Femi Spare Parts for Band Saw 785P - 8486024
€18.11
Tax included
Femi Spare Parts for Band Saw 785P - 8486024
We supply original FEMI spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Band Saw 785P - 8486024.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw 785P - 8486024
We supply original FEMI spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Electric Band Saw 785P - 8486024.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saw 785P/8486024 | ||
| # | Part Num. | Description |
| 1 | 0311499 | EXAGONAL HEAD SCREW |
| 2 | 5080132 | SPRING |
| 3 | 0063040 | BUSHING |
| 4 | 5124050 | WASHER |
| 5 | 0147003 | HAND LEVER |
| 7 | 5137809 | SWIVEL SUPPORT |
| 9 | 0100714 | NUT |
| 10 | 0102114 | CAP NUT |
| 11 | 5159513 | BASE INDEX |
| 12 | 0063037 | BUSHING |
| 13 | 0120718 | PLAIN WASHER |
| 15 | 7130552 | ROD STOP GROUP |
| 16 | 5133685 | BAND SAW BASE |
| 18 | 5124029 | ECCENTRIC |
| 19 | 5404012 | SLIDING SUPPORT PLATE |
| 21 | 0144003 | HANDGRIP |
| 29 | 5137778 | BRACKET |
| 30 | 5137793 | REST FOOT |
| 42 | 0140059 | LEVER COVER |
| 47 | 5182828 | VICE SCREW COVER |
| 49 | 0150701 | CYLINDRIC PIN WITH SLOT |
| 50 | 7130592 | COMPLETE VICE GROUP |
| 51 | 0606005 | BALL BEARING |
| 53 | 5183066 | BLADE TENSION INDEX COVER |
| 56 | 0063037 | FEATHER |
| 57 | 5154103 | CABLE LOCKING DEVICE |
| 59 | 5214022 | DRIVING WHEEL |
| 61 | 0101412 | SELF-LOCKING NUT |
| 63 | 5001558 | SHAFT |
| 64 | 5137808 | SLIDING DEVICE |
| 65 | 0155149 | THICKNESS WASHER |
| 66 | 0606204 | BALL BEARING |
| 67 | 0155116 | THICKNESS WASHER |
| 69 | 5181736 | PROTECTION |
| 71 | 0102005 | FLANGE NUT |
| 73 | 5124047 | WASHER |
| 74 | 7214210 | FREE WHEEL GROUP |
| 75 | 5140026 | HANDWHEEL |
| 77 | 0590624 | BALL BEARING |
| 78 | 5181738 | BLADE CLEANER |
| 79 | 0080259 | SPRING WASHER |
| 80 | 5122024 | SPACER |
| 82 | 5100504 | BLADE TENSIONING SCREW |
| 83 | 5081005 | SPRING |
| 85 | 5130734 | WHEEL GUIDE |
| 88 | 5181737 | CABLE PROTECTION |
| 89 | 5871048 | CABLE |
| 90 | 0802317 | SWITCH |
| 92 | 5050117 | HANDLE |
| 93 | 5142079 | LEVER |
| 94 | 5159504 | BLADE TENSION INDEX |
| 95 | 0179901 | NEEDLE |
| 96 | 5042793 | BANDSAW BODY |
| 97 | 7213019 | GEAR GROUP |
| 100 | 0102106 | CAP NUT |
| 102 | 0120718 | PLAIN WASHER |
| 103 | 0147006 | HAND LEVER |
| 105 | 0174016 | NEEDLE |
| 106 | 0129004 | INOX STEEL WASHER |
| 108 | 0400620 | SCREW |
| 109 | 5181729 | REAR BLADE GUIDE PROTECTION (5181868) |
| 110 | 0600607 | BALL BEARING |
| 115 | 5181654 | BLADE PROTECTION |
| 116 | 5100064 | SCREW |
| 117 | 5100065 | SCREW |
| 118 | 5130771 | GUIDE |
| 119 | 0400804 | SCREW |
| 120 | 7130588 | SLIDING GUIDE GROUP |
| 122 | 5182519 | MOTOR COVER |
| 123 | 0802314 | SWITCH |
| 124 | 5850111 | FAN WITH MAGNETIC RING |
| 125 | 5871047 | CABLE |
| 127 | 7801614 | MOTOR ASSEMBLY |
| 129 | 5154501 | CABLE LOCKING DEVICE |
| 132 | 5850005 | BRUSHES SUPPORT |
| 133 | 0802606 | SWITCH |
| 135 | 5182517 | SWITCH COVER |
| 136 | 0168507 | PLASTIC CAP |
| 145 | 0816004 | RADIO INTERFERENCE SUPPRESSOR |
| 146 | 5182823 | SWITCH BOX |
| 148 | 5182509 | GEAR COVER |
| 149 | 7013129 | Armature 240V Replaced by 7013134 |
| 150 | 5024111 | STATOR |
| 151 | 5182839 | MOTOR COVER |
| 152 | 0731012 | CAGE BEARING |
| 153 | 0730810 | CAGE BEARING |
| 157 | 7213018 | GEAR GROUP |
| 158 | 0730609 | CAGE BEARING |
| 159 | 0155140 | THICKNESS WASHER |
| 162 | 7213021 | GEAR GROUP |
| 169 | 5850110 | CARBON BRUSHE SET |
