Dolmar Lawnmower PM4601SC Parts
€15.20
Tax included
Dolmar Spare Parts for Lawnmower PM4601S
We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawnmower PM4601S - 190CC 46CM DOLMAR.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Lawnmower PM4601S
We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawnmower PM4601S - 190CC 46CM DOLMAR.In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| PM4601SC - RASAERBA 190CC 46CM DOLMAR | ||
| # | Part Num. | Description |
| 1 | 671006065 | BLADE TIGHTEN BOLT 3/8-24UNF |
| 2 | 671010730 | DISH SPRING WASHER |
| 3 | 671001451 | BLADE 46 |
| 3-1 | DA00001274 | BLADE 46 |
| 4 | 671015252 | INNER FRANGE |
| 5 | DA00000979 | BLADE SUPPORT LINING |
| 6 | DA00000535 | HIGHT ADJUST SUPPORTSPRING |
| 7 | DA00000598 | H.S.SET SCREW(FLATPOINT)M6X8 |
| 8 | 671004002 | V PULLEY |
| 9 | 671002043 | V BELT 10MMX6MM L=762MM |
| 11 | 671001037 | TRUSS HEAD TAPPINGSCREW 5X16 |
| 12 | 671005008 | NYLON INSERT HEX.LOCKNUT M8 |
| 13 | 671658001 | BELT PROTECTING COVER |
| 19 | DA00000617 | SPECIAL HEX.BOLTM8X35/M8X17 |
| 20 | DA00000586 | HEX. BOLT M8X35 |
| 21 | 671003024 | SPECIAL HEX. BOLTM8X60/M8X17 |
| 22 | DA00000832 | SPRING WASHER 8 |
| 23 | 671007007 | FLAT WASHER 8 |
| 24 | DA00000911 | TAPPING SCREW ST4.2X10 |
| 25 | 671659001 | FRONT AXLE COVER |
| 26 | 671001176 | WHEEL COVER 6.5 INCH |
| 27 | DA00000537 | HEX.FLANGE LOCK NUT M8 |
| 28 | DA00000538 | BALL BEARING 6201ZZ |
| 29 | 671020150 | WHEEL ASSY 7 INCH |
| 30 | DA00000538 | BALL BEARING 6201ZZ |
| 31 | 671002028 | PAN.HED SCREW M6X45 |
| 32 | 671418001 | FRONT AXLE MOUNT |
| 33 | 671001786 | FRONT AXLE |
| 34 | 671445001 | FRONT AXLE RETAINER |
| 35 | DA00000549 | NYLON INSERT HEX.LOCKNUT M6 |
| 36 | 671002019 | TRUSS HEAD SCREW M6X12 |
| 37 | DA00000542 | AXLE RETAINER |
| 38 | DA00000543 | HEX.FLANGE LOCK NUT M6 |
| 39 | DA00000604 | STOP RING E-12 |
| 40 | DA00000607 | SPUR GEAR 14 RIGHT |
| 41 | DA00000609 | BEARING |
| 42 | DA00000610 | DRIVE SHAFT BEARING CASE |
| 43 | DA00000604 | STOP RING E-12 |
| 44 | DA00000597 | COLUMN PIN 5X21.5 |
| 45 | 671502016 | GEAR ASSY FOR SELFDRIVING |
| 46 | DA00000605 | SPUR GEAR 14 LEFT |
| 47 | DA00000915 | GEAR BOX MOUNT ANGLE |
| 48 | 671007007 | FLAT WASHER 8 |
| 49 | DA00000832 | SPRING WASHER 8 |
| 50 | DA00000562 | HEX.FLANGE BOLT M8X16 |
| 51 | 671001460 | GEAR BOX MOUNT PLATE |
| 52 | 671005011 | NYLON INSERT HEX.LOCKNUT M5 |
| 53 | DA00000864 | SPRING WASHER 6 |
| 54 | 671002019 | TRUSS HEAD SCREW M6X12 |
| 67 | DA00000536 | WHEEL COVER 7 INCH |
| 68 | DA00000537 | HEX.FLANGE LOCK NUT M8 |
| 69 | DA00000538 | BALL BEARING 6201ZZ |
| 70 | 671020300 | WHEEL ASSY 8 INCH |
| 71 | DA00000849 | INTERNAL GEAR |
| 72 | DA00000603 | TAPPING SCREW ST4X16 |
| 073 | DA00000606 | REAR WHEEL DUST-PROOFCOVER |
| 74 | DA00000538 | BALL BEARING 6201ZZ |
| 75 | DA00000612 | STOP RING E-19 |
| 76 | 671144602 | REAR AXLE |
| 77 | DA00000912 | PAN.HED SCREW M5X14 |
| 78 | 671001430 | HEIGHT ADJUSTMENT LEVERASSY |
| 79 | 671102602 | HEIGHT ADJUSTMENT LEVERASSY |
| 79-1 | DA00001073 | HANDLE SET |
| 80 | 671005011 | NYLON INSERT HEX.LOCKNUT M5 |
| 81 | 671002019 | TRUSS HEAD SCREW M6X12 |
| 82 | DA00000787 | HEIGHT ADJUSTER STOPPLATE |
| 83 | DA00000543 | HEX.FLANGE LOCK NUT M6 |
| 84 | 671001526 | DECK RED |
| 85 | 671011125 | HEIGHT ADJUST TENSIONSPRING |
| 86 | DA00000562 | HEX.FLANGE BOLT M8X16 |
| 87 | 671001213 | RIGHT HANDLE BRACKET RED |
| 88 | DA00000537 | HEX.FLANGE LOCK NUT M8 |
| 89 | DA00000543 | HEX.FLANGE LOCK NUT M6 |
| 90 | 671009017 | STOP RING E-6 |
| 91 | 671001518 | REAR FLAP HINGE ROD |
| 92 | 671011101 | REAR FLAP TORSION SPRING |
| 93 | 671001212 | LEFT HANDLE BRACKET RED |
| 94 | 671800104 | GROMMET |
| 95 | DA00000549 | NYLON INSERT HEX.LOCKNUT M6 |
| 96 | 671002671 | LINK ROD |
| 97 | 671001353 | GRASS CATCHER FRAMESHEATH |
| 98 | 671468001 | REAR FLAP |
| 99 | 671001443 | GRASS CATCHER FRAME |
| 100 | 671001436 | WASHER 4 |
| 100-1 | DA00000025 | WASHER 5 |
| 101 | 671001203 | RETAINER PLATE |
| 101-1 | DA00000335 | RETAINER PLATE |
| 102 | DA00000888 | TAPPING SCREW ST5X12 |
| 103 | 671105502 | TAPPING SCREW ST5X16 |
| 103-1 | DA00000326 | TAPPING SCREW ST5X16 |
| 104 | 671467001 | GRASS CATCHER UPPERBORAD |
| 105 | 671454001 | GRASS CATCHER HANDLE |
| 106 | DA00000966 | GRASS CATCHER CLOTH SETDOLMAR |
| 107 | DA00000563 | HEXAGON NUT M8 |
| 108 | DA00000564 | KNOB |
| 109 | 671007007 | FLAT WASHER 8 |
| 110 | DA00000880 | SADDLE HEAD BOLT M8X35 |
| 111 | 671611001 | CABLE CLIP |
| 112 | 671001606 | LOWER HANDLE BAR |
| 113 | DA00000563 | HEXAGON NUT M8 |
| 114 | DA00000564 | KNOB |
| 115 | DA00000565 | PLASTIC SADDLE WASHER 8 |
| 116 | DA00000569 | SADDLE HEAD BOLT M8X58 |
| 117 | DA00000577 | HEX.FLANGE BOLT M6X35 |
| 118 | DA00000579 | STARTER GRIP HOOK |
| 119 | DA00000574 | FLAT WASHER 6 |
| 120 | DA00000864 | SPRING WASHER 6 |
| 121 | DA00000575 | HEX.CAP NUT M6 |
| 122 | 671611001 | CABLE CLIP |
| 123 | 671006082 | HEX. FLANGE BOLT M6X50 |
| 124 | 671001137 | THROTTLE CONTROL BOXASSY |
| 125 | DA00000574 | FLAT WASHER 6 |
| 126 | DA00000864 | SPRING WASHER 6 |
| 127 | DA00000575 | HEX.CAP NUT M6 |
| 128 | DA00000575 | HEX.CAP NUT M6 |
| 129 | DA00000573 | OUTER WIRE STOPPER |
| 130 | DA00000977 | SELF DRIVE CONTROL WIREASSY |
| 131 | 671001113 | ENGINE CLUTCH WIRE |
| 132 | DA00000577 | HEX.FLANGE BOLT M6X35 |
| 149 | 671002001 | UPPER HANDLE BAR ASSY |
| 150 | 671001524 | SADDLE WASHER 8 |
| 151 | DA00000961 | ENGINE CLUTCH LEVER |
| 152 | DA00000964 | SELF DRIVE CONTROL LEVER |
| 153 | DA00000537 | HEX.FLANGE LOCK NUT M8 |
| 154 | 671003012 | HEX. BOLT M5X14 |
| 155 | 671010830 | OUTER WIRE STOPPER |
| 156 | DA00000603 | TAPPING SCREW ST4X16 |
| 157 | 671317001 | PRESSING BOARD OF LOCKING |
| 158 | 671011005 | COMPRESSION SPRING |
| 159 | 671316004 | LOCKING BUTTON |
| 160 | 671660001 | MULCHING PLUG BOX |
| A01 | 671001078 | BOX WRENCH 21MM |
| A02 | DA00000584 | WRENCH HANDLE |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
