Compa-OMS Spare Parts for Band Saw SC1325
€75.97
Tax included
Compa-OMS Spare Parts for Band Saw SC1325
Original spare parts for Compa-OMS for Portable Band Saw SC 1325Base in die-cast aluminum
Tilting vise with quick approach and fine
Quick adjustment cutting speed on the switch
Rubber feet
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Band Saw SC1325
Original spare parts for Compa-OMS for Portable Band Saw SC 1325In the following table, look for the model of the Band Saw and their spare part.
| BAND SAW SC 1325 | ||
| # | Part Num. | Description |
| 1 | SC 1325/001 | Frame X SC 1325 |
| 2 | SC 1325/002 | Nut M6 X SC 1325 |
| 3 | SC 1325/003 | Spring Washer M6 X SC 1325 |
| 4 | SC 1325/004 | Guide Bracket X SC 1325 |
| 5 | SC 1325/005 | Washer X SC 1325 |
| 6 | SC 1325/006 | Bearing X SC 1325 607-2RS |
| 7 | SC 1325/007 | Eccentric Shaft X SC 1325 |
| 8 | SC 1325/008 | Knob X SC 1325 |
| 9 | SC 1325/009 | Adjustable Bracket (Front) X SC 1325 |
| 10 | SC 1325/010 | Bearing X SC 1325 624-2RS |
| 11 | SC 1325/011 | Pin X SC 1325 D.4x19.8L |
| 12 | SC 1325/012 | Washer X SC 1325 |
| 13 | SC 1325/013 | Blade Guard (Front) X SC 1325 |
| 14 | SC 1325/014 | Screw Hex Socket Head |
| 15 | SC 1325/015 | Screw Cart X SC 1325 M6x30L |
| 17 | SC 1325/017 | Screw Flat Head Phillips |
| 18 | SC 1325/018 | SC Bracket X 1325 |
| 19 | SC 1325/019 | Washer M6 X SC 1325 |
| 20 | SC 1325/020 | Washer M8 X SC 1325 |
| 21-1 | SC 1325/021 | Knob X SC 1325 |
| 22 | SC 1325/022 | Handle With Switch And Cable |
| 22-1 | SC 1325/022-1 | Switch X SC 1325 Kedu HY37 |
| 24 | SC 1325/024 | Lama X SC 1325 1325x13x0.65-8 / 12T |
| 25 | SC 1325/025 | Bolt Fixed X SC 1325 |
| 26-1 | SC 1325/026 | Driving Wheel X SC 1325 |
| 27 | SC 1325/027 | Washer X SC 1325 |
| 27-1 | SC 1325/027-1 | Washer SC X 1325 21.8 * 15.2-1 |
| 28 | SC 1325/028 | Screw T.E. X SC 1325 M5x10L |
| 29 | SC 1325/029 | Rear Blade Guard X SC 1325 |
| 32 | SC 1325/032 | Bracket Tension X SC 1325 |
| 33 | SC 1325/033 | Pressure Plate X SC 1325 |
| 34 | SC 1325/034 | Screw Flat Head Phillips |
| 35 | SC 1325/035 | Spring 1325 X SC |
| 36 | SC 1325/036 | Spring X SC 036 |
| 37 | SC 1325/037 | Bolt X SC 1325 |
| 42 | SC 1325/042 | Tree X SC 1325 |
| 45 | SC 1325/045 | Cable X SC 1325 |
| 46-1 | SC 1325/046-1 | Couple Brushes SC 1325 X 2 Speed ... |
| 46-3 | SC 1325/046-3 | Screw Round Head Slotted |
| 46-4 | SC 1325/046-4 | Crankcase SC 1325 X 2 Speed ... |
| 46-7 | SC 1325/046-7 | Separator SC 1325 X 2 Speed ... |
| 46-8 | SC 1325/046-8 | Fan Speed 2 X SC 1325 ... |
| 46-9 | SC 1325/046-9 | Bracket X 2 SC 1325 Speed ... |
| 46-S1 | SC 1325/046S1 | Engine Speed 2 X SC 1325 ... |
| 57 | SC 1325/057 | Allen Screw With Hexagon Socket |
| 58 | SC 1325/058 | Bearing X SC 1325 HK0609 |
| 59 | SC 1325/059 | Washer X SC 1325 |
| 60 | SC 1325/060 | Gear X SC 1325 |
| 61 | SC 1325/061 | Bushing X SC 1325 |
| 62 | SC 1325/062 | Gear B X SC 1325 |
| 63 | SC 1325/063 | Washer X SC 1325 |
| 64 | SC 1325/064 | Bearing X SC 1325 HK0810 |
| 66 | SC 1325/066 | Bearing X SC 1325 627-2RS |
| 67 | SC 1325/067 | Gear C X SC 1325 |
| 68 | SC 1325/068 | Bearing X SC 1325 6202LLU |
| 92 | SC 1325/092 | Spring Washer M8 X SC 1325 |
| 93 | SC 1325/093 | Allen Screw With Hexagon Socket |
| 94 | SC 1325/094 | Pideino Rubber |
| 95 | SC 1325/095 | Washer SC 1325 X D.20 * D.10.3-2t |
| 96 | SC 1325/096 | Nut M10 X SC 1325 |
| 97 | SC 1325/097 | Screw Cart X SC 1325 M10x33L |
| 98 | SC 1325/098 | Hex Nut X SC 1325 M14xp1.5 |
| 99 | SC 1325/099 | Auction Set Distance X SC 1325 |
| 100 | SC 1325/100 | Bracket Set Distance X SC 1325 |
| 100-1 | SC 1325/100-1 | Handle X SC 1325 |
| 100-2 | SC 1325/100-2 | Screw T.E. X SC 1325 M6x30L |
| 101 | SC 1325/101 | Washer X SC 1325 |
| 102 | SC 1325/102 | Screw Round Head Slotted |
| 104 | SC 1325/104 | Indicator Degrees X SC 1325 |
| 105 | SC 1325/105 | Rivet X SC 1325 D.3.3X6L |
| 107 | SC 1325/107 | Allen Screw With Hexagon Socket |
| 108 | SC 1325/108 | Hex Nut M6 X SC 1325 |
| 109 | SC 1325/109 | Screw Hex Socket Head |
| 110 | SC 1325/110 | Knob X SC 1325 |
| 111 | SC 1325/111 | Washer X SC 1325 M10x27x3t |
| 112 | SC 1325/112 | Knob With Tree X SC 1325 |
| 114 | SC 1325/114 | Positioning Pin X SC 1325 |
| 115 | SC 1325/115 | Locking Ring E X SC 1325 E7 |
| 116 | SC 1325/116 | Spring 1325 X SC |
| 117 | SC 1325/117 | Washer X SC 1325 |
| 118 | SC 1325/118 | Bushing X SC 1325 |
| 119 | SC 1325/119 | Swivel Arm X SC 1325 |
| 120 | SC 1325/120 | Washer X SC 1325 M10 |
| 121 | SC 1325/121 | Nut M10 X SC 1325 |
| 122 | SC 1325/122 | Power Cable X SC 1325 |
| 123 | SC 1325/123 | Adjusting Nut Cable X SC 1325 |
| 124 | SC 1325/124 | Screw Round Head Slotted |
| 126-1 | SC 1325/126-1 | Cover X 2 SC 1325 Speed ... |
| 126-2 | SC 1325/126-2 | Cover X 2 SC 1325 Speed ... |
| 126-3 | SC 1325/126-3 | Screw Round Head Slotted |
| 126S1 | SC 1325/126S1 | Group Switch SC 1325 X 2 Speed ... |
| 126S2 | SC 1325/126S2 | Group Switch X SC 1325 Variator |
| 131 | SC 1325/131 | Nut M10 X SC 1325 |
| 134 | SC 1325/134 | Gland X SC 1325 |
| 135 | SC 1325/135 | Hexagon Nut M8 X Sc 1325 |
| 136 | SC 1325/136 | Locking Clamp X SC 1325 |
| 137 | SC 1325/137 | Washer X SC 1325 |
| 138 | SC 1325/138 | Bearing X SC 1325 6002-2RS |
| 139 | SC 1325/139 | Allen Screw Flat Head Hex |
| 140 | SC 1325/140 | Idler X SC 1325 |
| 141 | SC 1325/141 | Swivel Base X SC 1325 |
| 142S | SC 1325/142S | Complete Vise X SC 1325 |
| 160 | SC 1325/160 | Star Washer X SC 1325 M5 |
| 161 | SC 1325/161 | Screw Round Head Slotted |
| 46-1 | SC 1325/46-1 | Couple Brushes X 1325 V |
| 46-2S | SC 1325/46-2S | Rotor Complete SC 1325/2 |
| 46-3 | SC 1325/46-3 | Screw Round Head Slotted |
| 46-4 | SC 1325/46-4 | Motor Housing Complete SC 1325 V |
| 46-5 | SC 1325/46-5 | Screw Round Head Slotted |
| 46-6S | SC 1325/46-6S | Electronic Card 1325 / VAR SC 1440 |
| 46-7 | SC 1325/46-7 | Separator SC 1325 V |
| 46-8 | SC 1325/46-8 | Fan X SC 1325 V |
| 46-9 | SC 1325/46-9 | Winding SC 1325/2 |
| 462S | SC 1325/462S | Group Motorotore-Tree Motorotore- |
| 46S1 | SC 1325/46S1 | Complete Engine X SC 1325 |
| 46S2 | SC 1325/46S2 | Engine X SC 1325 V |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Compa-OMS websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Compa-OMS brand review. Please refine the important parameters by the selling assistant when making a purchase.All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
