
| 56 | 5142110 | LEVER |
| 57 | 5100359 | SCREW |
| 58 | 5181905 | BRUSH PROTECTION |
| 59 | 5080186 | SPRING |
| 60 | 5142109 | LOCKING LEVER |
| 61 | 0551406 | BALL BEARING 51106 |
| 62 | 5182594 | BEARING COVER |
| 63 | 0140123 | KNOB |
| 64 | 5080187 | SPRING |
| 67 | 5133820 | |
| 68 | 5002059 | |
| 69 | 5002060 | |
| 70 | 0801214 | SAFETY SWITCH |
| 71 | 5131008 | |
| 73 | 0240311 | TAP |
| 74 | 5131009 | |
| 75 | 5100360 | |
| 76 | 5181926 | |
| 77 | 5142112 | |
| 79 | 0600608 | BALL BEARING 8X22X7 608 2RS |
| 80 | 5402802 | GRADUATE PLATE |
| 81 | 1725809 | COOLANT TUBE |
| 82 | 5181906 | BLADE CLEAN PROTECTION |
| 83 | 5152632 | |
| 84 | 5181927 | REAR BLADE PROTECTION WITH BRUSH |
| 85 | 0135003 | |
| 87 | 5402803 | SUPPORT PLATE |
| 88 | 5100361 | |
| 90 | 5002061 | SHAFT |
| 91 | 5131010 | |
| 92 | 5131011 | |
| 93 | 5063071 | BUSHING |
| 94 | 0802328 | SWITCH |
| 96 | 0241466 | PIPE FITTING |
| 99 | 5181928 | |
| 100 | 5181929 | |
| 101 | 5133802 | TANK EXTENSION |
| 102 | 5155162 | BLADE GUIDE PAD |
| 103 | 5155163 | BLADE GUIDE PAD |
| 105 | 0241002 | PRESSURE INDICATOR |
| 106 | 5100362 | BEARING SCREW (S) |
| 107 | 5100363 | BEARING SCREW (I) |
| 109 | 0155159 | STOP RING |
| 110 | 7241008 | DOWN FEED HYDRAULIC GROUP |
| 111 | 5241112 | |
| 112 | 5152633 | |
| 113 | 5042914 | VICE BASE |
| 114 | 5133821 | PANEL SUPPORT |
| 115 | 7800280 | COMPLETE CONTROL PANEL 400V |
| 116 | 0820020 | |
| 117 | 5142113 | |
| 118 | 5100364 | |
| 119 | 5063073 | |
| 120 | 0820021 | |
| 121 | 0806035 | EMERGENCY STOP BUTTON |
| 123 | 5134018 | |
| 124 | 5100365 | |
| 125 | 5134019 | |
| 127 | 5152634 | |
| 128 | 5155164 | |
| 129 | 5133822 | |
| 163 | 5100366 | |
| G18 | 7211009 | |
| M1 | 7801862 | MOTOR ASSY 400V |
| M2 | 5112036 | MOTOR FAN |
| M3 | 5182941 | MOTOR FAN COVER |
| TO1 | 5133823 | SIDE PANEL |
| TO2 | 5181930 | COLUMN |
| 130 | 0820022 | |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
