Dolmar Spare Parts for Brusch Cutter MS4520C
€1.44
Tax included
Dolmar Spare Parts for Brusch Cutter MS4520C
We have the original Spares for Brusch Cutter MS4520C, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Brusch Cutter MS4520C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Brusch Cutter MS4520C
We have the original Spares for Brusch Cutter MS4520C, the diagram, parts list and tool repair that help you need to get your tools running like new again.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| MS4520C - DECESPUGLIATORE DOLMAR 45CC IS - ENGINE Pag.1 | ||
| # | Part Num. | Description |
| 1 | BB630070 | STARTER ROPE |
| 2 | BB510190 | ROPE PLATE |
| 3 | BB724740 | STARTER HANDLE WITH STOP ROPE PLATE |
| 4 | BB091640 | STOP ROPE |
| 5 | BB543600 | ENGINE GROMMET SUPPORT QUICK |
| 6 | BB724300 | CARTER STARTER COVER |
| 7 | BB180240 | STARTER SPRING |
| 8 | BB541320 | STARTER PULLEY |
| 9 | BB090720 | FLAT WASHER D.4, 3 X 16 |
| 10 | BB030800 | SCREW TCB M 4 X 10 |
| 11 | BB730050 | WHITE STARTER GROUP BBK570P02P4ER MACCH. DCAT23031_72 |
| 12 | BB030410 | SCREW TCEI M 5 X 18 |
| 13 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 14 | BB541340 | TANK GROMMET |
| 15 | BB060370 | NUT M 9 X 1.25 |
| 16 | BB730080 | REEL SUPPORT |
| 17 | BB541330 | STARTER POWL |
| 18 | BB180200 | POWL SPRING |
| 19 | BB120160 | LOCK RING D4 |
| 20 | BB722460 | POWL GROUP |
| 21 | BB240370 | SEAL RING 15X26X7 |
| 22 | BB721430 | ENGINE CARTER ASSEMBLED |
| 23 | BB240260 | CARTER GASKET |
| 24 | BB420200 | PIN D.8X10 |
| 25 | BB270070 | BEARING 6202 |
| 26 | BB751600 | CRANKSHAFT |
| 27 | BB090150 | GROWER WASHER 5.1 |
| 28 | BB030620 | SCREW TCEI M 5 X 35 |
| 29 | BB240030 | SEAL RING 15X26X7 |
| 30 | BB420030 | KEY 10X3,7X3 |
| 31 | BB270050 | NEEDLE BEARING PB K10X14X13FKI-V1 |
| 32 | BB150040 | LOCK RING D.10 |
| 33 | BB420040 | PISTON PIN D10X30 |
| 34 | BB480710 | PISTON DIAM. 41 FOR N45E |
| 35 | BB150240 | PISTON RING D.41 |
| 36 | BB721350 | COMPLETE PISTON D.41 |
| 37 | BB240270 | CYLINDER GASKET |
| 38 | BB090620 | SCHNORR WASHER D.6,4 |
| 39 | BB030630 | SCREW TCEI M 6 X 25 |
| 40 | BB752340 | DECOMPRESSOR X ENGINE N39 / 57E |
| 41 | BB480630 | CYLINDER DIAMETER 41 FOR N45E |
| 42 | BB240290 | INGAKE MANIFOLD GASKET |
| 43 | BB541270 | CARBURETTOR INGAKE MANIFOLD WT |
| 44 | BB090800 | SCHNORR WASHER D.5,3 |
| 44A | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 45 | BB030070 | SCREW TE M 5 X 30 |
| 46 | BB240130 | CARBURETOR GASKET |
| 47A | BB331650A | CARBURETOR FOR BBK4500 |
| 48 | BB726390 | COMPLETE AIR FILTER SUPPORT |
| 49 | BB091630 | SPACER |
| 52 | BB120270 | RING |
| 53 | BB031140 | SCREW M 3 X 8 |
| 54A | BB726390 | COMPLETE AIR FILTER SUPPORT |
| 55 | BB090830 | WAVE WASHER D. 5.3 |
| 56 | BB030500 | SCREW TCEI M 5 X 45 |
| 57 | BB332100 | AIR FILTER X CARBURETOR WALBRO |
| 57A | BB332250 | AIR FILTER DBC5700 |
| 58 | BB543180/R | RED FILTER COVER |
| 59 | BB543090/R | RED ENGINE CYLINDER COVER |
| 60 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 61 | BB030680 | SCREW TCEI M 5 X 14 |
| 62 | BB090780 | FLAT WASHER 5.3 X 10 X 1 |
| 63 | BB030620 | SCREW TCEI M 5 X 35 |
| 64 | BB451060 | SPARK PLUG RCJ4 |
| 65 | BB543200/R | SPARK PLUG RED COVER |
| 66 | BB240500 | MUFFLER GASKET |
| 67 | BB752350 | MUFFLER |
| 68 | BB090830 | WAVE WASHER D. 5.3 |
| 69 | BB030410 | SCREW TCEI M 5 X 18 |
| 70 | BB090830 | WAVE WASHER D. 5.3 |
| 71 | BB030680 | SCREW TCEI M 5 X 14 |
| 73 | BB031150 | SCREW M 5 X 20 |
| 74 | BB450930 | CAPACITIVE COIL FOR N39 / 57 |
| 75 | BB450340 | GROUND WIRE X COIL |
| 76 | BB541510 | GROUND WIRE GROMMET |
| 77 | BB450280 | FLYWHEEL FOR N39 / 57 |
| 78 | BB091000 | WAVE WASHER D.10.5 |
| 79 | BB060300 | NUT M 10 X 8 |
| 80 | BB780080 | CLUTCH ARM SUPPORT N31 / 52 |
| 81 | BB780020 | CLUTCH ARM N31 / 52 |
| 82 | BB180040 | EXTERNAL CLUTCH SPRING |
| 83 | BB180030 | INTERNAL CLUTCH SPRING |
| 84 | BB510200 | PERFORATED DISC |
| 85 | BB721390 | COMPLETE CLUTCH SINT. |
| 86 | BB090830 | WAVE WASHER D. 5.3 |
| 87 | BB030620 | SCREW TCEI M 5 X 35 |
| 88 | BB751300 | CLUTCH DRUM |
| 89 | BB120070 | SEEGER 32I UNI 7437 RING |
| 90 | BB270240 | BEARING 6201-ZZ |
| 91 | BB120020 | SEEGER 12E UNI 7435-75 RING |
| 92 | BB480980 | CLUTCH HOUSING |
| 99 | BB724100 | SUPPORT GROUP AND CLUTCH DRUM |
| 100 | BB726390 | COMPLETE AIR FILTER SUPPORT |
| 107 | BB030380 | SCREW TCEI M 5 X 16 |
| 108 | BB543220 | LOWER HALF |
| 109 | BB543210 | SUPERIOR HALF |
| 110 | BB481000 | LOWER SPACER |
| 111 | BB480990 | SUPERIOR SPACER |
| 112 | BB060100 | NUT M 5 X 4 |
| 113 | BB030410 | SCREW TCEI M 5 X 18 |
| 114 | BB724110 | FUEL TANK ASS'Y FOR ENGINE |
| 115 | BB542520 | RECOVERY TUBE |
| 116 | BB723740 | CPL. TANK CAP |
| 117 | BB542460 | FUEL TUBE |
| 118 | BB330820 | FUEL FILTER |
| MS4520C - DECESPUGLIATORE DOLMAR 45CC IS - HANDLEGRIP Pag.2 | ||
| 1 | BB543490 | NEW TYPE HANDLEBAR KNOB |
| 2 | BB511030 | SPACER X HANDLE SUPPORT M |
| 3 | BB750920 | BELT HOOK |
| 4 | BB030630 | SCREW TCEI M 6 X 25 |
| 5 | BB090040 | FLAT WASHER D.6,4 |
| 6 | BB542450 | CAP CROSS SUPPORT |
| 8 | BB542440 | CAP CROSS BODY |
| 9 | BB542430 | BODY CROSS SHELL |
| 10 | BB030810 | SCREW TCEI M 6 X 40 |
| 11 | BB722620 | CUP HOLDER NYLON HANDLEBAR SUPPORT |
| 12 | BB751640 | BUSH |
| 13 | BB391030 | RIGID SHAFT TRANSMISSION |
| 14 | BB540420 | DAMPER BUSH D.27 |
| 15 | BB750540 | COMPLETE RUBBER TUBE |
| 16 | BB540690 | SUPPORT CONTROL THROTTLE WIRE |
| 17 | BB570530 | RUBBER HOSE X FRONT GRIP |
| 18 | BB542420 | ADJUSTABLE ANTI-VIBRATING HANDLE |
| 19 | BB722830 | SHEATH GRIP |
| 20 | BB570670 | HANDLEBAR X EBC NBC |
| 21 | BB751620 | HARNESS WITH PROTECTION |
| 22 | BB751580 | SUSPENDER |
| MS4520C - DECESPUGLIATORE DOLMAR 45CC IS - GEARS CASE Pag.3 | ||
| 1 | BB090020 | BUSHING CASE |
| 2 | BB030800 | SCREW TCB M 4 X 10 |
| 3 | BB120020 | SEEGER 12E UNI 7435-75 RING |
| 4 | BB120010 | SEEGER 28I UNI 7437 RING |
| 5 | BB270010 | BEARING 6001-ZZ |
| 6 | BB723380 | GEAR KIT FOR GEAR CASE |
| 7 | BB060060 | NUT M 6 X 5 |
| 8 | BB090010 | GROWER WASHER D. 6.1 |
| 9 | BB480470 | GEAR CASE D.27 |
| 10 | BB030010 | SCREW TE M 6 X 30 |
| 11 | BB031080 | GREASE CAP SCREW |
| 12 | BB270020 | BEARING 6000 |
| 13 | BB390010 | GEAR CASE SPINDLE POST D.27 |
| 14 | BB420010 | LOCK PIN |
| 15 | BB270030 | BALL BEARING 6202-2RS |
| 16 | BB120030 | SEEGER 35I UNI 7437 RING |
| 17 | BB091560 | DISC FLANGE SUPPORT D.50 |
| 18 | BB510180 | UPPER FLANGE |
| 19 | BB090070 | DISC LOCKING FLANGE X D.27 |
| 20 | BB060470 | SELF-LOCKING NUT M 10 X 1 X 12 |
| 21 | BB722760 | GEAR CASE ASSY BBC4500 |
| 22 | P-47400 | 8 TEETH BLADE |
| 23 | P-47341 | BLADE 48 TEETH (255X1.4X25.4) MM |
| 24 | P-47391 | 4 TEETH BLADE (255X1.4X25.4) MM |
| 25 | BB120050 | SEEGER 15E UNI 7435-75 RING |
| 26 | BB480060 | BEARING SUPPORT |
| 27 | BB270060 | BEARING 6002-ZZ |
| 28 | BB060160 | NUT M10X1 |
| 30 | BB090010 | GROWER WASHER D. 6.1 |
| 31 | BB030050 | SCREW TE M 6 X 12 |
| 33 | BB060100 | NUT M 5 X 4 |
| 34 | BB542410 | SAFETY GUARD |
| 35 | BB511020 | LINE BLADE |
| 36 | BB030820 | SCREW 3,9 X 16 |
| 37 | BB729200 | COVER GUARD WITH BLADE |
| 38 | BB091360 | WASHER 5.5 X 15 X 1.6 |
| 39 | BB090150 | GROWER WASHER 5.1 |
| 40 | BB030830 | SCREW M 5 X 12 |
| 41 | P-47335 | SAFE GUARD D.27 |
| 42 | P-47282 | CUP |
| 43 | BB720330 | SERVICE KEYS KIT |
| MS4520C - DECESPUGLIATORE DOLMAR 45CC IS - ACCESSORIES Pag.4 | ||
| 1 | BB543260 | COVER SUP. FLASH LIGHT |
| 3 | BB180370 | SPRING FOR FLASH LIGHT HEAD |
| 4 | BB091350 | GUIDE BUSH X WIRE HEAD |
| 5 | BB543280 | BOBINA X FLASH LIGHT TEST |
| 6 | BB543270 | FLASH LIGHT STOP FLANGE |
| 7 | P-47313 | HEAD BATTI AND GO M10X1.0F |
| 8 | BB542180 | FLASH RAPID HOLDER COVER |
| 10 | BB180180 | SPRING X AUTOMATIC HEAD |
| 11 | BB091350 | GUIDE BUSH X WIRE HEAD |
| 12 | P-47254 | BOBINA PER TESTINA P-47422 |
| 13 | BB542190 | FLANGE OF STOP TEST.RAPID |
| 14 | P-47307 | MANUAL HEAD M10X1.0F |
| 15 | BB391510 | NUT X HEAD FLASH QUICK |
| 16 | BB543460 | TOP COVER TEST.QUICK |
| 17 | BB091350 | GUIDE BUSH X WIRE HEAD |
| 18 | BB724140 | BOBINA X FLASH QUICK |
| 19 | BB180110 | SPRING X FLASH HEAD AND QUICK |
| 20 | BB543430 | KNOB FOR "QUICK" HEAD |
| 21 | BB091600 | NUT INF.X HEAD FLASH QUICK |
| 22 | P-47416 | MANUAL HEAD M10X1.0F |
| 23 | BB390540 | NUT X FLASH HEAD |
| 24 | BB541110 | TOP COVER TEST.FLASH |
| 25 | BB091350 | GUIDE BUSH X WIRE HEAD |
| 26 | BB540340 | BOBINA X FLASH HEAD S / FILO |
| 27 | BB180110 | SPRING X FLASH HEAD AND QUICK |
| 28 | BB541100 | LOWER COVER TEST.FLASH |
| 29 | BB090590 | WASHER X M16 17X30X3 |
| 30 | BB480310 | POMOLO X HEAD SIN |
| 31 | P-47307 | MANUAL HEAD M10X1.0F |
| MS4520C - DECESPUGLIATORE DOLMAR 45CC IS - THROTTLE Pag.5 | ||
| 4 | BB751100 | GAS CABLE GROUP |
| 5 | BB721450 | KNOB CPL IMP.ANT. |
| 6 | BB722740 | CPL KNOB |
| MS4520C - DECESPUGLIATORE DOLMAR 45CC IS - CARBURATOR Pag.6 | ||
| 6 | BB96-166 | SCREW COVER PUMP WT |
| 7 | BB21-353 | PUMP COVER WT |
| 8 | BB96-647 | SCREW + SPRING X REGULATION MINIMUM |
| 9 | BB92-225 | MIXED PUMP GASKET |
| 10 | BB95-118 | POMPA MEMBRANE WT |
| 11 | BB88-131 | PLUG |
| 13 | BB96-142 | BUTTERFLY VALVE WT |
| 14 | BB52-548 | PIN WT101 |
| 15 | BB30-1140 | BUTTERFLY TREE |
| 16 | BB34-158 | THROTTLE |
| 17 | BB98-234 | SPRING WE RECALL THE VALVE |
| 18 | BB140-70 | FUEL INLET FILTER |
| 19 | BB16-71 | SAFETY RING |
| 20 | BB102-330 | SCREW MINIMUM ADJUSTMENT WT |
| 21 | BB98-404 | MINIMUM ADJUSTMENT SPRING |
| 22 | BB102-3066 | MAXIMUM ADJUSTMENT SCREW WT |
| 23 | BB98-405 | MAXIMUM ADJUSTMENT SPRING |
| 24 | BB140-69 | VALVE SCREEN WASHER |
| 25 | BB16-42 | STILL RING |
| 26 | BB88-119 | PLUG |
| 27 | BB88-171 | MINIMUM CIRCUIT CAP |
| 28 | BB96-156 | AXIS BILANCIERE SCREW |
| 29 | BB84-613 | VALVE SEAT |
| 30 | BB82-75 | PIN VALVE |
| 31 | BB98-387 | SPRING VALVE SPRING BALANCER |
| 32 | BB166-48 | ROCKER |
| 33 | BB144-77 | AXIS BILANCIERE |
| 34 | BB92-251 | DIAFR.WT MEMBRANE GASKET |
| 35 | BB95-526 | DIAPHRAGM MEMBRANE |
| 36 | BB5-2694 | AIR FILTER BODY |
| 37 | BB176-64 | CONTROL VALVE |
| 38 | BB188-12 | SEAL |
| 39 | BB21-404 | PRIMER PUMP COVER |
| 40 | BB090190 | GROWER WASHER D.3,1 |
| 41 | BB96-578 | MEMBRANE COVER SCREW |
| 42A | BB331650A | CARBURETOR FOR BBK4500 |
| 43 | BBD10-WAT | MEMBRANE KIT X WT 362,364,397 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
