DeWalt DCH213 Type 1 Rotary Hammer Spare Parts
€3.33
Tax included
DeWalt DCH213 Type 1 Rotary Hammer Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DCH213 Cordless Rotary Hammer Type 1.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DeWalt DCH213 Type 1 Rotary Hammer Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DCH213 Cordless Rotary Hammer Type 1.Open PDF Drawing in this page to check spare parts you need.
| DeWalt DCH213 Type 1 Rotary Hammer Spare Parts | ||
| # | Part Num. | Description |
| 101 | 323489-00 | CAP |
| 102 | 579212-00 | RING |
| 103 | N774198 | TUBE |
| 104 | 583890-00 | BALL 7.0 |
| 105 | 578387-00 | SDS BALL PLATE (WASHER SDS 1.4MM) |
| 106 | 871690 | SPRING BEVEL |
| 107 | 590306-00 | FELT SEAL |
| 110 | 574937-00 | COVER |
| 111 | 490785-00 | SLEEVE |
| 112 | 575023-00 | SELECTOR |
| 113 | 324006-16 | SCREW |
| 114 | 478843-00 | SPRING |
| 115 | 575026-00 | CAP |
| 116 | 575024-00 | BUTTON RELEASE |
| 120 | N123179 | CLAMSHELL PAIR |
| 121 | 330065-08 | SCREW M4x18 T20 |
| 122 | N072124 | LEVER |
| 123 | 575030-00 | SPRING |
| 124 | 575032-00 | PIN MM7,34 |
| 125 | 479313-00 | SPRING |
| 127 | N123191 | LED LIGHT |
| 128 | N160455 | SWITCH & PCB SA |
| 130 | N094649 | PLATE |
| 131 | N119679 | SPRING |
| 132 | N122099 | BLOCK |
| 160 | N112156 | HANDLE SIDE SA |
| 170 | 580787-00 | DEPTH STOP |
| 201 | 492807-00 | SPINDLE |
| 202 | 323711-02 | O-RING |
| 203 | 492808-00 | BEAT PIECE |
| 204 | 492809-00 | GUIDE BUSH |
| 205 | N451068 | RETAINER |
| 206 | 327087-00 | WASHER |
| 207 | 323762-07 | RING |
| 210 | 590302-00 | BEARING NEEDLE |
| 211 | 488105-00 | CLIP |
| 212 | 589350-00 | WASHER |
| 213 | 589346-00 | SPRING |
| 214 | 492817-00 | BUSH |
| 216 | 479478-00 | BEARING,BALL |
| 217 | 589348-00 | WASHER |
| 218 | 488390-00 | CLIP |
| 219 | 491536-00 | O-RING |
| 220 | 492820-00 | HOUSING PAIR |
| 221 | 478909-00 | SEAL - DISCONTINUED |
| 222 | N178363 | RAM SA |
| 223 | 577168-00 | RING O DYNAMIC 13X3 |
| 224 | 492822-00 | PISTON |
| 225 | N108992 | WASHER |
| 226 | 490286-00 | SPRING |
| 227 | 492823-00 | BALL SPINDLE |
| 228 | 492824-00 | CRANKSHAFT |
| 229 | N021608 | REPAIR KIT |
| 230 | N168103 | BEARING,BALL |
| 240 | N466046 | COMPRESSION SPRING |
| 241 | 492826-00 | COLLAR |
| 242 | 323763-10 | LOCKING RING |
| 243 | N450704 | GEAR SA |
| 244 | N621023 | BEARING |
| 246 | 575022-00 | PLATE, TRANSMISSION |
| 247 | 590312-00 | PIN |
| 250 | 492829-00 | MOTOR SA |
| 251 | 582865-00 | FELT FILTER |
| 252 | 323711-34 | O-RING |
| 253 | 478898-00 | LEVER SA |
| 254 | 577802-00 | WASHER SHIM |
| 255 | 490129-00 | SCREW |
| 260 | 493511-00 | BRUSHE PAIR (X 2) |
| 800 | 870889-03 | RENOLIT PARAGON EP GREASE ½ - 20 GRAMS |
| 800 | 870889-02 | RENOLIT PARAGON EP GREASE ½ - 90 GRAMS |
| 801 | 487130-04 | GREASE GLK FLUID 249 NLGI 000 (10G SERVICE) |
| 818 | 493152-03 | LABEL |
| 821 | N051446 | RATING PLATE |
| 836 | 596005-99 | S.T.CIRCLIP REMOVER |
| 836 | 596006-99 | S.T.CIRCLIP REMOVER |
| 836 | 596007-99 | S.T.CIRCLIP REMOVER |
| 846 | N455852 | SERVICE KIT |
| 861 | 576657-05 | KITBOX |
| 866 | N195933 | BATTERY 18V - 4.0AH - 72WH DCB182-XE DCH213M2 |
| 871 | N450536 | BATTERY CHARGER DCS565P2-QW / DCB115 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s DEWALT websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to DEWALT brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
