Compa-OMS Spare Parts for Combined machines KOMPACTA 250C

Compa-OMS Spare Parts for Surface Tickness Planer KOMPACTA 250C

Compa-OMS authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Combined Surface Tickness Planer KOMPACTA 250C.

In the following table, look for the model of the Portable Saws and their spare part.

	Mini-KOMPACTA 250C
#	Part Num.	Description
1	K250C.00.001	Upper carriage ANODIZED
2	K250C.00.002	Plane planer WORKED CAST
5	K250C.00.005	screw M8X20
6	K250C.00.006	washer 8
7	K250C.00.007	Flat washer 8
8	K250C.00.008	screw M8X20
9	K250C.00.009	washer 8
10	K250C.00.010	Flat washer 8
15	K250C.00.015	Emergency entrance thickness K250C
16	K250C.00.016	START button side mortiser K250c
17	K250C.00.017	STOP side mortiser K250C
18	K250C.00.018	Key set complete
19	K250C.00.019	Pack rings tree toupiŠ
20	K250C.00.020	Sets of rings toupiŠ per floor
1	K250C.01.001	Sliding Table Saw Stand PAINTED
3	K250C.01.003	Screw PHLP M10x70
4	K250C.01.004	Hexagonal nut M10
5	K250C.01.005	Flat washer 10
6	K250C.01.006	Sega D.250 z.40 F.30 + rid.20 Widia wood
7	K250C.01.007	Fulcrum block plug WORKED
8	K250C.01.008	screw M8x50
9	K250C.01.009	Hexagonal locking nut M8
10	K250C.01.010	Flat washer 8
11	K250C.01.011	Shirt toupie WORKED
12	K250C.01.012	screw M8x30
13	K250C.01.013	Flat washer 8
14	K250C.01.014	washer 8
15	K250C.01.015	Riga for planer WORKED
17	K250C.01.017	Flat washer 6
19	K250C.01.019	screw M10x65
20	K250C.01.020	Hexagonal nut M10
21	K250C.01.021	bolt M8x55
22	K250C.01.022	Hexagonal nut M10
23	K250C.01.023	Flat washer 8
24	K250C.01.024	Upper carriage ANODIZED
25	K250C.01.025	Profile feedback telescopic extension
28	K250C.01.028	screw M5X8
29	K250C.01.029	Plain washer 5
30	K250C.01.030	Carter upper crankcase
31	K250C.01.031	screw M5X8
32	K250C.01.032	screw M5x10
33	K250C.01.033	Plain washer 5
34	K250C.01.034	screw M6x45
35	K250C.01.035	Hex nut M6
36	K250C.01.036	Plastic cap x feet
37	K250C.01.037	Hexagonal nut M10
39	K250C.01.039	Hexagonal nut M16
40	K250C.01.040	Flat washer 16
41	K250C.01.041	Carter outer side moulder PAINTED
42	K250C.01.042	screw M5X8
43	K250C.01.043	Plain washer 5
44	K250C.01.044	Stop. General 0-1 x mod. 250C
45	K250C.01.045	selector mod.250C
46	K250C.01.046	Stop. 1-0-2 x mod. Kompacta 250 / C
47	K250C.01.047	Electric Box K250C
48	K250C.01.048	Sized panel saw
49	K250C.01.049	Inclined Ladder x Kompacta 250C
50	K250C.01.050	screw M5x6
51	K250C.01.051	Plain washer 5
52	K250C.01.052	Fusion Protector for Moulding
54	K250C.01.054	screw M4X8
55	K250C.01.055	Emergency button x Komp250C
56	K250C.01.056	screw M5X12
57	K250C.01.057	Plain washer 5
59	K250C.01.059	screw M4X35
62	K250C.01.062	screw M6x16
63	K250C.01.063	External pressure hor. headphone toupiŠ
64	K250C.01.064	Internal vertical pressure cuff toupiŠ
65	K250C.01.065	Clamp pressure cuff toupiŠ
66	K250C.01.066	Knob clamp pressure d.30
67	K250C.01.067	Control panel complete (44-45-46-47)
1	K250C.02.001	Support Flap WORKED
2	K250C.02.002	Screw M6x10 PHLP
3	K250C.02.003	driven pulley
4	K250C.02.004	Screw M8x30 PHLP
5	K250C.02.005	screw M5x10
7	K250C.02.007	Ring "C" 12
8	K250C.02.008	Pivot pin support engraver
10	K250C.02.010	screw M10x30
11	K250C.02.011	Washer lock disc engraver
15	K250C.02.015	spacer engraver
16	K250C.02.016	Cusc.d.17x35x10 6003-2RS1
17	K250C.02.017	Holder engraver WORKED
19	K250C.02.019	tree engraver
21	K250C.02.021	driven pulley
22	K250C.02.022	Flat washer 10
23	K250C.02.023	Left nut M10
24	K250C.02.024	Lever positioning riving knife
25	K250C.02.025	screw M6X20
26	K250C.02.026	nut M6
27	K250C.02.027	Flat washer 6
28	K250C.02.028	screw M6X30
29	K250C.02.029	Hex nut M6
30	K250C.02.030	Flat washer 6
32	K250C.02.032	Pivot pin sleeve tree saw
33	K250C.02.033	Turntable AS2542
34	K250C.02.034	Round nut M20x1.5
35	K250C.02.035	Hex bolt M10x25
36	K250C.02.036	washer 10
37	K250C.02.037	Rond.ferma saw GROUND
39	K250C.02.039	Washer f.sega internal WORKED
40	K250C.02.040	Spacer saw 2300/3000/3500
43	K250C.02.043	Holder riving knife
44	K250C.02.044	Spacer for dividing knife COMBI
45	K250C.02.045	Riving knife combined BRUNITO
46	K250C.02.046	Riving knife locking plate
47	K250C.02.047	Screw for splitting wedge K250C
48	K250C.02.048	Saw guard K250C
49	K250C.02.049	Mast saw WORKED
50	K250C.02.050	tree saw
51	K250C.02.051	Tongue tree saw
52	K250C.02.052	2Z bearing 6004 x 250 F / C mm20x42x12
53	K250C.02.053	Pulley shaft saw
54	K250C.02.054	Hexagonal locking nut M10
55	K250C.02.055	washer 10
42	K250C.02.42	washer
1	K250C.03.001	Handle Snap-KP55 M6x105 0155C105
2	K250C.03.002	washer 8
3	K250C.03.003	Flyer tilt the saw with a Wing
5	K250C.03.005	Flat washer 16
6	K250C.03.006	Flange knob tilt saw
8	K250C.03.008	screw M6X12
9	K250C.03.009	Fixing plate flange
11	K250C.03.011	screw M6X35
12	K250C.03.012	Sprocket Z.35 M2 WORKED
13	K250C.03.013	Clamp locking tilt saw
14	K250C.03.014	Hexagon lock nut M8
15	K250C.03.015	Index reading tilt saw
16	K250C.03.016	Spacer for index reading Saw
17	K250C.03.017	screw M6X30
18	K250C.03.018	Lunetta command tilt saw
19	K250C.03.019	screw M4x20
20	K250C.03.020	Hex Nut M4
21	K250C.03.021	Screw PHLP M6X25
22	K250C.03.022	Hex nut M6
23	K250C.03.023	Hex Bolt M6X20
24	K250C.03.024	screw M6X25
26	K250C.03.026	Left Auricle WORKED
27	K250C.03.027	Fulcrum block plug WORKED
28	K250C.03.028	Hex Bolt M6X12
29	K250C.03.029	Conveyor saw internal PAINTED
30	K250C.03.030	screw M6x10
31	K250C.03.031	Flat washer 6
32	K250C.03.032	screw M5X12
33	K250C.03.033	washer
34	K250C.03.034	Flyer lifting saw d.155
35	K250C.03.035	Turntable AS1226
36	K250C.03.036	Holder screw lifting blade
37	K250C.03.037	Galletto M6x70 K250C
38	K250C.03.038	Screw climb-down saw
40	K250C.03.040	Hexagon lock nut M8
41	K250C.03.041	Flat washer 12
42	K250C.03.042	Flat washer 8
43	K250C.03.043	Snail lifting saw
45	K250C.03.045	Screw PHLP M5X8
47	K250C.03.047	Screw PHLP M6X25
48	K250C.03.048	Hex nut M6
49	K250C.03.049	screw M6x45
50	K250C.03.050	Turntable AS1226
51	K250C.03.051	Screw M6x10 PHLP
52	K250C.03.052	Flat washer 20
53	K250C.03.053	Biella lifting saw
54	K250C.03.054	Hex bolt M10x40
55	K250C.03.055	Flat washer 10
56	K250C.03.056	Hexagonal nut M10
57	K250C.03.057	Biella tensioner
61	K250C.03.061	Bearing d.10x26x8 6000-2RS1
62	K250C.03.062	idler pulley
65	K250C.03.065	Hex bolt M10x40
66	K250C.03.066	Hexagonal nut M10
68	K250C.03.068	Hex bolt M10x40
69	K250C.03.069	Hexagonal nut M10
70	K250C.03.070	Flat washer 10
71	K250C.03.071	screw M10x80
73	K250C.03.073	Cusc. d.10x26x8 6000-2RS1
74	K250C.03.074	idler pulley
76	K250C.03.076	Hexagon lock nut
77	K250C.03.077	Flat belt 25x1,5x800 S1
79	K250C.03.079	Spring tensioner for engraver
80	K250C.03.080	Hex bolt M10x40
81	K250C.03.081	Hexagonal nut M10
89	K250C.03.089	Motor saw Komp.250C
105	K250C.03.105	Strap trap. 0-840 Kompacta 250 C
150	K250C.03.150	Group idler pulley
151	K250C.03.151	Group pulley (71-72-73-74-
3	K250C.04.003	Flyer incl. Saw d.125 K250C
8	K250C.04.008	gear K250C
15	K250C.04.015	Locking handle x Komp.250C
25	K250C.04.025	Bezel toothed inc.sega K250C
1	K250C.05.001	Moulding shirt for Kompacta 250 C
3	K250C.05.003	Spindle moulder x Komp.250C
5	K250C.05.005	Top cover x Komp.250C
6	K250C.05.006	Cusc. d.30x62x16 6206-2RS1 x Komp.250C
8	K250C.05.008	Cylinder moulder worked x Komp.250C
9	K250C.05.009	Cusc. d.25x52x15 6205-2RS1 x Komp.250C
10	K250C.05.010	Holder cylinder moulder x Komp.250C
14	K250C.05.014	Pulley spindle, x Komp.250C
19	K250C.05.019	Madrevite get up toupie x Komp.250C
20	K250C.05.020	Spacer x Komp.250C
23	K250C.05.023	Engine toupiŠ x Komp.250C
24	K250C.05.024	Motor pulley toupie x Komp.250C
30	K250C.05.030	Screw get up toupie x Komp.250C
31	K250C.05.031	Gear x Komp.250C
32	K250C.05.032	Spacer d.12,2x20x24,5 x Komp.250C
33	K250C.05.033	Axial ball d.12x26x9
37	K250C.05.037	Bushing x Komp.250C
41	K250C.05.041	Pin flyer toupie x Komp.250C
42	K250C.05.042	Inner flange flyer x Komp.250C
43	K250C.05.043	Outer flange flyer x Komp.250C
47	K250C.05.047	Flyer soll.spes.VSI432 d.120 f.12H7
50	K250C.05.050	Handle with snap threaded bushing
51	K250C.05.051	Strap trap. 0-620 x Komp.250C
60	K250C.05.060	Rings toupiŠ d.30 int. d.50 east. mm.5
61	K250C.05.061	Ring toupiŠ d.30 int. d.50 east. mm.10
62	K250C.05.062	Ring toupiŠ d.30 int. d.50 east. mm.16
63	K250C.05.063	Ring toupiŠ d.30 int. d.50 east. mm.20
64	K250C.05.064	Ring toupiŠ d.30 int. d.50 east. mm.30
14	K250C.06.014	Arm x Komp.250C
1	K250C.07.001	Insert line parallel cut K250C
22	K250C.07.022	Locking micrometer K250C
23	K250C.07.023	Knob line K250C
24	K250C.07.024	Square nut x line K250C
40	K250C.07.040	Lever R.55 M6x15
50	K250C.07.050	Group line saw complete
50	K250C.08.050	Group line to cart
51	K250C.09.051	Cylinder liner thickness x Komp.250C
52	K250C.09.052	Shelf spiral x Komp.250C
58	K250C.09.058	Soll.spes flyer. x Komp.250C
68	K250C.09.068	Screw lifting floor thickness x K250C
69	K250C.09.069	Tree for flyer thickness x Kom.250C
72	K250C.09.072	Threaded rod locking thickness
126	K250C.09.126	micro planer
572	K250C.09.572	Handle with snap threaded bushing
599	K250C.09.599	Motor planer unit KOMP.250C
22	K250C.10.022	Eccentric lever K250C
31	K250C.10.031	Knob soll.piano planer K250C
98	K250C.10.098	Protez.ponte complete albe.pialla K250C
521	K250C.10.521	nut
522	K250C.10.522	washer
523	K250C.10.523	Holder closure plans K250C
41	K250C.11.041	Gib lock knives K250C
43	K250C.11.043	Peg registration knives K250C
81	K250C.11.081	Toothed drive roller
529	K250C.11.529	Screw T.E. M6x15 burnished K250C
569	K250C.11.569	Chain-sprocket roller towing 05B1
570	K250C.11.570	Chain wheel clutch 05B-1 38 m.c.g.s.
586	K250C.11.586	Strap trap. 0-1092 Kompacta 250 / C
901	K250C.12.901	Column for pressure K250C
929	K250C.12.929	Lever locking soll. mortiser
940	K250C.12.940	Flyer lifting mortiser K250C
956	K250C.12.956	Head hub d.14-M14 K250C
957	K250C.12.957	Nut M14 medium UNI5588
959	K250C.12.959	Lever movement mortiser
960	K250C.12.960	Lever grip mov.cavatrice
970	K250C.12.970	Spindle WESCOTT mortiser 250C
971	K250C.12.971	Protection chuck Wescott K250C
972	K250C.12.972	Pressure unit complete mortiser 250C
980	K250C.12.980	Complete group mortiser
10	K250C/03C/105	Belt for saw Kompacta 250C
