Dolmar Spare Parts for Petrol Brusch Cutter MS22C

Name: Dolmar Spare Parts for Petrol Brusch Cutter MS22C
Brand: Makita
SKU: Dolmar MS22C
Price: 7.8 EUR
Availability: InStock

€7.80

Tax included

Dolmar Spare Parts for Petrol Brusch Cutter MS22C

Dolmar genuine spare parts for the repair or replacement of Petrol Brusch Cutter MS22C.

Very versatile brushcutters suitable for garden care.
Ideal for the demanding user who does not want to give up quality, reliability and safety.
Innovative and ergonomic design.
Soft and comfortable handle fixed on aluminum rod.
Easy maintenance.

ITEM CODE: 5193500101

5193500101
5216500200
0021805000
0022705000
0031424000
0031426000
0031510000
0043105600
0100069790
0119059490
0119059520
0119059730
0119059850
0119059880
0119059890
0140059360
0140059380
0140059500
0150059780
0440109980
0561059990
0566059980
0600109910
0600109980
0650149661
0654009931
0655009870
0851089950
125476-1
126036-2
126037-0
126038-8
140436-2
141047-6
141056-5
141058-1
141986-0
161477-5
162329-3
163447-0
168668-9
168680-9
168683-3
168797-8
210049-4
213632-6
233976-8-4
234220-6
234221-4
257320-5
264018-7
265195-8
266585-8
268277-5
318785-7
318792-0
318831-6
324893-4
325923-4
326906-7
346513-0
352018-0
424102-2
424103-0
424460-6
424461-4
424462-2
442173-7
442175-3
442176-1
442177-9
443168-3
450653-9
451938-6
452920-8
452971-1
452972-9
452975-3
452976-1
452989-2
5191004001
5191500400
5193001002
5193001050
5195500000
5195501201
5196019060
5196019140
5196019150
5196019220
5196019240
5196019250
5196019310
5196019320
5196019360
5196019410
5196019420
5196019430
5196019450
5196019460
5196019510
5196032010
5197017010
5197018000
5197500100
5225004020
5246009030
5255016020
6165500201
6192002003
6193006120
6195021000
6197005001
6198008001
6198014001
6199519800
6199520100
6214016000
6214016030
6243008002
6253011012
6258061002
6258508200
6271501501
6279505700
911128-8
911218-7
DA00000158
122979-6

Quantity

Usually Ships in: 7/10 Business Days Approx.

Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Description
Product Details
Attachments

Dolmar Spare Parts for Petrol Brusch Cutter MS22C

Dolmar genuine spare parts for the repair or replacement of Petrol Brusch Cutter MS22C.

In the following table, look for the model of the Brusch Cutter and the respective parts of the code.

Dolmar Petrol Brusch Cutter MS22C - Spare Parts List
A Pag.1
#	Part Num.	Description
1	6214016000	HANDLE SETMS26C
2	6214016030	SCREW MS26C
3	0022705000	NUT M5
4	6195021000	LEVER
5	6197005001	HANGER ASS'Y MS26C
6	0140059360	SCREW & WASHER ASS'Y MS26C
7	6271501501	SPACER MS26C
8	141986-0	SHAFT PIPE
9	6199519800	CAUTION LABEL
10	6198014001	GUARD X RBC2110
11	6258061002	GUARD ASSY
12	0100069790	BOLT M6X30MS26C
13	6258508200	HOLDER GUARD
14	0140059380	SCREW M5X40 ASSEMBLY MS26C
15	6198008001	LOWER GARD
16	0021805000	NUT
17	0119059490	SOCKET HEAD BOLT M5X14 (W,SW)
18	324893-4	SHAFT, MEM427
19	125476-1	GEAR CASE ASSEMBLY
20	0031424000	INNER SNAP RING
21	6193006120	OUTER SNAP RING MS26C
22	210049-4	BALL BEARING 609ZZ, EBH251U
23	0119059890	SOCKET HEAD BOLT M5X25
24	6253011012	OIL BOLT M6X9
25	450653-9	PAN HEAD SCREW M5X12
26	265195-8	SCREW M5X12 RBC2510
27	DA00000158	BALL BEARING 626ZZ
28	0600109910	BALL BEARING 6000DDUMS26C
29	0031426000	INNER SNAP RING
30	326906-7	RECIEVE WASHER
31	168797-8	CLAMP WASHER
32	264018-7	NUT M8 RBC2510
33	6243008002	CUTTER SHAFT SET MS26C
B Pag.2
34	442177-9	GASKET
35	0140059500	SCREW M5X25
36	141056-5	INSULTATOR COMPLETE
37	6165500201	WIRE
38	442175-3	INSULTATOR GASKET
39	0119059730	SOCKET HEAD BOLT M5X20
40	5197500100	PLUG CAP
41	0650149661	SPARK PLUG X RBC350-RBC420-PB500R
42	318785-7	CYLINDER
43	5195501201	CYLINDER COVER X MS20C
44	6279505700	MAKITA LABEL
46	0655009870	PLUG CAP X MS254U-C
47	0654009931	PIN X RBC415-225-255
48	0851089950	TUBE X RBC2110
49	5197018000	WIRE COMP. RBC2110
50	911128-8	SCREW M4X16 X HR4000C
51	168683-3	IGNITION COIL FOR RBC2110
52	0119059520	SCREW M5 X 40 RBC201
53	5193001002	MUFFLER RBC201
54	5193001050	SPARK ARRESTER FOR RBC2110
55	168680-9	MUFFLER GASKET
56	442173-7	CYLINDER GASKET .RBC201
57	257320-5	PISTON RING
58	233976-8-4	CIRCLIP EBH252L (4pcs)
59	318831-6	PISTON RBC2110
60	268277-5	PIN
61	141047-6	CRANKSHAFT
62	266585-8	SCREW 5X12 EBH252L
63	325923-4	SWING ARM EBH252L
64	451938-6	FLANGE EBH252L
65	452972-9	STARTER REEL
66	234220-6	SPIRAL SPRING
67	911128-8	SCREW M4X16 X HR4000C
68	5225004020	STARTER KNOB HT2256D
69	6199520100	LABEL RBC2110
70	5255016020	ROPE RBC201
71	5195500000	ENGINE COVER RBC201
72	5191004001	HOUSING MOTOR CPL RBC2110
73	0440109980	RBC201 OIL SEAL
74	5191500400	GASKET RBC201
75	0600109980	BALL BEARING 6000
76	0140059500	SCREW M5X25 X RBC225-255
77	5197017010	FLYWHEEL X RBC2110
78	6192002003	CLUTCH RBC201
79	161477-5	CLUTCH DRUM
80	141058-1	CLUTCH HOUSING
81	0031510000	STOP X RBK 410
82	0119059880	BOLT X RBC 310
83	424461-4	DAMPER
84	318792-0	PIPE BRAKET
85	0566059980	BRACKET X RBC525
86	0150059780	SCREW M5X20 X MS20C
87	0119059850	SCREW M5 X 14 RBC201
88	168668-9	TANK CAP CPL RBC2510
89	452920-8	TANK CAP
90	140436-2	ROD EBH341U
91	452989-2	COMPLETE TANK
92	162329-3	TUBE
93	0561059990	HOSE CLAMP X RBC230-310 / 520
94	163447-0	FUEL FILTER X DCS230T
95	424102-2	DAMPER EBH341U
96	424103-0	DAMPER EBH341U
97	5193500101	PLATE RBC201
98	5216500200	RUBBER X RBC230-225-255
134	126037-0	STARTER ASSY X MS20C
C Pag.3
100	5196019240	ADJUSTMENT SCREW X MS20C
101	5196019310	SCREW X MS20C
102	5196019450	THROTTLE CABLE SCREW X MS20C
103	5196019460	WASHER X MS20C
104	452976-1	STARTER LEVER X MS20C
105	234221-4	SPRING STARTER
106	5196019250	SCREW X MS20C
107	5196019510	STOP RING X MS20C
108	5196019220	RING X MS20C
109	5196019150	RING X MS20C
110	5196032010	JET X MS20C
111	5196019410	RING X MS20C
112	5196019360	CONTROL VALVE X MS20C
113	5196019420	PLATE X MS20C
114	5196019430	SCREW X MS20C
115	126038-8	DIAPHRAGM
116	346513-0	DIAPHRAGM COVER
117	5196019060	SCREW X MS20C
118	442176-1	PUMP PACKING
119	424460-6	PUMP DIAPHRAGM
120	5196019350	PUMP BODY X MS20C
121	352018-0	REEL
123	452975-3	PUMP COVER
124	5246009030	VALVE X MS20C
125	424462-2	PRIMING PUMP X MS20C
126	5196019320	PRIMIMG PUMP PLATE X MS20C
127	5196019140	SCREW X MS20C
128	213632-6	RING 14
129	126036-2	FILTER PLATE
130	0043105600	SCREW M5X60 X RBC230 / RST250
131	443168-3	AIR FILTER X MS20C
132	452971-1	FILTER COVER X MS20C
133	911218-7	CYLINDER HEAD SCREW M5x14
Accessories Pag.4
501	122979-6	HEAD NYLON M8X1,25 100MM DIAM2,4MM
