Dolmar Spare Parts for Brushcutter MS230C
€41.64
Tax included
Dolmar Spare Parts for Brushcutter MS230C
We have the original DOLMAR Parts for Brushcutter MS230C, the diagram and parts list and tool repair that help you need to get your tools running like new again.Fix Your Brushcutter MS230C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Brushcutter MS230C
Fix Your Brushcutter MS230C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 351130040 | CASE,DRIVE BCM2310 |
| 2 | 351130050 | CASE,STARTER BCM2310 |
| 3 | 351110601 | BEARING BCM2310 - MS230 |
| 4 | 351210050 | OIL SEAL X BCM2310-MS230 |
| 5 | 351400030 | PIN BCM2310-MS230 |
| 6 | 351120280 | SCREW CPL BCM2310-230C |
| 7 | 351900050 | GUIDE BCM2310-MS230C |
| 8 | 351900060 | GUIDE BCM2310-2610 |
| 9 | 351400040 | PIN BCM2310-MS230 |
| 10 | 351300240 | FLYWHEEL HOUSING BCM2310-MC230C |
| 11 | 352645690 | SCREW BCM2310 - MS230C |
| 13 | 351900760 | CRANKCASE GUARD BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.2 | ||
| 1 | 351130210 | CYLINDER BCM2310 MS230C |
| 2 | 351320140 | CYLINDRER GASKET BCM2310 |
| 3 | 351121052 | SCREW BCM2310 - MS230C |
| 4 | 351900160 | COVER BCM3300-3310 |
| 5 | 351900170 | INTERMEDIATE FALNGE BCM2310 |
| 6 | 351390770 | GASKET BCM2310-2610 |
| 7 | 351120310 | SCREW BCM2310-2610 |
| 8 | 351151055 | THREADED BOLT BCM2310-2610 |
| 9 | 352400940 | CYLINDER COVER RED |
| 10 | 351700200 | COVER FOR SPARK PLUG RED BCM2310-2610 |
| 11 | 351071520 | SCREW + WASHER BCM2310-2610 |
| 12 | 351120430 | SCREW + WASHER BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.3 | ||
| 1 | 351010330 | CRANKSHAFT BCM2310-2610 |
| 2 | 351130150 | PISTON 31MM BCM2310-2610 |
| 3 | 351648150 | PISTON PIN BCM2310-2610 |
| 4 | 351642640 | PISTON RINGS BCM2310-2610 |
| 5 | 351648170 | CIRCLIP |
| 6 | 351648570 | NEEDLE BEARING BCM2310-2610 |
| 7 | 351700280 | NUT BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.4 | ||
| 1 | 351110260 | FLYWHEEL BCM2310-2610 |
| 2 | 351040320 | IGNITION COIL BCM2310 |
| 3 | 351649610 | PLUG CAP BCM2310 |
| 4 | 351900010 | RUBBER BUSH BCM2310-2610 |
| 5 | 351667510 | COVER BCM2310-2610 |
| 6 | 351645690 | SCREW + WASHER BCM2310-2610 |
| 7 | 351410110 | SPARK PLUG NGK BPMR8Y BCM2310 |
| 8 | 351902390 | CABLE ASSY. BCM2310 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.5 | ||
| 1 | 351340660 | INTERMEDIATE FLANGE GASKET |
| 2 | 351310310 | INTERMEDIATE FLANGE BCM2310 |
| 3 | 352649600 | SCREW + WASHER BCM2310-2610 |
| 4 | 351390910 | CARBURETOR GASKET |
| 5 | 352210440 | CARBURETOR BCM2310-2610 |
| 7 | 351210092 | CARBURETOR FILTER BCM2310 |
| 8 | 351220073 | VALVE BCM2310-2610 |
| 9 | 352230025 | SPRING BCM2310-2610 |
| 10 | 351220075 | SCREW BCM2310-2610 |
| 11 | 353666527 | AXLE BCM2310-2610 |
| 12 | 353666529 | CONTROL LEVER BCM2310-2610 |
| 14 | 351220077 | PUMP COVER BCM2310-2610 |
| 15 | 351210173 | PRIMING PUMP BCM2310- |
| 16 | 351210286 | LOWER DIAPHRAGM BCM2310-2610 |
| 17 | 352220072 | GASKET BCM2310-2610 |
| 18 | 352210175 | UPPER DIAPHRAGM |
| 19 | 352210289 | PUMP BODY GASKET |
| 20 | 352220570 | JET BCM2310-2610 |
| 21 | 351210172 | RING BCM2310-2610 |
| 22 | 354666522 | SAFETY WASHER BCM2310 |
| 23 | 353210242 | THROTTLE CABLE SUPPORT |
| 24 | 353210171 | SCREW BCM2310-2610 |
| 25 | 352220234 | ADJUST SCREW SUPPORT |
| 26 | 353210177 | NUT BCM2310-2610 |
| 27 | 352220086 | ADJUSTSCREW BCM2310-2610 |
| 28 | 352210289 | PUMP BODY GASKET |
| 29 | 352220079 | SCREW BCM2310-2610 |
| 30 | 353220044 | WASHER BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.6 | ||
| 1 | 351110250 | AIR FILTER HOLDER |
| 2 | 351071550 | SCREW + WASHER BCM2310-2610 |
| 3 | 351400800 | AIR FILTER BCM2310-2610 |
| 4 | 351020320 | AIR FILTER COVER |
| 5 | 351649600 | SCREW + WASHER BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.7 | ||
| 1 | 351700610 | INSULATING PROTECTION |
| 2 | 351010800 | MUFFLER BCM2310-2610 |
| 4 | 351901790 | SPARK GUARD BCM2310-2610 |
| 5 | 351006306 | SCREW BCM2310-2610 |
| 6 | 351675660 | NUT BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.8 | ||
| 1 | 351010490 | CLUTCH BCM2310-2610 |
| 3 | 351010492 | CLUTCH SPRING BCM2310-2610 |
| 4 | 351140040 | HEXAGONAL SCREW BCM2310-2610 |
| 5 | 351340030 | WASHER BCM2310-2610 |
| 6 | 351340070 | WASHER BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.9 | ||
| 1 | 351200880 | STARTER ASSY BCM2310-261 |
| 2 | 351200881 | STARTER CARTER BCM2310 |
| 3 | 351200216 | ROPE GUIDE BCM2310-2610 |
| 4 | 351200885 | REEL X ROPE BCM2310-2610 |
| 5 | 351671663 | STARTER SPRING |
| 6 | 351200887 | CATCH BCM2310-2610 |
| 7 | 351200888 | SCREW BCM2310-2610 |
| 8 | 351200889 | SPACER BCM2310-2610 |
| 9 | 352200881 | STARTING ROPE BCM2310-2610M |
| 10 | 352668811 | STARTER HANDLE BCM2310 |
| 11 | 352200970 | SQUARE WASHER BCM2310-2610 |
| 12 | 351300450 | STARTER PULLEY BCM2310 |
| 13 | 351120430 | SCREW + WASHER BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.10 | ||
| 1 | 351010750 | FUEL TANK BCM2310-2610 |
| 2 | 351050230 | FUEL TANK CAP BCM2310-2610 |
| 3 | 351901550 | SEAL RING BCM2310-2610 |
| 7 | 351901540 | SPONGE RING BCM2310-2610 |
| 8 | 351900480 | POWER SUPPLY CAP BCM2310 |
| 9 | 351700110 | FUEL HOSE L=220 |
| 10 | 351700310 | FUEL HOSE L=75 |
| 11 | 351010337 | CLAMP |
| 12 | 352400040 | FUEL FILTER BCM2310 |
| 13 | 351300200 | BASE |
| 14 | 351800080 | WASHER BCM2310-2610 |
| 15 | 352120180 | SCREW + WASHER MS430U |
| 16 | 354120180 | SCREW + WASHER BCM2310-2610 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.11 | ||
| 1 | 351010151 | Allen key BCM2310-2610 |
| 2 | 351010152 | Allen key BCM2310-2610 |
| 3 | 351010153 | Allen key BCM2310-2610 |
| 4 | 351010154 | HEXAGONAL WRENCH BCM2310-2610 |
| 5 | 351010155 | BAG FOR KEYS BCM2310- |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.12 | ||
| 1 | 351501091 | MAIN SHAFT BCM2310-2610 |
| 2 | 351501042 | DRIVE SHAFT BCM2310-2610 |
| 3 | 351505080 | CLUTCH HOUSING BCM2310-2610 |
| 4 | 351505041 | CLUTCH DRUM BCM2310-2610 |
| 7 | 351090921 | SPACER BCM2310-2610 |
| 8 | 351505013 | BEARING BCM2310-2610 |
| 9 | 351505048 | ANTIVIBRATION BCM2310-2610 |
| 10 | 351505015 | CIRCLIP BCM2310-2610 |
| 11 | 351505016 | CIRCLIP BCM2310-2610 |
| 12 | 351505017 | SCREW BCM2310-2610 |
| 13 | 351505018 | SCREW BCM2310-2610 |
| 14 | 351505047 | SCREW BCM2310-2610 |
| 15 | 351506021 | LEVER CASE, RIGHT |
| 16 | 351506023 | HANDLE HALF |
| 17 | 351506025 | THROTTLE LEVER BCM2310-2610 |
| 18 | 351506026 | SAFETY LEVER BCM2310-2610 |
| 19 | 351506027 | SWITCH BCM2310-2610 |
| 20 | 351506028 | CLAMP BCM2310-2610 |
| 21 | 351506019 | TORSION SPRING BCM2310 |
| 22 | 352506010 | TORSION SPRING BCM2310-2610 |
| 23 | 352506011 | THROTTLE CABLE BCM2310-2610 |
| 24 | 352506013 | CABLE ASSY. BCM2310-2610 |
| 25 | 351505018 | SCREW BCM2310-2610 |
| 26 | 352506015 | SCREW BCM2310-2610 |
| 27 | 351507061 | UPPER HANDLE BCM2310-2610 |
| 28 | 351507014 | SCREW BCM2310-2610 |
| 29 | 351504016 | NUT BCM2310-2610 |
| 30 | 351507026 | LOWER HANDLE BCM2310-2610 |
| 31 | 351508050 | HOOK BCM2310-2610 |
| 32 | 351508012 | SCREW BCM2310-2610 |
| 33 | 351508013 | NUT BCM2310-2610 |
| 34 | 351508014 | WASHER 351508012 |
| 35 | 351509010 | HARNESS BCM2310-2610 |
| 36 | 351504020 | SCREW BCM2310-2610 |
| 39 | 351501095 | HANDLE X SHAFT BCM2310 |
| MS230C - BRUSHCUTTER 22,6 CC M10x1 Pag.13 | ||
| 2 | 351502031 | HOUSING BCM2310-2610 |
| 3 | 351502032 | COVER X HEAD BCM2310 |
| 4 | 351502033 | THREAD BUSH BCM2310 |
| 5 | 351502034 | NUT BCM2310-2610 |
| 6 | 351502015 | BUSH BCM2310-2610 |
| 7 | 351502037 | SPRING BCM2310-2610 |
| 8 | 351503040 | GEAR ASSY BCM2310 |
| 9 | 351503042 | GEAR BCM2310-2610 |
| 10 | 351503043 | BEVEL GEAR BCM2310-2610 |
| 11 | 351503044 | SPINDLE BCM2310-2610 |
| 12 | 351503045 | MOUNTING DISC MS230C-260C |
| 13 | 351503046 | BEARING BCM2310-2610 |
| 14 | 351503047 | BEARING BCM2310-2610 |
| 15 | 351503048 | BEARING BCM2310-2610 |
| 16 | 351503049 | BEARING BCM2310-2610 |
| 17 | 352503020 | SAFETY RING BCM2310 |
| 18 | 352503021 | SAFETY RING BCM2310 |
| 19 | 352503040 | SAFETY RING BCM2310 |
| 20 | 352503043 | PROTECTION BCM2310-2610 |
| 21 | 352503022 | SCREW BCM2310-2610 |
| 22 | 352503045 | SCREW BCM2310-2610 |
| 23 | 352503046 | SPACER BCM2310-2610 |
| 24 | 352503047 | OIL SEAL BCM2310-2610 |
| 25 | 352503048 | SCREW BCM2310-2610 |
| 26 | 351505047 | SCREW BCM2310-2610 |
| 27 | 352504081 | STONE PROTECTION BCM3300- |
| 28 | 351504032 | SUPPORT X PROTECTION BCM2310-2610 |
| 29 | 351504083 | THREAD SIZE BCM2310-2610 |
| 30 | 352506015 | SCREW BCM2310-2610 |
| 31 | 351504020 | SCREW BCM2310-2610 |
| 32 | 351504086 | NUT BCM2310-2610 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
