Compa-OMS Spare Parts for Portable Saw 2300 XL MAXIMA
€3.48
Tax included
Compa-OMS Spare Parts for Portable Saw 2300 XL MAXIMA
Compa-OMS Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Professional Portable Saw 2300 XL MAXIMA.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Portable Saw 2300 XL MAXIMA
Compa-OMS Original spare parts at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Professional Portable Saw 2300 XL MAXIMA.In the following table, look for the model of the Portable Saw and their spare part.
| Mitre saw Compa 2300XL MAXIMA | |
| Part Num. | Description |
| 0118 | Washer Brass d.24x10,5x2 |
| 0132/01 | Flat 13,5x5 stop bracket |
| 0134 | Ades.cuffie / occh. / Gloves unific.PVC |
| 0163 | Knob d.20 M6x10 (01TBP20C10) |
| 0184 | THP knob d.20 M6x15 nylon tip |
| 0188 | TBP knob d.20 M6x15 iron |
| 0207QUALITY | Bearing 6201 ZZ (ERI) mm.12x32x10 |
| 0208QUALITY | 6203 ZZ bearing mm.17x40x12 |
| 0214 | rubber grommet |
| 0216MONO | VVF cable 3x1 + mt.2 sp.SHUKO FR. |
| 0222 | thrust 51100 |
| 0228 | Allen stops saw HEX SOCKET HEAD M10x25 SX Zn |
| 0283 | disc brake pads |
| 0284 | Spring 'CO.MEC 720 P.32'x brake |
| 0292/2300 | Capacitor 25mF. V.400 2 cav.mm.250 |
| 0293 | d.30 knob M10x60 conical tip |
| 0321/01 | Line graph to rivet |
| 0345 | lower guard upstairs NEW |
| 0357 | graduated increase shelf auction |
| 0360/01LAV | Shelf assembled extruded aluminum |
| 0395LAV | top team worked |
| 0623 | Auction 335 millimeter aluminum adessive case x3000 3500 2300XL |
| 0636 | adhesive aluminum arrow |
| 0911LAVORATO | motor cover 250 WORKED |
| 0912 | Polycarbonate screw cover small motor 250/300/2300 |
| 0913 | small motor fan 250/300/2300 |
| 13030600 | Bearing (d.8x22x7) 608-2RS1 |
| 20010160 | Wing Bolt d.30 TNP32 M6x100 |
| 20050011 | Support vise x 2300/250 FCT WORKED |
| 23010012LAV | Base x mod.2300 (vers.reggispinta) |
| 23010020LAV | ruot.LAVORATA table |
| 23010080 | fifth wheel |
| 23010110 | Washer dished x bas.to 2300 |
| 23010120 | rubber foot univ.x 2300 / 1-3000 / 1-3500 |
| 23010140 | lever positioning ring |
| 23010160 | lever return spring |
| 23010170 | Lever positioning table |
| 23010180 | Galletto NPT d.40 M8x210 |
| 23010220 | Snap handle KP79 M10 (0179E) |
| 23010320 | Index graduated sector 2300/3000/3500 |
| 23010330 | Spacer for auction blocc.tavola 2300 |
| 23010390 | A leaf spring X 2300/1 |
| 23010400 | Bush to get up lever cover 2300 |
| 23010420 | Bezel mounting brackets |
| 23010450 | Side support x base 2300 XL |
| 2301057/80LAV | Caliper bracket x mont.SX x 300JET / 2300 |
| 23020010LAV | Arm WORKED x mod.2300 / 5300 |
| 23020012LAV | Arm worked vers. "MAXIMA |
| 23020020 | Arm Cover x 2300 |
| 23020040 | Spacer sleeve 2300/3000/3500 |
| 23020050 | Grip x line 2300 |
| 23020060 | Trigger Grip line x 2300 |
| 23020070 | Tear-proof cable clamp x impugn.tipo 2300 |
| 23020180 | Guy M5x180 Zn |
| 23020200 | Jack fulcrum arm |
| 23020250 | Arm spring rod tube |
| 23020350 | Buffer column |
| 23020440 | Switch SCHURTER ABCW F00-U3-AZM02 X2300 / 250 |
| 23020610 | plast protection. motor 90x120 |
| 23020620 | Rosetta spingimolla |
| 23020630 | Jack spring adjustment |
| 23020640 | Spring holder rod |
| 23020651 | Arm spring 2300 L.130 |
| 23020660 | Arm spring spacer 2300 |
| 23020691 | Flat reinforces spring 2300 NEW |
| 23020695 | Spacer reinforcement spring 2300 |
| 23020720 | Spacer bushing spring shelter |
| 23020801LAV | Carter engine support 2300 MAX.LAVORATO |
| 23020843 | drive pulley x MAXIMA (new ver.) |
| 23020854 | driven pulley x MAXIMA (new ver.) |
| 23020861 | Driven shaft MAXIMA |
| 23020870 | Washer stops pulley MAXIMA |
| 23020880 | Locking Washer Saw WORKED |
| 23020890 | Washer stops Saw |
| 23020900 LAV | Sliding Blade Guard |
| 23020901 | extension spring nr.9 |
| 23020910 | for internal protection ring |
| 23020920 | conveyor maxima |
| 23020930 | Get up lever guard maxima |
| 23020960 | compensator AN32x10 MAXIMA ring |
| 23021030 | spacer |
| 23021071 | Sheet interposed maxima |
| 23021081 | BELT, MAXIMA line - HP255 5MHP15 |
| 23030030COM | Prot.sega plan sup.completa with springs |
| 23030050 | riving knife |
| 23030260 | gearbox |
| 23030270 | Lid box |
| 23030280 | Rack |
| 23030290 | cogwheel |
| 23030311 | Adjusting knob 01THP50 with pin |
| 23030330 | Stud master plan |
| KIT23020810 | Crankshaft + rotor x mod.MAXIMA |
| KIT2302094/4 | graduated scale + arm support 2300 MAXIMA Assembled |
| KITASTEARREST | Rods Assy stopping upright (139 + 115 + 112 + 113x2) |
| KITLEVE2300 | Linkage mounted x-release 2300/3000/1 |
| KITMOT2300MON | Engine 2300 mono (Paccco St. + Lawyer. + Car) |
