DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DW821 Type 1 Angle Grinder Spare Parts.
In the following table, look for the model of the hammer and the respective parts of the code.![]()
| DEWALT DW821 ANGLE GRINDER TYPE 1 | ||
| # | Part NUm. | Description |
| 103 | 945614-00 | SWITCH - DISCONTINUED |
| 106 | 622613-02 | OUTER FLANGE |
| 107 | 391969-00 | INNER FLANGE |
| 110 | 944586-00 | GUARD |
| 111 | 393576-00 | RING |
| 112 | 562160-01 | SCREW |
| 113 | 945298-00 | GEARCASE COVER |
| 117 | 945295-01 | BEVEL GEAR & PINION ASSY TYPE 1 |
| 118 | 562097-01 | VITE |
| 119 | 562304-02 | GEARCASE ASSY |
| 121 | 573115-00 | SIDE HANDLE |
| 122 | 945299-00 | FLANGE |
| 123 | 945292-00 | NUT M7 0,80 |
| 124 | 944574-00 | BUTTON SW |
| 125 | 562210-00 | SPRING |
| 126 | 944571-00 | SPINDLE LOCK |
| 127 | 605040-22 | BEARING |
| 128 | 641823-00 | SLEEVE |
| 129 | 401635-00 | BAFFLE SA |
| 130 | 949638-01 | BUFFER |
| 132 | 606574-01 | BRUSH HOLDER |
| 133 | 562204-00 | BRUSH SPRING |
| 135 | 605040-02 | BEARING |
| 136 | 394938-01 | END CAP |
| 137 | 611540-00 | SUPPORT |
| 138 | 401253-00 | WRENCH |
| 139 | 562097-05 | SCREW |
| 140 | 401622-01 | FLANGE |
| 141 | 398906-00 | SPACER INSULATING |
| 145 | 562097-00 | SCREW |
| 160 | N110359 | BEARING 608 |
| 162 | 611737-01 | SWITCH LINK |
| 163 | 569624-01 | SWITCH LINK BUTTON |
| 164 | 562097-13 | SCREW |
| 800 | 286436-00 | GREASE |
| 816 | 569037-00 | RATING PLATE |
| 821 | 946194-00 | BRAND LABEL |
