Femi Spare Parts for Band Saw SN120XL - 6901707

€18.10
Tax included

Femi Spare Parts for Band Saw SN120XL - 6901707

We are FEMI original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to resolve any maintenance or repair issues for Band Saw SN120XL - 6901707.
ITEM CODE: 5001572
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Femi Spare Parts for Band Saw SN120XL - 6901707

We are FEMI original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you on the purchase of the most suitable spare part to resolve any maintenance or repair issues for Band Saw SN120XL - 6901707.

In the following table, look for the model of Band Saw and the respective parts of the code.
Femi SN120XL - 6901707

Band Saw SN120XL - 6901707
# Part Num. Description
1 5100076 SCREW
2 0063027 BUSHING
3 5080116 SPRING
4 0155143 THICKNESS WASHER
5 0147002 HAND LEVER
7 0120710 PLAIN WASHER
9 0140076 HANDWHEEL
10 0140076 HANDWHEEL
11 5171043 LOCKING PIN
12 0222021 O-RING SEAL
13 0151409 SNAP RING
14 0402905 RIVET
15 5401319 GRADUATE PLATE
17 5124029 ADJUST WASHER
18 7130535 ROD STOP ASSY
21 5133637 ANGULAR PLASTIC FOOT
24 0150701 CYLINDRIC PIN WITH SLOT
25 5124029 ADJUST WASHER
26 7130680 VICE ASSEMBLY
29 0063042 SLEEVE
31 0120706 FLAT WASHER
34 0120710 FLAT WASHER
35 5142070 LEVER
36 5870851 CABLE
38 5050117 HANDLE
39 0802317 SWITCH
41 5154501 CABLE LOCKING DEVICE
43 0179901 NEEDLE
45 5124064 WASHER
46 7214212 DRIVING WHEEL GROUP
47 5124065 WASHER
48 5001572 SHAFT
49 0606205 BALL BEARING
50 5124066 WASHER
52 5137914 WHEEL SUPPORT
53 0155152 THICKNESS WASHER
54 0596002 BALL BEARING
55 5120663 SPACER
58 0123004 NYLON WASHER
61 5124062 WASHER
62 7132504 FREE WHEEL GROUP
63 0124026 THICKNESS WASHER
64 5081005 SPRING
66 5130734 WHEEL GUIDE
68 0080256 SPRING WASHER
69 5100507 BLADE TENSIONING SCREW
70 7130589 COMPLETE BLADE TENSION DEVICE
78 0590634 BALL BEARING
79 0129004 INOX STEEL WASHER
81 5100075 SCREW
82 5100074 SCREW
83 5100065 SCREW
84 5100064 SCREW
85 5181843 SLIDING PROTECTION
86 0600607 BALL BEARING
87 5181868 REAR BLADE GUIDE PROTECTION
88 7132527 COMPLETE REAR BLADE GUIDE
91 5130932 BLADE GUIDE
92 0174022 NEEDLE
93 0590624 BALL BEARING
94 5120638 SPACER
95 0147000 HAND LEVER
96 0120706 PLAIN WASHER
99 5130774 BLADE GUIDE
100 0174016 NEEDLE
101 7213016 GEAR GROUP
102 5850111 FAN WITH MAGNETIC RING
103 7820112 ELECTRONIC SPEED REGULATOR
104 5182857 CASE COVER
107 0802316 SWITCH
110 0816008 THERMOSTAT
111 0816004 RADIO INTERFERENCE SUPPRESSOR
113 5182542 GEAR COVER
114 0600608 BALL BEARING
115 5850008 BRUSHES SUPPORT
116 5182856 MOTOR COVER
117 7013154 ROTOR
119 5063040 THREADED BUSH
121 0606001 BALL BEARING
122 5182006 GREASE BAFFLE PLATE
123 5024121 STATOR - FIELD
124 5850112 CARBON BRUSHE SET
125 5061038 RUBBER BUSHING
126 7801852 MOTOR
127 0123004 NYLON WASHER
129 5181867 ADDITIONAL GUIDE PROTECTION
130 0120706 PLAIN WASHER
131 0147000 HAND LEVER
132 5154501 CABLE LOCKING DEVICE
133 5181004 RUBBER CABLE PROTECTION
134 5870886 CABLE
137 5150005 VICE PIN STOPPER
138 5142014 LEVER
