Dolmar Chainsaw PS460 Parts

€178.37
Tax included

Dolmar Spare Parts for Chainsaw PS460

DOLMAR Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw PS460.
ITEM CODE: 181114111
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Dolmar Spare Parts for Chainsaw PS460

DOLMAR Original spare parts

 at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Chainsaw PS460.

In the following table, look for the model of Chainsaw and the respective parts of the code.
Dolmar PS460

PS460 - ENGINECHAINSAW
Pag.1
# Part Num. Description
1 181114111 FUEL TANK ASSY RED
D10 INC. 2-6,8-12,15,17,18
2 181117050 GRIP OUTER SHELL
2-1 450851-5 GRIP OUTER SHELL
3 181117132 CATCH LEVER
4 181117031 SPRING
5 181117081 ROCKER
6 181117111 SPRING
8 935930240 CYLINDRICAL PIN 3X24
8-1 268233-5 PIN 3
9 181117120 THROTTLE LEVER
9-1 181117121 THROTTLE LEVER
10 957114061 AIR VALVE CPL.
11 913455204 H.L.TAPPING SCREW 5.5X20
11-1 266475-5 H.L.TAPPING SCREW 5.5X20
12 181114065 FUEL LINE
13 163499-1 SUCTION HEAD
C10 010114020 REP.KIT, FILTER(FELT ELEMENT)
13-1 010114200 FUEL FILTER ASSY
15 181114202 TANK CAP CPL.
D10 INC. 16
15-1 168507-3 TANK CAP COMPLETE
D10 INC. 16
16 213080-9 O RING 29.5
17 181114301 DAMPING SPRING, CPL.
18 181114301 DAMPING SPRING, CPL.
19 181310200 FRONT HANDLE
20 913455204 H.L.TAPPING SCREW 5.5X20
20-1 266475-5 H.L.TAPPING SCREW 5.5X20
21 913455164 H.L. TAPPING SCREW 5.5X16
21-1 266478-9 H.L.TAPPING SCREW 5.5X16
22 181114051 HANDLE COVER DOLMAR RED
23 908006205 H.L. SOCKET HEAD BOLT M6X20
23-1 266479-7 H.L. SOCKET HEAD BOLT M6X20
24 913455204 H.L.TAPPING SCREW 5.5X20
24-1 266475-5 H.L.TAPPING SCREW 5.5X20
26 181118261 AIR FILTER ELEMENT COVER
D10 INC. 27
26-1 181118241 AIR FILTER ELEMENT COVER
D10 INC. 27,70
26-2 181118242 AIR FILTER ELEMENT COVER
D10 INC. 27,70
27 181118060 ANTI ICING PLATE SUMMER
28 181173090 AIR FILTER ELEMENT NYLON ME SH
28A_ 181173240 AIR FILTER ELEMENT FINE NYLO N
028B_ 181173190 AIR FILTER ELEMENT FLEECE
29 325593-9 CLIP
30 181171011 AIR SUCTION PIPE
31 908505555 H.L. SOCKET HEAD BOLT M5X55
31-1 266480-2 H.L. SOCKET HEAD BOLT M5X55
32 181155020 ENGINE STOP / CHOKE LEVER
32-1 181155070 ENGINE STOP / CHOKE LEVER
33 970311550 EARTH CABLE
33-1 970311580 EARTH CABLE
34 913455164 H.L. TAPPING SCREW 5.5X16
34-1 266478-9 H.L.TAPPING SCREW 5.5X16
36 181131103 CARBURETOR HOUSING ASSY RED
D10
36-1 181131160 CARBURETOR HOUSING ASSY RED
37 908805205 H.L. SOCKET HEAD BOLT M5X20
37-1 266472-1 TORX SOCKET HEAD BOLT M5X20
38 038118110 RUBBER FLAP
39 938650062 RIVET
40 181171150 INTAKE MANIFOLD SET
D10
40-1 181171160 INTAKE MANIFOLD SET
D10
41 181131090 OIL RESISTANT HOSE
42 181131040 INTAKE MANIFOLD
42-1 181131041 INTAKE HOSE
44 181131070 RING SPRING
44-1 233971-8 RING SPRING
45 913455164 H.L. TAPPING SCREW 5.5X16
45-1 266478-9 H.L.TAPPING SCREW 5.5X16
46 181155010 CONTACT SPRING
47 181155030 ADJUSTING GUIDE
47-1 181155080 ADJUSTING GUIDE
48 913455164 H.L. TAPPING SCREW 5.5X16
48-1 266478-9 H.L.TAPPING SCREW 5.5X16
49 928405000 SPRING WASHER 5
49-1 267821-5 SPRING WASHER 5
50 980115961 LABEL
50-1 816917-5 INDICATION LABEL
53 181174102 MUFFLER
57 181174062 HEAT INSULATION PLATE
58 181174050 GASKET DCS4600S-5000
59 908005205 H.L. SOCKET HEAD BOLT M5X20
59-1 266476-3 H.L. SOCKET HEAD BOLT M5X20
60 181174091 MUFFLER COVER
61 908005095 H.L. SOCKET HEAD BOLT M5X9
61-1 266474-7 H.L. SOCKET HEAD BOLT M5X9
62 908805205 H.L. SOCKET HEAD BOLT M5X20
62-1 266472-1 TORX SOCKET HEAD BOLT M5X20
63 346413-4 BUSH 17
65 179130215 CYLINDER/PISTON SET FOR DEC
D10 INC. 66,74
66 181132064
D10 INC. 67-69
67 180132080 PISTON RING 43MM
68 181132090 PISTON PIN
69 181132050 CIRCLIP 10
69-1 181132050 CIRCLIP 10
70 181118070 RUBBER DAMPING PLUG
70-1 424173-9 DAMPING PLUG
72 908805235 H.L. SOCKET HEAD BOLT M5X23
72-1 266473-9 H.L. SOCKET HEAD BOLT M5X23
73 181114401 DAMPING SPRING,CPL.
74 181131131 CYLINDER GASKET
74-1 181131133 CYLINDER GASKET
74-2 181131134 CYLINDER GASKET
75 181120100 CRANKSHAFT CPL.
75-1 185120200 CRANKSHAFT CPL.
75-2 143395-9 CRANKSHAFT CPL.
76 962210103 NEEDLE BEARING 10X13X12.5CAGE
77 211154-0 BALL BEARING 6202
78 960123159 BALL BEARING 6203 C3
C10 962900065 OIL SEAL
78-1 211250-4 BALL BEARING 1514
79 962900156 OIL SEAL
79-1 213141-5 OIL SEAL 12
80 179111153 CRANKCASE ASSY LEFT RED
D10
80-1 181111155 CRANKCASE ASSY LEFT RED
D10
81 179111141 CRANKCASE ASSY RIGHT RED
D10
81-1 181111142 CRANKCASE ASSY RIGHT RED
D10
82 181111061 CRANKCASE GASKET FOR PS-460/500
83 170114100 TANK CAP COMPLETE
D10
83-1 168508-1 TANK CAP COMPLETE
D10
84 963225030 O RING
84-1 213355-6 O-RING 25
85 181118050 STEELCLIP
86 908006205 H.L. SOCKET HEAD BOLT M6X20
86-1 266479-7 H.L. SOCKET HEAD BOLT M6X20
87 908805205 H.L. SOCKET HEAD BOLT M5X20
87-1 266472-1 TORX SOCKET HEAD BOLT M5X20
88 181111230 RUBBER BUFFER
89 936430160 PIN 3X16
89-1 258038-1 CLAMPING PIN
90 181111230 RUBBER BUFFER
91 908805205 H.L. SOCKET HEAD BOLT M5X20
91-1 266472-1 TORX SOCKET HEAD BOLT M5X20
92 908005205 H.L. SOCKET HEAD BOLT M5X20
92-1 266476-3 H.L. SOCKET HEAD BOLT M5X20
93 181111050 CHAIN CATCH
93-1 181111051 CHAIN CATCH
94 908006205 H.L. SOCKET HEAD BOLT M6X20
94-1 266479-7 H.L. SOCKET HEAD BOLT M6X20
95 905808210 GUIDE BAR BOLT M8X21
96 181250011 SPIKE BAR
97 908805205 H.L. SOCKET HEAD BOLT M5X20
97-1 266472-1 TORX SOCKET HEAD BOLT M5X20
98 010245030 VENT VALVE
98-1 168504-9 VENT VALVE
100 181213300 CHAIN TENSIONER CPL.
D10
101 181213230 TESIONING SCREW
101-1 227743-1 HELICAL GEAR 11
102 181213240 TENSION SLIDE
102-1 181213241 TENSION SLIDE
103 181213250 ADJUSTING SCREW
103-1 227744-9 HELICAL GEAR 18
104 452667-4 GEAR COVER PROFESSIONAL
105 181213260 TENSIONING SCREW BEARING
106 963207020 O RING
107 908705125 H.L. SOCKET HEAD BOLT M5X12
107-1 266484-4 H.L SOCKET HEAD BOLT M5X12
112 181131140 RUBBER BUSH
113 181117094 RETAINING CLIP
114 181117041 THROTTLE CONTROL CABLE
115 181160101 STARTER ASSY RED
D10
116 181112021 STARTER HOUSING RED
117 980115190 LABEL PS-460
118 908805205 H.L. SOCKET HEAD BOLT M5X20
119 001161020 STARTER GRIP
120 108164020 STARTER ROPE 3.5MM (L=0.98M)
122 928405000 SPRING WASHER 5
123 181162150 CABLE DRUM
124 181163020 REWIND SPRING IN HOUSING
125 924605510 WASHER 5.5/18X1.6
126 913455204 H.L.TAPPING SCREW 5.5X20
127 181118041 AIR GUIDE PLATE
128 181143204 IGNITION COIL COMPLETE
D10
128-1 181143206 IGNITION COIL COMPLETE
D10
128-2 181143212 IGNITION COIL COMPLETE
D10
128-3 181143213 IGNITION COIL COMPLETE
D10 INC. 129,131,132
128-4 181143214 IGNITION COIL COMPLETE
D10
129 181147050 IGNITION CABLE
130 195143031 ISOLATION WASHER
130-1 451462-9 ISOLATING WASHER
131 970502110 INSULATING TUBE 6 L=1M
131-1 970502120 INSULATING TUBE
132 957604260 PLUG CAP COMPLETE
D10
133 168648-5 SPARK PLUG (BPMR7A)
134 908805205 H.L. SOCKET HEAD BOLT M5X20
134-1 266472-1 TORX SOCKET HEAD BOLT M5X20
135 920208024 HEX. NUT M8X1(FINE THREAD)
135-1 264107-8 HEXAGONAL NUT M8
136 926208001 SPRING WASHER 8
136-1 267822-3 SPRING WASHER 8
137 181141104 FLYWHEEL ASSY.
D10 INC. 138
138 181166050 STARTER RATCHET CP
140 181245251 OIL PUMP CPL.
D10 INC. 150
142 181155011 CONTACT SPRING
142-1 181155060 CONTACT SPRING
143 181245120 OIL LINE
143-1 424178-9 OIL TUBE
145 144274-4 TUBE COMPLETE
D10 INC. 146,147
146 231975-4 SPRING
147 001245020 HOSE STEM
149 908705125 H.L. SOCKET HEAD BOLT M5X12
149-1 266484-4 H.L SOCKET HEAD BOLT M5X12
150 181245090 PUMP DRIVE
150-1 450956-1 PUMP DRIVE
151 267389-1 FLAT WASHER 12
152 181180300 CLUTCH ASSY
D10 INC. 153
152-1 127443-2 CLUTCH ASSEMBLY
D10 INC. 153
153 232352-3 TENSION SPRING 6
153-1 232352-3 TENSION SPRING 6
154 181224090 FLAT WASHER 10
155 181213011 BRAKE BAND
155-1 346029-5 BRAKE BAND
156 181223312 CLUTCH DRUM CPL. .325", Z=7
D10 INC. 157
156-1 158927-9 CLUTCH DRUM COMPLETE
D10 INC. 157
157 962300009 NEEDLE BEARING
157-1 212082-2 NEEDLE BEARING 1012
159 181224081 WASHER 29
159-1 267820-7 WASHER 29
160 927408000 STOP RING E-8
160-1 259045-7 STOP RING E-8
161 927304000 STOP RING E-4
161-1 257934-0 STOP RING E-4
162 185213100 BREAK LINK PLATE COMPLETE
163 181213023 TENSION SPRING
163-1 231870-8 TENSION SPRING 10
164 181213170 HANDGUARD GUIDE,CPL.
164-1 450926-0 STOPPER CASE
165 181213371 FOAM SPONGE
167 181213161 HAND GUARD CPL.
D10
167-1 181213162 HAND GUARD CPL.
167-2 181213163 HAND GUARD CPL.
168 810449-4 CAUTION LABEL
169 181213310 SPACER
170 181213320 BUSHING
170-1 325604-0 BUSH
171 908805205 H.L. SOCKET HEAD BOLT M5X20
171-1 266472-1 TORX SOCKET HEAD BOLT M5X20
174 181213400 FOAM SPONGE
175 957213200 SPROCKET GUARD COMPLETE RED
D10
176 923208004 HEX. FLANGE NUT M8(BAR NUT)
176-1 252145-2 COLLARED HEX NUT M8
177 957213220 CHIP GUIDE
178 181213191 SPROCKET COVER DCS4600S-5000
179 908105126 H.L.S. FLAT HEAD BOLT M5X12
179-1 266477-1 H.L. C.S. HEAD SCREW M5X12
182 181160155 STARTER ASSY RED
D10
182-1 181160201 STARTER ASSY RED
D10
182-2 123560-6 STARTING DEVICE RED
D10
183 181112060 STARTER HOUSING RED
183-1 140732-8 FAN HOUSING COMPLETE
184 181118041 AIR GUIDE PLATE
184-1 181118120 AIR GUIDE PLATE
184-2 456685-4 AIR GUIDE PLATE
185 181164010 STARTER GRIP
185-1 452458-3 STARTER GRIP
186 266942-0 H.L. SOCKET HEAD BOLT M5X20
187 140587-1 REWIND SPRING COMPLETE
188 181162020 CABLE DRUM
188-1 452224-8 CABLE DRUM
189 234193-3 SPRING EASY START
190 181163090 STARTER WHEEL
190-1 452227-2 DRIVER EASY START
191 181163095 STEPPED TAPPING SCREW 5X16.5
191-1 266616-3 SCREW
192 108164020 STARTER ROPE 3.5MM (L=0.98M)
194 143331-5 FLYWHEEL COMPLETE
D10
195 181166100 STARTER RATCHET CP
200 181153100 CARBURETOR
D10
202 181153030 PUMP COVER
D10
203 038153360 SCREW
204 181153040 DIAPHRAGM COVER
205 ZJ00000014 SCREW (WITH SERRATION)
206 181153020 SET DAIPHRAGM/GASKETS
D10
207 181153050 PUMP DIAPHRAGM TEFLON
208 038153210 LOCKING BALL
209 181153070 IDLE STOP SCREW
210 036153040 SCREEN
211 957153090 KIT THROTTLE SHAFT
D10
212 957153080 KIT CHOKE SHAFT
D10
213 957153070 CONTROL PARTS
214 028153480 SPRING
215 181153180 IDLE ADJUSTMENT SCREW
216 181153190 MAIN ADJUSTMENT SCREW
217 181153220 WASHER
224 181153110 SPRING
225 181153160 SPRING
226 181153210 PLUG-WELCH
230 038155012 RETAINING CLIP
231 965402995 GASKET
250 181153301 CARBURETOR (REGULATED MARKET)
D10
D20
251 181153261 IDLE ADJUSTMENT SCREW L (DD)
252 181153271 MAIN ADJUSTMENT SCREW H (DD)
255 181153031 PUMP COVER
256 181153021 DIAPHRAGM & GASKETS
257 181153560 REBUILD KIT
D10
258 181153570 KIT THROTTLE SHAFT
259 181153580 KIT CHOKE SHAFT
263 965604180 PLUG CAP SPRING
263-1 234358-7 TERMINAL SPRING
264 928405000 SPRING WASHER 5
264-1 267821-5 SPRING WASHER 5
303 038153360 SCREW
304 181153040 DIAPHRAGM COVER
305 ZJ00000014 SCREW (WITH SERRATION)
326 181153210 PLUG-WELCH
330 038155012 RETAINING CLIP
331 965402995 GASKET
A41 957004011 TOOL CPL.
D10
A42 944500795 CYLINDER FIN CLEANER
A43 782033-4 UNIVERSAL WRENCH 13/19
A44 940827000 HEXALOBULAR ANGLED DRIVER T27
A44-1 782025-3 HEXALOBULAR WRENCH 27
A45 783012-5 SCREWDRIVER
A46 950004002 PLASTIC BAG
A46-1 831340-3 TOOL BAG
156 181223322 CLUTCH DRUM CPL. 3/8", Z=7
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Domar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Dolmar PS460
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS APPROX
MORE INFO:
info@bricoutensili.com
New

Download

Dolmar PS460 Parts Diagram

Dolmar PS460 Parts Diagram

Download (1.81MB)

You might also like

Comments (0)
No customer reviews for the moment.

Viewed products

16 other products in the same category:
