Dolmar Lawnmower PM5101S3 Parts
€13.45
Tax included
Dolmar Spare Parts for Lawn Mower PM5101S3
We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawn Mower PM5101S3.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Lawn Mower PM5101S3
We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawn Mower PM5101S3.In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| DOLMAR PM5101S3 - PETROL LAWN MOWER Parts List | ||
| Pag.1 | ||
| # | Part Num | Decription |
| 1 | DA00000964 | OPERATION LEVER |
| 2 | DA00000961 | OPERATION LEVER |
| 3 | 671001524 | PM5100S3 PRESSURE PLATE |
| 4 | 671001524 | PM5100S3 PRESSURE PLATE |
| 5 | 671001029 | GRIP |
| 6 | DA00000963 | UPPER HANDLE |
| 7 | 671006082 | SCREW |
| 8 | 671001150 | PM5100S3 THROTTLE CABLE |
| 9 | DA00000574 | WASHER |
| 10 | DA00000576 | SPRING WASHER |
| 11 | DA00000575 | M6 NUT |
| 12 | DA00000543 | NUT |
| 13 | DA00000573 | PLATE |
| 14 | DA00000543 | NUT |
| 15 | DA00000977 | PM5100S3 TRACTION CABLE |
| 16 | 671001151 | PM5100S3 MOTOR BRAKE CABLE |
| 17 | 671470002 | PM5100S3 RH CASE |
| 18 | 671011123 | SPRING |
| 19 | DA00000972 | ADJUSTMENT BOX |
| 20 | DA00000543 | NUT |
| 21 | DA00000869 | UPPER SPEED ADJUSTMENT LEVER |
| 22 | DA00000870 | LOWER SPEED ADJUSTMENT LEVER |
| 23 | DA00000873 | M4.2X15 SCREW ELM 3310-3710 |
| 24 | 671001514 | PM5100S3 CONTACT |
| 25 | 671001511 | M6X60 SCREW |
| 26 | 671001191 | GEAR CABLE |
| 27 | 671006063 | SCREW M6X40 |
| 28 | DA00000577 | SCREW |
| 29 | DA00000603 | SCREW |
| 30 | 671002075 | WASHER 12/4 |
| 31 | 671470001 | LEFT HOUSING PM5100S3 |
| 32 | 671010630 | SCREW 2X25 |
| 33 | 671001513 | SOCKET 9X32 |
| 34 | 671006063 | SCREW M6X40 |
| 35 | DA00000577 | SCREW |
| 36 | DA00000579 | HOOK |
| 37 | DA00000574 | WASHER |
| 38 | DA00000576 | SPRING WASHER |
| 39 | DA00000575 | NUT M6 |
| 40 | DA00000563 | HEXAGONAL NUT |
| 41 | DA00000564 | KNOB |
| 42 | DA00000924 | SEAL |
| 43 | DA00000569 | SCREW |
| 44 | 671001453 | LOWER HANDLE PLM4110-4610-4611 |
| 45 | 671611001 | CABLE SUPPORT |
| 46 | 671611001 | CABLE SUPPORT |
| 47 | DA00000563 | HEXAGONAL NUT |
| 48 | DA00000564 | KNOB |
| 49 | 671007007 | WASHER 8 ELM3310-3710 |
| 50 | DA00000880 | SCREW M8X35 ELM4410 |
| 51 | DA00000562 | FLANGED NUT |
| 52 | 671001356 | RH SUPPORT PM5100S3 |
| 53 | DA00000537 | FLANGED NUT |
| 54 | 671001355 | RH SUPPORT PM5100S3 |
| Pag.2 | ||
| 55 | 671468001 | COVER PLM4110-4610-4611 |
| 56 | DA00000543 | NUT |
| 57 | 671009017 | BRAKE RING ELM4110 |
| 58 | 671001518 | SUPPORT PLM4110-4610-4611 |
| 59 | 671011101 | SPRING ELM4110 |
| 60 | 671002019 | SCREW M6X12 ELM4110 |
| 61 | 671010280 | ADJUSTABLE HEIGHT PLATE |
| 62 | DA00000543 | NUT |
| 63 | 671800104 | CABLE GROOVE FOR PLM5600 |
| 64 | 671800104 | CABLE GROOVE FOR PLM5600 |
| 65 | DA00000537 | FLANGE NUT |
| 66 | 671144701 | RUBBER RING PM5100S3 |
| 67 | 671001344 | FRAME PM5100S3 |
| 68 | 671513001 | FRONT PANEL PM5100S3 |
| 69 | DA00000911 | SCREW 4.2X10 |
| 70 | 671001571 | PLATE PM5100S3 |
| 71 | DA00000198 | SPRING WASHER |
| 72 | 671201501 | SCREW PM5100S3 |
| 73 | 671111300 | TORSION SPRING |
| 74 | 671001019 | ROD PM5100S3 |
| 75 | 671514001 | SIDE EXHAUST COVER PM5100S3 |
| 76 | 671007007 | WASHER 8 ELM3310-3710 |
| 77 | DA00000832 | SPRING WASHER |
| 78 | 671003024 | SCREW M8X60X17 PLM4110-4610-11 |
| 79 | DA00000586 | SCREW |
| 80 | DA00000617 | SCREW |
| 81 | 671002019 | SCREW M6X12 ELM4110 |
| 82 | 671011021 | SPRING PM5100S3 |
| 83 | 671003042 | SCREW |
| 84 | DA00000971 | PLATE |
| 85 | DA00000549 | NUT |
| 86 | 671001455 | SUPPORT PM5100S3 |
| 87 | DA00000537 | FLANGED NUT |
| 88 | 671001056 | PULLEY |
| 89 | 671004015 | BEARING 6001RS |
| 90 | 671009021 | RING 28 |
| 91 | DA00000563 | HEXAGONAL NUT |
| 92 | 671005008 | NUT M8 PLM4110-4610-4611 |
| 93 | DA00000563 | HEXAGONAL NUT |
| 94 | 671001533 | PRESSURE PLATE |
| 95 | DA00000537 | FLANGED NUT |
| 96 | 671004013 | PULLEY PM5100S3 |
| 97 | DA00000598 | SCREW |
| 98 | DA00000968 | BELT PM5100S3 |
| 99 | 671006123 | SCREW M5X55 |
| 100 | DA00000198 | SPRING WASHER |
| 101 | 671009020 | RING 19 PM5100S3 |
| 102 | 671001457 | PROTECTION PLATE |
| 103 | 671011122 | SPRING PM5100S3 |
| 104 | 671010540 | UPPER PULLEY |
| 105 | 671001082 | LOWER PULLEY |
| 106 | 671501031 | TRACTION PM5100S3 |
| 107 | DA00000543 | NUT |
| 108 | 671002038 | COVER PM5100S3 |
| 109 | 671011156 | SPRING PM5100S3 |
| 110 | 671005011 | NUT M5 ELM4110 |
| 111 | 671001717 | PLATE |
| 112 | DA00000562 | FLANGED NUT |
| 113 | DA00000832 | SPRING WASHER |
| 114 | 671007007 | WASHER 8 ELM3310-3710 |
| 115 | DA00000915 | FIXING PLATE 2 |
| 116 | DA00000537 | FLANGED NUT |
| 117 | 671004015 | BEARING 6001RS |
| 118 | DA00000543 | NUT |
| 119 | DA00000974 | FIXING PLATE |
| 120 | 671011136 | SPRING PM5100S3 |
| 121 | DA00000873 | SCREW M4.2X15 ELM 3310-3710 |
| 122 | 671522001 | BELT COVER PM5100S3 |
| 123 | 671006066 | SCREW PM5100S3 |
| 124 | 671005008 | NUT M8 PLM4110-4610-4611 |
| 125 | DA00000535 | KEY |
| 126 | 671015252 | HUB BLADE PM5100S3 |
| 127 | DA00000973 | BLADE 510MM |
| 128 | DA00000529 | WASHER |
| 129 | 671006065 | SCREW 3/8X30 |
| Pag.3 | ||
| 130 | 671001322 | HUB CAP PM5100S3 |
| 131 | DA00000537 | FLANGE NUT |
| 132 | DA00000538 | BEARING |
| 133 | 671002021 | REAR WHEEL PM5100S3 |
| 134 | DA00000538 | BEARING |
| 135 | 671200010 | GEAR PM5120-5120S |
| 136 | DA00000603 | SCREW |
| 137 | 671251800 | INNER HUB COVER FOR PLM5600 |
| 138 | 671001574 | REAR AXLE PM5100S3 |
| 139 | 671002030 | SCREW PM5100S3 |
| 140 | 671001570 | DEPTH LEVER PLM5113N2 |
| 141 | DA00001058 | KNOB |
| 142 | DA00000549 | NUT |
| 143 | DA00000604 | RETAINING RING |
| 144 | DA00001091 | RIGHT PINION PLM4611 |
| 145 | DA00000597 | PIN |
| 146 | DA00001029 | BEARING FOR ELM4611 |
| 147 | 671002024 | BEARING BOX PLM4611 |
| 148 | DA00000612 | STOP RING |
| 149 | 671002019 | SCREW M6X12 ELM4110 |
| 150 | DA00000542 | SUPPORT |
| 151 | DA00000543 | NUT |
| 152 | DA00001090 | LEFT PINION PLM4110-4610-4611 |
| 153 | 671001575 | BARROW PM5100S3 |
| 154 | DA00000549 | NUT |
| 155 | DA00000549 | NUT |
| 156 | DA00000536 | REAR HUB CAP |
| 157 | DA00000537 | FLANGED NUT |
| 158 | DA00000538 | BEARING |
| 159 | 671020160 | WHEEL 200 PLM4110-4610-4611 |
| 160 | DA00000538 | BEARING |
| 161 | 671001573 | FRONT AXLE PM5100S3 |
| 162 | DA00000549 | NUT |
| 163 | 671445001 | BUSHING ELM4110 |
| 164 | 671418001 | BUSHING ELM4110 |
| 165 | 671002028 | SCREW M6X45 ELM4110 |
| 166 | 671011142 | SPRING PM5100S3 |
| Pag.4 | ||
| 167 | 671454001 | BAG HANDLE ELM4410 |
| 168 | 671521001 | BASKET COVER PM5100S3 |
| 169 | DA00000326 | SCREW 5X16 |
| 170 | 671001443 | BAG FRAME PLM4110-4610-4611 |
| 171 | DA00000025 | WASHER UR3000 |
| 172 | DA00000888 | SCREW 5X12 |
| 173 | DA00000335 | FRONT AXLE FLANGE |
| 174 | DA00000888 | SCREW 5X12 |
| 175 | 671001353 | PLATE PLM4110-4610-4611 |
| 176 | DA00000967 | GRASS COLLECTOR BAG PM5100S3 |
| 177 | 671509001 | MULCHING CAP PM5100S3 |
| 178 | 671316004 | LOCK BUTTON PLM4110-4610- |
| 179 | 671011005 | SPRING PLM4110-4610-4611 |
| 180 | 671317001 | PLATE PLM4110-4610-4611 |
| 181 | DA00000603 | SCREW |
| 182 | DA00000969 | PM5100S3 PROTECTION |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
