Dolmar Spare Parts for Brusch Cutter MS245.4C
€22.41
Tax included
Dolmar Spare Parts for Brusch Cutter MS245.4C
We have the original DOLMAR Spare Parts for Brusch Cutter MS245.4C, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Brusch Cutter MS245.4C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Brusch Cutter MS245.4C
Fix Your Brusch Cutter MS245.4C. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Brush Cutter and the respective parts of the code.
| Brushcutter Dolmar MS245.4C - 24,5 cm³ 4T - pag.1 | ||
| # | Part Num. | Description |
| 1 | 195215-3 | HANDLEBAR GRIP FOR BBC |
| 2 | 451601-1 | SPACER EBH252L |
| 3 | 125759-9 | CONTROL LEVER EBH252L |
| 4 | 195143-2 | HOOK EBH252L |
| 5 | 911233-1 | HEAD SCREW M5X20 3600H |
| 6 | 140041-5 | AST EBH252L |
| 7 | 810517-3 | SAFETY LABEL MS245.4C |
| 8 | 806904-2 | SERIAL NUMBER LABEL |
| 9 | 324893-4 | TRANSMISSION SHAFT EBH252L |
| 10 | 922218-2 | SCREW M5X14 EBH341U |
| 11 | 123833-7 | GEAR CASE ASSY |
| 14 | 210049-4 | BALL BEARING 609ZZ EBH252L |
| 15 | 961005-4 | RING CHECK S9 |
| 16 | 962103-7 | R-24 GN900SE CHECK RING |
| 17 | 922241-7 | SCREW M5X25 |
| 18 | 265590-2 | SCREW M8X10 EBH341U |
| 19 | 211019-6 | BALL BEARING 626 EBH252L |
| 20 | 188866-9 | CUTTER SHAFT SET EBH252L |
| 23 | 210115-7 | BALL BEARING 6001LLU EBH252L |
| 24 | 961108-4 | RING CHECK S-28 |
| 25 | 331861-0 | RECIEVE WASHER EBH252L |
| 26 | 346355-2 | CLAMP WASHER |
| 27 | 168526-9 | EBH341U CUP |
| 28 | 264025-0 | NUT M10-17 EBH341U |
| 29 | 126216-0 | PROTECTOR |
| 30 | 451097-6 | PROTECTOR SUPPORT EBH252L |
| 31 | 922353-6 | SCREW M6 X30 X HM1202C |
| 32 | 346073-2 | PROTECTION FLANGE EBH252L |
| 33 | 266326-2 | SCREW 4X18 X MT601 |
| 186 | 347050-7 | BLADE |
| 187 | 135753-3 | LOWER PROTECTION |
| 196 | 266583-2 | SCREW M5X25 EBH252L |
| 197 | 264037-3 | NUT M5 EBH252L |
| Brushcutter Dolmar MS245.4C - 24,5cm³ 4T - pag.2 | ||
| 3 | 125759-9 | CONTROL LEVER EBH252L |
| 198 | 266584-0 | SCREW M4X20 EBH252L |
| 199 | 638704-0 | EBH252L SWITCH |
| 200 | 168579-8 | CABLE CONTROL EBH252L |
| 201 | 451933-6 | LEVER EBH252L |
| 202 | 233568-3 | SPRING TUBE EBH252L |
| 203 | 451934-4 | LEVER BLOCK EBH252L |
| 204 | 451936-0 | HOOD EBH252L |
| 205 | 264038-1 | NUT M5 EBH252L |
| 206 | 451935-2 | TUBE EBH252L |
| 207 | 922233-6 | HEX SOCKET HD BOLT M5X20 X DCS230T |
| Brushcutter Dolmar MS245.4C - 24,5cm³ 4T - pag.3 | ||
| 34 | 922226-3 | SCREW M 5 X 18 X 4341FCT |
| 35 | 922211-6 | SCREW 5 X 12 X AN250HC |
| 36 | 424191-7 | HALF CASE 1 EBH252L |
| 37 | 318270-0 | SPACER 1 EBH252L |
| 38 | 318271-8 | SPACER 2 EBH252L |
| 39 | 424107-2 | SEMIGUSCIO 2 EBH252L |
| 40 | 922222-1 | SCREW M5X16 |
| 41 | 318329-3 | CLUTCH CASE EBH252L |
| 42 | 450569-8 | SPACER EBH252L |
| 43 | 961052-5 | RETAINER RING S12 |
| 44 | 168475-0 | CLUTCH DRUM FOR EBH252L |
| 45 | 210111-5 | BEARING 6201LLU EBH252L |
| 46 | 962151-6 | R32 RING |
| 47 | 195144-0 | SUPPORT EBH341U |
| 48 | 911218-7 | SCREW M5x14 |
| 49 | 911213-7 | SCREW M5X12 X 5143R EBH252L |
| 50 | 451261-9 | CYLINDER COVER MS245.4C |
| 52 | 450568-0 | SPARK PLUG COVER EBH252L |
| 55 | 911128-8 | SCREW M4X16 X HR4000C |
| 56 | 266440-4 | SCREW M5X40 EBH341U |
| 57 | 265184-3 | SCREW M5X55 EBH341U |
| 58 | 345915-7 | EBH341U EXHAUST COVER |
| 59 | 168469-5 | MUFFLER EBH341U |
| 60 | 345916-5 | MUFFLER GASKET EBH341U |
| 61 | 140023-7 | VALVE COVER EBH252L |
| 62 | 162275-0 | COVER GASKET EBH252L |
| 63 | 922223-9 | SCREW M5X16 EBH341U EX2650LH |
| 64 | 168534-0 | SPARK PLUG NGKCMR4A EBH341U |
| 65 | 162274-2 | CAM GEAR COVER GASKET ER2650LH EBH341 |
| 66 | 318443-5 | SIDE COVER EBH341U |
| 67 | 266495-9 | SCREW M5X14 |
| 68 | 450565-6 | EBH341U OIL CAP |
| 69 | 424100-6 | GASKET OIL CAP EBH341U |
| 70 | 162276-8 | GASKET OIL CUP EBH252L |
| 71 | 318442-7 | OIL CUP EBH252L |
| 72 | 266495-9 | SCREW M5X14 |
| 73 | 325666-8 | FITTING EBH341U |
| 74 | 424202-8 | OIL TUBE EBH341U |
| 75 | 282020-8 | CLAMP EBH341U |
| 76 | 922111-0 | SCREW EXAG. INC. 4X10 |
| 77 | 318440-1 | EBH341U CHECK PLATE |
| 78 | 346083-9 | EBH341U PLATE |
| 79 | 135375-9 | CYLINDER CPL EBH252L |
| 80 | 424201-0 | CONTROL VALVE EBH341U |
| 81 | 266495-9 | SCREW M5X14 |
| 82 | 424200-2 | SPACER EBH341U |
| 83 | 125554-7 | BALANCER EBH341U |
| 84 | 325668-4 | SPRING BLOCK EBH252L VALVE |
| 85 | 234108-0 | COMPRESSION SPRING 9 EBH252L |
| 86 | 256200-2 | PIN 5 FOR 2704 |
| 87 | 326367-1 | SUCTION VALVE EBH252L |
| 88 | 326366-3 | EBH252L DISCHARGE VALVE |
| 89 | 125552-1 | CAM GEAR EBH341U |
| 90 | 268238-5 | PIN 5 EBH341U |
| 91 | 313169-4 | BALANCER CAM EBH341U |
| 92 | 268239-3 | PIN 4 EBH341U |
| 93 | 256865-0 | ROD 2,5 EBH252L |
| 94 | 195145-8 | ELASTIC RING EBH252L |
| 95 | 233976-8-4 | RING PIN (4pcs) EBH252L |
| 96 | 318441-9 | PISTON EBH252L |
| 97 | 257781-9 | PISTON PIN EBH252L |
| 98 | 213089-1 | SEAL 12 EBH252L |
| 99 | 267400-9 | WASHER 23 |
| 100 | 135374-1 | ECCENTRIC SHAFT EBH252L |
| 101 | 213769-9 | OIL SEAL 10 |
| 102 | 424105-6 | SPARK PLUG HOOD EBH252L |
| 103 | 324891-8 | SPARK PLUG SPRING EBH341 |
| 104 | 168816-0 | IGNITION COIL EBH341U |
| 105 | 922138-0 | SCREW M4X20 |
| 106 | 318343-9 | FLYWHEEL EBH252L |
| 107 | 267812-6 | WASHER 6 EBH252L |
| 108 | 161332-1 | CLUTCH GEAR X MH-246.4DF |
| 109 | 267817-6 | WASHER 8 EBH252L |
| 110 | 266457-7 | SCREW M6X25 EBH252L |
| 111 | 265577-4 | SCREW M6X16 EBH341U |
| 112 | 231858-8 | CLUTCH SPRING EBH252L |
| 113 | 125472-9 | CPL. TANK CAP |
| 114 | 140435-4 | EBH341U TANK CAP |
| 115 | 140436-2 | TANK CAP STRAP EBH341U |
| 116 | 810455-9 | EBH341U COLLAR PLATE |
| 117 | 424102-2 | DAMPER EBH341U |
| 118 | 424103-0 | DAMPER EBH341U |
| 119 | 424104-8 | DAMPER EBH341U |
| 120 | 450566-4 | FUEL TANK EBH252L |
| 121 | 163447-0 | FUEL FILTER X DCS230T |
| 122 | 345920-4 | CLAMP EBH341U |
| 123 | 168472-6 | FUEL TUBE EBH252L |
| 124 | 195146-6 | STARTING CPL EBH252L |
| 125 | 168483-1 | STARTER PULLEY EBH252L |
| 126 | 266585-8 | SCREW 5X12 EBH252L |
| 127 | 451938-6 | FLANGE EBH252L |
| 128 | 451937-8 | STARTER SPRING EBH252L |
| 129 | 232258-5 | SPRING SPRING EBH252L |
| 130 | 325923-4 | OSBILLATOR EBH252L |
| 131 | 424319-7 | STARTER KNOB EBH252L |
| 132 | 444019-3 | STARTER ROPE EBH252L |
| 133 | 808738-9 | LABEL MS245.4C |
| 183 | 806902-6 | ENGINE LABEL EBH252L |
| 184 | 345964-4 | TANK PROTECTION EBH252L |
| 185 | 806903-4 | LABEL |
| 189 | 911546-0 | CYLINDER HEAD SCREW M4x25 |
| 190 | 911213-7 | SCREW M5X12 X 5143R EBH252L |
| 191 | 331835-1 | SPACER EBH252L |
| 192 | 345963-6 | HOOK EBH341U |
| 193 | 638664-6 | CABLE EBH341U |
| 194 | 638665-4 | CABLE EBH341U |
| 195 | 324980-9 | ARRESTER EBH341U |
| Brushcutter Dolmar MS245.4C - 24,5cm³ 4T - pag.4 | ||
| 134 | 265188-5 | SCREW M5X68 EBH341U |
| 135 | 345919-9 | EBH341U FIXING PLATE |
| 136 | 423376-2 | GASKET EBH341U |
| 137 | 450560-6 | EBH341U AIR LEVER PLATE |
| 138 | 911218-7 | CYLINDER HEAD SCREW M5x14 |
| 139 | 450561-4 | AIR FILTER COVER EBH341U |
| 140 | 443141-3 | FILTER EBH341U |
| 141 | 443140-5 | PRE-FILTER EBH341U |
| 142 | 345918-1 | FASCETTA EBH341U |
| 143 | 422041-0 | BREATHER TUBE EBH252L |
| 144 | 422042-8 | TUBE EBH341U |
| 145 | 125468-0 | EBH341U FILTER PLATE |
| 146 | 451925-5 | CHOKE LEVER EBH341U |
| 147 | 213540-1 | RING 15 EBH341U |
| 148 | 424316-3 | EBH341U CHECK VALVE |
| 149 | 213539-6 | RING 14 EBH341U |
| 150 | 451924-7 | RETURN VALVE PLATE |
| 151 | 424315-5 | EBH341U CONTROL VALVE |
| 152 | 168577-2 | SEALER SEQUAR GASKET EBH341U |
| 153 | 168576-4 | SEPARATOR EBH341U |
| 154 | 413121-3 | CARBURETOR GASKET EBH252 |
| 155 | 922228-9 | SCREW M5X18 EBH341U |
| 156 | 450559-1 | EBH252L INSULATOR |
| 159 | 324961-3 | SUCTION TUBE EBH252L |
| 160 | 413120-5 | INSULATING GASKET EBH341U |
| 161 | 213078-6 | RING 10 EBH341U |
| 162 | 922213-2 | SCREW M5X12 EBH341U |
| 163 | 450562-2 | FASCETTA EBH341U |
| 165 | 168497-0 | CARBURATOR EBH252L |
| 166 | 140437-0 | PUMP BODY EBH341U |
| 167 | 352010-6 | FILTER EBH252L |
| 168 | 442154-1 | EBH341U DIAPHRAGM GASKET |
| 169 | 168574-8 | DIAPHRAGM CPL EBH341U |
| 170 | 140438-8 | BODY EBH341U |
| 171 | 424314-7 | EBH341 PRIMING PUMP |
| 172 | 346270-0 | EBH341U PUMP COVER |
| 173 | 266582-4 | SCREW 3X24 EBH341U |
| 174 | 168575-6 | EBH341U PUMP DIAPHRAGM |
| 175 | 442155-9 | PUMP GASKET EBH341U |
| 176 | 325924-2 | JET EBH252L |
| 177 | 213538-8 | RING 2 EBH341U |
| 178 | 234183-6 | SPRING 65-9 EBH341U |
| 179 | 266581-6 | SCREW M3X8 EBH341U |
| 180 | 325922-6 | CARBURETOR SCREW EBH341U |
| 181 | 413140-9 | WASHER EBH341U |
| 182 | 257964-1 | RETAINER RING E3 EBH341U |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
