Compa-OMS Spare Parts for Combined machines Mini-KOMPACTA 200/2
€1.38
Tax included
Spare Parts for Combined Machines Mini-KOMPACTA 200/2
COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Combined Surface Tickness Planer Mini-KOMPACTA 200/2.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Spare Parts for Combined Machines Mini-KOMPACTA 200/2
COMPA-OMS authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Combined Surface Tickness Planer Mini-KOMPACTA 200/2.In the following table, look for the model of the Combined Machine and their spare part.
| Surface Tickness Planer MINI KOMPACTA 200/2 | ||
| # | Part Num. | Description |
| 003 | KOMP.200/0003 | Protection planer Assembly |
| 1 | KOMP.200/001 | Rivet supply chain |
| 2 | KOMP.200/002 | Chain tensioner |
| 3 | KOMP.200/003 | Collar open 6 |
| 4 | KOMP.200/004 | Spring washer |
| 5 | KOMP.200/005 | Nut M5 |
| 6 | KOMP.200/006 | Plain washer 5 |
| 7 | KOMP.200/007 | Wheel adjustable chain |
| 8 | KOMP.200/008 | Chain 2 (P = 8) |
| 9 | KOMP.200/009 | Rivet for placement plane |
| 10 | KOMP.200/010 | Signal press feeding chips |
| 11 | KOMP.200/011 | Hex bolt M5x12 |
| 12 | KOMP.200/012 | Lead screw negative |
| 13 | KOMP.200/013 | Lead screw active |
| 14 | KOMP.200/014 | Stud Hexagon Socket |
| 15 | KOMP.200/015 | pin open 3x15 |
| 16 | KOMP.200/016 | Sleeve |
| 17 | KOMP.200/017 | Racket |
| 18 | KOMP.200/018 | Component welded workbench |
| 19 | KOMP.200/019 | Connecting block Crank |
| 20 | KOMP.200/020 | Guide plate |
| 21 | KOMP.200/021 | Hex bolt M6x15 |
| 22 | KOMP.200/022 | Fermo for crank |
| 23 | KOMP.200/023 | Bolt Crank |
| 24 | KOMP.200/024 | Locking crank |
| 25 | KOMP.200/025 | Hex bolt M8x20 |
| 26 | KOMP.200/026 | Flat washer 8 |
| 27 | KOMP.200/027 | Pan head screws slotted |
| 28 | KOMP.200/028 | Spring washer 4 |
| 29 | KOMP.200/029 | Pointer power pressing and |
| 30 | KOMP.200/030 | Rubber base |
| 31 | KOMP.200/031 | Nut M4 |
| 32 | KOMP.200/032 | Fastener for cables |
| 33 | KOMP.200/033 | Pan head screws with cutting |
| 34 | KOMP.200/034 | Coating plate base (B) |
| 35 | KOMP.200/035 | Component welded plate for station |
| 36 | KOMP.200/036 | Tapping screw ST4.2x10 |
| 37 | KOMP.200/037 | Signal scale up / down |
| 38 | KOMP.200/038 | Hex bolt M5x8 |
| 39 | KOMP.200/039 | Sheath anti-bending |
| 40 | KOMP.200/040 | Spacer fiss.carcassa |
| 42 | KOMP.200/042 | Tapping screw ST4.2x20 |
| 43 | KOMP.200/043 | Supply line (plug) |
| 44 | KOMP.200/044 | Bolt |
| 45 | KOMP.200/045 | Locking spring |
| 46 | KOMP.200/046 | Components for locking bolt |
| 47 | KOMP.200/047 | Screw cap M5 |
| 48 | KOMP.200/048 | 5 large flat washer |
| 49 | KOMP.200/049 | Knob bloc. planer protection K200 |
| 50 | KOMP.200/050 | Bushing reference plane |
| 51 | KOMP.200/051 | Bushing reference plane |
| 52 | KOMP.200/052 | Bearing K10x13x13 |
| 53 | KOMP.200/053 | Tension spring block (B) |
| 54 | KOMP.200/054 | Block |
| 55 | KOMP.200/055 | Tension spring block |
| 56 | KOMP.200/056 | Component roller |
| 57 | KOMP.200/057 | KNIVES FOR 200/2 |
| 58 | KOMP.200/058 | Spring for planer blade |
| 59 | KOMP.200/059 | Spring pin 3x8 |
| 60 | KOMP.200/060 | Locking plate planer blade |
| 61 | KOMP.200/061 | Bolt for planer blade |
| 62 | KOMP.200/062 | Planer Shaft mod. Komp.200/2 |
| 63 | KOMP.200/063 | Nut M6 |
| 64 | KOMP.200/064 | Fixed work bench |
| 65 | KOMP.200/065 | Flat washer 4 |
| 66 | KOMP.200/066 | Hex bolt M4x12 |
| 67 | KOMP.200/067 | Protractor (a) |
| 68 | KOMP.200/068 | Flat washer 6 |
| 69 | KOMP.200/069 | Spring washer 6 |
| 70 | KOMP.200/070 | Hex bolt M6x12 |
| 71 | KOMP.200/071 | Support protractor |
| 72 | KOMP.200/072 | Allen screw hexagonal reference |
| 73 | KOMP.200/073 | Hex bolt M6x25 |
| 74 | KOMP.200/074 | 6 large flat washer |
| 75 | KOMP.200/075 | Locking screw |
| 76 | KOMP.200/076 | Pointer corner |
| 77 | KOMP.200/077 | Spring pin 3x10 |
| 78 | KOMP.200/078 | Axis Locking |
| 79 | KOMP.200/079 | Angular |
| 80 | KOMP.200/080 | Hex bolt male M4x15 |
| 81 | KOMP.200/081 | Protractor (B) |
| 82 | KOMP.200/082 | Component welded plate ruler |
| 83 | KOMP.200/083 | Coupling for dust extraction hood |
| 84 | KOMP.200/084 | Knob (dust extraction hood) |
| 85 | KOMP.200/085 | Dust extraction hood |
| 86 | KOMP.200/086 | Collar open |
| 87 | KOMP.200/087 | Pointer for planing |
| 88 | KOMP.200/088 | Marking pointer |
| 89 | KOMP.200/089 | TC screws Phillips M5x12 |
| 90 | KOMP.200/090 | Knob |
| 91 | KOMP.200/091 | Adjustment bar |
| 92 | KOMP.200/092 | Lock nut |
| 93 | KOMP.200/093 | Lever |
| 94 | KOMP.200/094 | Iserto |
| 95 | KOMP.200/095 | Firm |
| 96 | KOMP.200/096 | Self-tapping screw |
| 97 | KOMP.200/097 | Clamping sleeve |
| 98 | KOMP.200/098 | Components shelter |
| 99 | KOMP.200/099 | Welded component support bridge |
| 100 | KOMP.200/100 | Knob lock d.20 M5x15 |
| 101 | KOMP.200/101 | Locking knob |
| 102 | KOMP.200/102 | Shield plate KOMP.200/189 |
| 103 | KOMP.200/103 | Screw shaper reference |
| 104 | KOMP.200/104 | Locking plate |
| 105 | KOMP.200/105 | Screw shaper reference |
| 106 | KOMP.200/106 | Screw reference |
| 107 | KOMP.200/107 | Block Plate |
| 108 | KOMP.200/108 | Rod suspension |
| 109 | KOMP.200/109 | Seal (brake) |
| 110 | KOMP.200/110 | Brake |
| 111 | KOMP.200/111 | Bearing cover |
| 112 | KOMP.200/112 | Ball bearing (6000-2Z) |
| 113 | KOMP.200/113 | Component welded to plate |
| 114 | KOMP.200/114 | Marking scale power |
| 115 | KOMP.200/115 | Locking spring "slightly open" |
| 116 | KOMP.200/116 | Hex bolt M4x15 |
| 117 | KOMP.200/117 | Split washer |
| 118 | KOMP.200/118 | Macro switch |
| 119 | KOMP.200/119 | Wheel belt shaft |
| 120 | KOMP.200/120 | Poly-V belt 5PJ605 K200 / K250 2/2 |
| 121 | KOMP.200/121 | Bush |
| 122 | KOMP.200/122 | Big wheel for chain |
| 123 | KOMP.200/123 | Allen screws with hexagon socket |
| 124 | KOMP.200/124 | Chain coupling (P = 12.7) |
| 125 | KOMP.200/125 | Pinion |
| 126 | KOMP.200/126 | AL wheel belt K200 / 250/2 |
| 127 | KOMP.200/127 | TC screws Phillips M5x20 |
| 128 | KOMP.200/128 | Collar axis 12 |
| 129 | KOMP.200/129 | Poly-V belt (3PJ605) K200 / K250 / 2 |
| 130 | KOMP.200/130 | Spacer for coverage |
| 131 | KOMP.200/131 | Housing |
| 132 | KOMP.200/132 | Marking Main |
| 133 | KOMP.200/133 | Collar axis 9 |
| 134 | KOMP.200/134 | Washer (junction plate) |
| 135 | KOMP.200/135 | Small wheel for chain |
| 136 | KOMP.200/136 | Bushing square section |
| 137 | KOMP.200/137 | Large gear |
| 138 | KOMP.200/138 | Rivet for junction plate |
| 139 | KOMP.200/139 | Spring tensioning device for plate |
| 140 | KOMP.200/140 | Collar axis 12 |
| 141 | KOMP.200/141 | Phillips screws M3x18 |
| 142 | KOMP.200/142 | Spring washer |
| 143 | KOMP.200/143 | Flat washer |
| 144 | KOMP.200/144 | Strain Relief |
| 145 | KOMP.200/145 | Link imterrutore |
| 146 | KOMP.200/146 | Drive pulley |
| 147 | KOMP.200/147 | Locking screw |
| 148 | KOMP.200/148 | Lock microswitch |
| 149 | KOMP.200/149 | Washer eccentric axis |
| 150 | KOMP.200/150 | Spring washer 8 |
| 151 | KOMP.200/151 | Allen screw M8x15 |
| 152 | KOMP.200/152 | Motor Mini-Kompacta 200/2 |
| 153 | KOMP.200/153 | Cover feet (A) |
| 154 | KOMP.200/154 | Garnizioni locking outer teeth |
| 155 | KOMP.200/155 | Fixing element M16 |
| 156 | KOMP.200/156 | Support box switches |
| 157 | KOMP.200/157 | TC screws Phillips M5x10 |
| 158 | KOMP.200/158 | Motor protection 7 |
| 159 | KOMP.200/159 | Cover box switches |
| 160 | KOMP.200/160 | Self-tapping screw 4,2x15 T |
| 161 | KOMP.200/161 | Low nut M12 |
| 162 | KOMP.200/162 | Main switch KJD12-16 |
| 163 | KOMP.200/163 | Eccentric axis |
| 164 | KOMP.200/164 | Workbench Mobile |
| 165 | KOMP.200/165 | Screw mounting housing brush |
| 166 | KOMP.200/166 | Gland (engine) |
| 167 | KOMP.200/167 | Protection strip |
| 169 | KOMP.200/169 | Carbon brushe Set x K200/2 |
| 181 | KOMP.200/181 | Washer handle MINI-KOMP.200/2 |
| 182 | KOMP.200/182 | Lever KP40 M5x20 KOMP.200/2 |
| 183 | KOMP.200/183 | Record knives K200 / 2 fig.H |
| 184 | KOMP.200/184 | Open key K200 / 2 fig.I |
| 185 | KOMP.200/185 | Push stick K200 / 2 fig.K |
| 186 | KOMP.200/186 | Key set complete K200/2 |
| 187 | KOMP.200/187 | Group bracket K200/2 |
| 188 | KOMP.200/188 | Knob lifting floor thickness. K200/2 |
| 189 | KOMP.200/189 | Set compl.protez.albero planer K200/2 |
| 190 | KOMP.200/190 | Set accessories K200/2 (183-189) |
| 120 | K2002.200.120 | Motor Belt (Poly-V 5P J788) |
| 129 | K2002.200.129 | Reduction belt 3PJ722 |
| 500 | Acc.n.33-1 | Kniver for Mini-Kompacta 200/2 |
