Dolmar Spare Parts for Brushcutter MS20C
€225.79
Tax included
Dolmar Spare Parts for Brushcutter MS20C
We have the original DOLMAR Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.Fix Your Brushcutter MS20C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Brushcutter MS20C
We have the original DOLMAR Parts, the diagram and parts list and tool repair that help you need to get your tools running like new again.
Fix Your Brushcutter MS20C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| MS20C - BRUSHCUTTER 20CC DOLMAR pag.1 | ||
| # | Part Num. | Description |
| 1 | 6191010000 | PIPE SHAFT COMP. CPL X RBC201 |
| 2 | 324893-4 | SHAFT EBH252L |
| 3 | 6193004002 | GEAR BOX CPL RBC201 |
| 4 | 6193003001 | CUTTER SHAFT GEAR SET RBC201 |
| 5 | 210049-4 | BALL BEARING 609ZZ EBH252L |
| 6 | DA00000158 | BALL BEARING 626ZZ |
| 7 | 0600109930 | BALL BEARING XRBK250 / RBC225-255 |
| 8 | 6198500102 | RECEIVE WASHER RBC201 |
| 9 | 6193004010 | WASHER RBC201 |
| 10 | 0031508000 | OUTER SNAP RING XRBC260-230-225-255 |
| 11 | 0031424000 | INNER SNAP RING XRBC260-230-225- |
| 12 | 0031426000 | INNER SNAP RING X RBC260 / 230/225/2 |
| 13 | 6253011012 | OIL BOLT M6 X 9 RBC201 |
| 14 | 6193004020 | NUT M8 RBC201 |
| 15 | 0119059890 | SOCKET HEAD BOLT M5X25 XRBC225- |
| 16 | 6251501400 | GASKET RBC201 |
| 17 | 0119059900 | SOCKET HEAD BOLT M5X12 X RBC225-255 |
| 18 | 6197005001 | HANGER ASS'Y X MS20C |
| 19 | 0043605203 | TAPPING SCREW X MS20C |
| 20 | 6218008003 | PROTECTOR ASS'Y FOR BRUSHCUTTER |
| 21 | 6418500303 | BRACKET RBC201 |
| 22 | 0011706300 | BOLT M6X30 X RBK250-RBC225- |
| 101 | 0150059940 | SCREW X RBK250-RBC225-RBC255 |
| 102 | 6271501501 | SPACER RBC201 |
| 104 | 6195021000 | CONTROL LEVER X MS20C |
| 105 | 0119069880 | SCREW M6X20 X RBC525 |
| 106 | 6415011140 | NUT X EH760 HT2276E |
| 107 | 6214016000 | HANDLE X MS20C |
| 108 | 0022705000 | NUT M5 X RBC230 / 310 / RBK410 |
| 109 | 6214016020 | LOWER HANDLE MS20C |
| 110 | 6214016030 | SCREW X MS20C |
| MS20C - BRUSHCUTTER 20CC DOLMAR pag.2 | ||
| 23 | 5191004000 | CRANK CASE ASS'Y RBC201 |
| 24 | 0440109980 | OIL SEAL RBC201 |
| 25 | 0600109980 | BALL BEARING 6000 |
| 26 | 5191500702 | CYLINDER RBC201 |
| 27 | 442173-7 | CYLINDER GASKET CYL.RBC201 |
| 28 | 5191500400 | CRANKCASE GASKET RBC201 |
| 29 | 0119059730 | SOCKET HEAD BOLT X RBC 260/230/225/255 |
| 30 | 0140059500 | SCREW M5X25 X RBC225-255 |
| 31 | 141047-6 | CRANKSHAFT COMPLETE |
| 32 | 5192500800 | PISTON RBC201 |
| 33 | 268277-5 | PISTON PIN |
| 34 | 5192500600 | PISTON RING RBC201 |
| 35 | 233976-8-4 | CLIP EBH252L (4pcs) |
| 36 | 5193001002 | EXHAUST MUFFLER RBC201 |
| 37 | 5193500001 | MUFFLER INSULATOR RBC201 |
| 38 | 0119059520 | SCREW M5 X 40 RBC201 |
| 39 | 141056-5 | INSULATOR COMPL |
| 40 | 442175-3 | INSULATOR GASKET RBC201 |
| 43 | 442177-9 | GASKET |
| 44 | 5193500302 | PLATE RBC201 |
| 45 | 0140059500 | SCREW M5X25 X RBC225-255 |
| 46 | 5193500101 | PLATE RBC201 |
| 47 | 6165500201 | METAL WIRE RBC201 |
| 48 | 126037-0 | REWIND STARTER ASS'Y X MS20C |
| 49 | 325923-4 | SWING ARM EBH252L |
| 50 | 452972-9 | STARTER REEL |
| 51 | 266585-8 | SCREW 5X12 EBH252L |
| 52 | 234220-6 | SPIRAL SPRING |
| 53 | 5255016020 | STARTER ROPE X RBC201 |
| 54 | 5225004020 | STARTER KNOB HT2256D |
| 55 | 451938-6 | COLLAR EBH252L |
| 56 | 5195500000 | ENGINE COVER RBC201 |
| 57 | 5195501201 | CYLINDER COVER X MS20C |
| 59 | 0043604250 | SCREW M4 X 25 RBC201 |
| 62 | 452989-2 | FUEL TANK CPL |
| 64 | 163447-0 | FUEL FILTER X DCS230T |
| 65 | 0561059990 | HOSE CLAMP X RBC230-310 / 520 |
| 66 | 452920-8 | FUEL TANK CAP |
| 67 | 424102-2 | SHOCK ABSORBER EBH341U |
| 68 | 424103-0 | SHOCK ABSORBER EBH341U |
| 69 | 5216500200 | DAMPER X RBC230-225-255 |
| 70 | 5197001010 | FLTYWHEEL RBC201 |
| 71 | 5197001020 | IGNITION COIL RBC201 |
| 72 | 0851119930 | TUBE RBC201 |
| 73 | 0655009940 | SPARK PLUG CAP X RBC410 / RBK410RBC520 |
| 74 | 5197500100 | SPARK PLUG COVER RBC201 |
| 75 | 324891-8 | PLUG CAP SPRING EBH341 |
| 76 | 0650149721 | SPARK PLUG BMR7A RBK250 |
| 77 | 911526-6 | SCREW M4 X 14 X HR2420 |
| 78 | 5257018001 | WIRE COMPLETE RBC201 |
| 79 | 141058-1 | CLUTCH CASE COMPLETE |
| 80 | 0150059780 | SCREW M5X20 X MS20C |
| 81 | 0566059980 | BRACKET X RBC525 |
| 82 | 424461-4 | SHOCK ABSORBER |
| 83 | 318792-0 | PIPE BRACKET |
| 84 | 0119059880 | BOLT X RBC 310 |
| 85 | 6601500500 | SCREW X RBL250 |
| 86 | 161477-5 | CLUTCH DRUM |
| 87 | 6192002003 | CLUTCH RBC201 |
| 88 | 0031510000 | OUTER SNAP RING X RBK 410 |
| 89 | 140436-2 | TANK CAP STRAP EBH341U |
| MS20C - BRUSHCUTTER 20CC DOLMAR pag.3 | ||
| 11 | 911218-7 | SCREW ASS'Y M5X14 |
| 12 | 0043105600 | SCREW M5X60 X RBC230 / RST250 |
| 13 | 452971-1 | FILTER COVER X MS20C |
| 14 | 443168-3 | AIR FILTER X MS20C |
| 15 | 126036-2 | PLATE,AIR CLEANER ASSY |
| 17 | 213632-6 | RING 14 |
| 18 | 5196019450 | SCREW CABLE ACCELERATOR X MS20C |
| 19 | 5196019460 | WASHER X MS20C |
| 20 | 234221-4 | STARTER SPRING |
| 21 | 452976-1 | STARTER LEVER X MS20C |
| 22 | 5196019320 | PRIMING PUMP PLATE X MS20C |
| 23 | 5196019140 | SCREW X MS20C |
| 24 | 424462-2 | PRIMING PUMP X MS20C |
| 25 | 5196019250 | SCREW X MS20C |
| 26 | 5196019510 | CIRCLIP X MS20C |
| 27 | 5246009030 | VALVE X MS20C |
| 28 | 452975-3 | PUMP COVER |
| 29 | 352018-0 | REEL |
| 31 | 5196019350 | PUMP BODY X MS20C |
| 32 | 424460-6 | PUMP DIAPHRAGM |
| 33 | 442176-1 | PUMP PACKING |
| 34 | 5196032010 | MAIN JET X MS20C |
| 35 | 126052-4 | CHECK VALVE ASSY X MS20C |
| 36 | 5196019430 | SCREW X MS20C |
| 37 | 5196019060 | SCREW X MS20C |
| 38 | 346513-0 | DIAPHRAGM COVER ASSY |
| 39 | 126038-8 | DIAPHRAGM |
| 40 | 5196019420 | PLATE X MS20C |
| 41 | 5196019410 | RING X MS20C |
| 42 | 5196019150 | RING X MS20C |
| 43 | 5196019220 | RING X MS20C |
| 44 | 5196019240 | ADJUST SCREW X MS20C |
| 45 | 5196019310 | SCREW X MS20C |
| MS20C - BRUSHCUTTER 20CC DOLMAR pag.4 | ||
| 1 | 6197003000 | HARNESS ASSY RBC201 |
| 2 | B-02945 | TAP & GO NYLON HEAD M8-M10X1.25F |
| 3 | 6199003000 | SERVICE KEYS RBC201 |
| 4 | 0717049990 | WRENCH X NUTS RBC350-RBC420 |
| 5 | 0717059990 | WRENCH X NUTS RBC350-RBC420 |
| MS20C - BRUSHCUTTER 20CC DOLMAR pag.5 | ||
| 1 | 6195021000 | CONTROL LEVER ASSY X MS20C |
| 2 | 6195006060 | SCREW M 4 X 20 X MS251.4 |
| 3 | 0119059720 | SCREW M 5 X 20 X MS251.4 |
| 4 | 6195021010 | WIRE SET X MS20C |
| 5 | 6195021020 | THROTTLE CABLE X MS20C |
| 6 | 6195006050 | SPRING X MS251.4 |
| 7 | 6215023060 | LEVER X MS251.4 |
| 8 | 6415011160 | NUT X EH760 HT2276E |
| 9 | 6195006150 | COVER X MH2556 |
| 10 | 6415011160 | NUT X EH760 HT2276E |
| 11 | 6195006030 | LEVER X MS251.4 |
| 12 | 0119059720 | SCREW M 5 X 20 X MS251.4 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
