DeWalt D25831K-QS Type 1 Spare Parts
€152.38
Tax included
DeWalt D25831K-QS Type 1 Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DEWALT D25831K Type 1 Model: D25831K-QS Combination Hammer.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DeWalt D25831K-QS Type 1 Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DEWALT D25831K Type 1 Model: D25831K-QS Combination Hammer.
In the following table, look for the model of the hammer and the respective parts of the code.
| DeWalt D25831K Type 1 Chipping Hammer Spare Parts | ||
| ITEM CODE : D25831K | ||
| Model: D25831K-QS | ||
| Pos. | Codice | Descrizione |
| 1 | N046419 | ARMATURE 120V |
| 1 | N046420 | ARMATURE 230V |
| 2 | N046421 | FIELD 230V |
| 2 | N046422 | FIELD 120V |
| 3 | N082756 | HOUSING MOTOR |
| 4 | 330003-39 | BEARING |
| 5 | 327141-03 | SEAL |
| 6 | 577746-00 | RING |
| 9 | 330065-21 | SCREW |
| 11 | 1007970-00 | CONNECTOR |
| 12 | N020117 | CABLE |
| 20 | 330003-60 | BEARING |
| 20 | N110359 | BEARING 608 RS |
| 21 | 1007732-00 | SLEEVE |
| 22 | 1007798-00 | BRIDGE |
| 23 | N047304 | BRUSH HOLDER 115V |
| 23 | N047444 | SA BRUSH HOLDER 230V SENSOR |
| 24 | N047424 | BRUSH PAIR 230V |
| 24 | N047286 | BRUSH PAIR 120V |
| 25 | N047446 | SA BRUSH HOLDER 230V |
| 26 | N016920 | BAFFLE FAN |
| 27 | 330065-08 | SCREW M4x18 T20 |
| 28 | 1006592-01 | FAN SA |
| 29 | 324119-02 | SCREW |
| 40 | 1008683-00 | END CAP |
| 41 | 1006576-01 | MOTOR COVER |
| 42 | N041752 | GACC MODULE 230V |
| 42 | N041755 | GACC MODULE 115V |
| 49 | 1005672-00 | SCREW |
| 50 | 1007939-00 | COVER PLATE |
| 60 | 1007569-00 | SPRING |
| 61 | 1007567-00 | BUSH |
| 62 | 1007566-00 | STOP |
| 63 | 1007565-00 | BELLOW |
| 64 | 1008681-01 | HANDLE |
| 65 | 488065-01 | TRIGGER |
| 66 | 581070-01 | SWITCH |
| 67 | 1008682-00 | HANDLE COVER |
| 69 | N046423 | SET OF LEAD WIRES |
| 71 | 326619-00 | SCREW |
| 72 | 582319-41 | CORDSET (EURO) |
| 72 | 324438-90 | CORDSET |
| 80 | 1008678-00 | BELLOWS |
| 81 | N038214 | BUSH |
| 82 | N062047 | PIN |
| 83 | 324007-11 | TORX SCREW M5 X 18 |
| 85 | 821070 | CORD CLAMP |
| 86 | 323091-01 | CORD PROTECTOR |
| 88 | 1008391-00 | COVER |
| 90 | N021606 | LENS |
| 100 | 329816-00 | RUBBER LIP SEAL |
| 101 | 326575-01 | COLLAR |
| 102 | 479247-00 | SLEEVE S/A |
| 103 | 918825-02 | SCREW |
| 104 | 1006572-00 | COVER |
| 105 | 325878-00 | ROLLER |
| 106 | 325929-00 | HALF WASHER |
| 107 | 327208-00 | GUIDE |
| 108 | 323395-06 | SPRING |
| 109 | 487118-00 | SPRING |
| 110 | 325930-00 | SPRING GUIDE |
| 110 | N313860 | GUIDE |
| 119 | N038151 | FELT |
| 120 | N045793 | INSULITION SHEET |
| 122 | 1007828-00 | SEAL |
| 123 | N041835 | MOTOR HOUSING |
| 126 | 1005982-00 | WASHER |
| 127 | 496191-00 | DAMPER |
| 128 | N041834 | SPINDLE |
| 129 | N041847 | BEAT PIECE |
| 130 | N244259 | SEAL |
| 131 | 323711-10 | O-RING |
| 135 | N064329 | WASHER |
| 140 | 494857-00 | INSULATING SHEATH |
| 141 | 1006283-00 | GASKET |
| 142 | 1005748-00 | SPRING |
| 143 | N210233 | O-RING |
| 144 | 1006778-00 | INSULATING SHEATH |
| 145 | N041846 | CYLINDER |
| 146 | 577744-00 | O-RING |
| 147 | N041845 | RAM |
| 148 | 576232-01 | O-RING |
| 149 | N041844 | SLEEVE |
| 150 | 1005749-00 | SELECTOR FORK |
| 161 | 325905-00 | RETAINER |
| 162 | 330041-22 | PISTON PIN |
| 163 | N041843 | PISTON |
| 164 | 494724-00 | CON ROD |
| 165 | 1006721-00 | GEAR CASE COVER RH |
| 165 | N482797 | COVER RH |
| 166 | 1006786-00 | SELECTOR |
| 167 | 326467-00 | DETENT |
| 168 | 1006575-01 | COVER-TOP |
| 169 | 323711-57 | O-RING |
| 172 | 496856-00 | ECCENTRIC |
| 180 | 1006784-00 | SLIDER |
| 181 | 323395-32 | SPRING |
| 182 | 1006783-00 | CONNECTOR |
| 183 | 496857-00 | COVER |
| 184 | 323711-59 | O-RING |
| 185 | 1006785-00 | PLATE |
| 186 | N041841 | CRANKSHAFT |
| 187 | 323711-26 | O-RING |
| 188 | N082641 | HOUSING SA |
| 190 | 577745-01 | BEARING, BALL |
| 191 | 586301-00 | BEARING, NEEDLE |
| 192 | 323711-57 | O-RING |
| 193 | 1008427-00 | SCREW.SPECIAL |
| 201 | 1006720-00 | GEAR CASE COVER |
| 206 | 1006282-00 | GASKET |
| 220 | 487277-00 | HANDLE |
| 223 | 487291-00 | KNOB SA |
| 225 | 487343-00 | BOLT |
| 226 | 479319-00 | CLAMPING INSERT |
| 227 | 479317-00 | WASHER LOCK |
| 228 | N021994 | WASHER CLAMP |
| 229 | N021995 | CLAMP |
| 250 | N073104 | HANDLE SIDE SA |
| 800 | 870889-02 | GREASE, PARAGON EP ½ GREASE 90 GMS |
| 800 | 870889-03 | RENOLIT PARAGON EP ½ GREASE - 20 GRAMS |
| 810 | N040237 | TUBE OIL |
| 816 | N064908 | BRAND LABEL |
| 817 | 487395-01 | LABEL |
| 821 | N029861 | RATING PLATE |
| 821 | N029863 | RATING PLATE |
| 821 | N102212 | RATING LABEL |
| 821 | N486502 | RATING LABEL |
| 836 | 1003938-99 | S.T.SEAL FITTING TOOL |
| 837 | 559645-99 | S.T. FIXING TOOL |
| 847 | N080634 | SERVICE KIT 120V |
| 847 | N095947 | SERVICE KIT 120V |
| 847 | N081427 | SERVICE KIT 230V |
| 850 | N537841 | SERVICE KIT 230V |
| 847 | N095940 | INSERT |
| 856 | 351086-02 | BIT |
| 861 | 574931-23 | KITBOX |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s DEWALT websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to DEWALT brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
