CM Motori Spare Parts for Diesel Engines LA170
CM Motori genuine parts for replacement or repair Diesel Engines LA170, for Engine pumps, rotary tiller, tillers.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
CM Motori Spare Parts for Diesel Engines LA170
CM Motori genuine parts for replacement or repair Diesel Engines LA170, for Engine pumps, rotary tiller, tillers.
In the following table, look for the model of the Motor Pump and the respective parts of the code.
Items will be shipped within 7/10 working days approx.
| DIESEL ENGINE PARTS 170 | ||
| 1 | 7001017 | PLUG OIL DRAIN |
| 2 | 7001100 | OR OIL CAP |
| 3 | 9701301 | RING SEAL OIL |
| 4 | 7001001 | BLOCK CYLINDER CARTER |
| 5 | 7011200 | FUEL VALVE |
| 6 | 9702024 | OR |
| 7 | 7001002 | PLUG THE OIL |
| 8 | 9802008 | ROLLER BEARING |
| 9 | 7001012 | SHORT STUD |
| 10 | 7001011 | LONG STUD |
| 13 | 7012002 | PLATE |
| 14-108-136 | 9901061 | NUT M6 |
| 15 | 7001009 | PLATE HOLDER |
| 16 | 9903080 | FLAT WASHER |
| 17 | 9902081 | BOLT |
| 18 | 9802015 | ROLLER BEARING |
| 19 | 7001003 | HEAD STUD SHORT |
| 20 | 7001007 | WASHER STUD |
| 21 | 7001005 | NUT HEAD STUD |
| 23 | 7001006 | NUT UP HEAD STUD |
| 24 | 7001004 | HEAD STUD LONG |
| 27 | 9801205 | BEARING |
| 28 | 7001014 | BEARING SHAFT |
| 29 | 9905081 | PLUG 8X12 |
| 30 | 7001016 | COVER CARTER |
| 31 | 9701025 | RING SEAL OIL |
| 32 | 9902083 | PLUG OIL DRAIN |
| 33 | 7001019 | PIN |
| 34-51 | 7001021 | PIN |
| 35 | 9902072 | BOLT 6X28 |
| 36-84 | 9902064 | BOLT 6X14 |
| 37 | 7001018 | AIR DEFLECTOR |
| 38 | 7002200 | HEAD |
| 40 | 7002203 | VALVE INTAKE |
| 41 | 7002004 | EXHAUST VALVE |
| 44 | 7007401 | AIR CONNECTION |
| 7007402 | OIL FILTER CONNECTION | |
| 45 | 7003202 | LIFTER VALVE |
| 46 | 7003201 | BALL |
| 47 | 7003001 | HEAD COVER |
| 48 | 9702012 | OR |
| 50 | 7003005 | PIN DECOMPRESSOR |
| 52 | 7003004 | SPRING DECOMPRESSOR |
| 53 | 7003100 | POST DECOMPRESSOR |
| 54 | 9702010 | OR |
| 55 | 9905316 | PIN |
| 56 | 9902074 | BOLT HEAD COVER |
| 57 | 9904051 | KEY 5X7 |
| 58 | 7005006 | GEAR COUNTERSHAFT |
| 59 | 7005004 | GEAR SPEED REGULATOR |
| 60 | 7005201 | SHAFT |
| 61 | 7005202 | SPINA |
| 62 | 9904052 | KEY 5XI2 |
| 63-80 | 9904053 | KEY 5X14 |
| 64 | 7016200 | FLYWHEEL |
| 65 | 9801306 | BEARING BANK |
| 66 | 7005001 | STARTING PULLEY |
| 67 | 7005002 | NUT FLY |
| 68 | 7005003 | WASHER NUT FLY |
| 69 | 7004100 | OIL SCRAPER RING |
| 70 | 7004101 | RING COMPRESSION |
| 71 | 7004102 | RING COMPRESSION |
| 72 | 7004103 | PISTON |
| 7004105 | PISTON AND RINGS INCREASED MM 00:25 | |
| 73 | 7004104 | PIN |
| 74 | 9906019 | PIN LOCKING RING |
| 75 | 7004200 | ROD COMPLETE |
| 76 | 7005007 | COUNTERSHAFT |
| 77 | 7006001 | SHAFT CAMMES |
| 78 | 7006003 | TAPPET |
| 79 | 7006100 | AUCTIONS ROCKER |
| 81 | 7006002 | GEAR SHAFT CAMMES |
| 82 | 7009200 | OIL FILTER |
| 83 | 9702025 | OR |
| 87 | 7009004 | GEAR OIL PUMP |
| 88 | 7009100 | OIL PUMP |
| 89 | 7009003 | PUMP COVER OLIOO |
| 91 | 7012000 | INJECTION PUMP |
| 92 | 7013000 | INJECTOR |
| 7013100 | PULVERIZER INJECTOR | |
| 93 | 7017100 | AIR BAFFLE |
| 95 | 7017002 | DUMPER |
| 96 | 7014000 | RECOIL ASSY |
| 97-90 | 9902061 | BOLT 6X8 |
| 98 | 7014008 | CABLE RECOIL |
| 99 | 7014007 | RECOIL HANDLE |
| 100 | 7814009 | SPRING RECOIL CABLE |
| 101 | 7014012 | PULLEY CABLE RECOIL |
| 102 | 9905082 | PLUG 8X18 |
| 103 | 7014005 | SPRING RETURN Ratchet |
| 104 | 7014004 | COVER POWLS |
| 105 | 7014002 | SPRING COMPRESSION |
| 106 | 7014006 | CLUTCH SPRING POWLS |
| 107 | 7014003 | CLUTCH WASHER |
| 109 | 9903060 | WASHER D. 6 |
| 110 | 7014001 | Ratchet RECOIL |
| 111 | 7016100 | ALTERNATOR |
| 112 | 7016005 | STARTER MOTOR |
| 113 | 7016004 | VOLTAGE REGULATOR |
| 114 | 7005102 | STARTING CROWN |
| 115-116 | 7008200 | MUFFLER ASSY FTlRO OIL |
| 7008300 | MUFFLER ASSY FOR AIR FILTER | |
| 117 | 7010500 | PIPE NAFTA |
| 7010012 | PIPE INJECTOR RUBBER | |
| 7010009 | PIPE NAFTA TANK RUBBER | |
| 118 | 7010201 | TANK NAFTA |
| 119 | 7010004 | FILTER TANK |
| 120 | 7010100 | TANK CAP |
| 121 | 7010001 | UPPER BRACKET FIXING TANK |
| 122 | 7010002 | SHOCK TANK |
| 123 | 7010300 | FILTER NAFTA |
| 124 | 7002007 | VALVE SPRING WASHER |
| 125 | 7002005 | VALVE SPRING |
| 126 | 7002002 | VALVE PLATE |
| 127 | 7002105 | SCREW LOG VALVE |
| 128 | 9901060 | NUT SCREW THE REGISTER |
| 129 | 7002106 | BOLT UPPER ROCKER |
| 130·131-132-133 | 7002000 | ROCKER SOLD |
| 134 | 7002016 | SHORT VALVE |
| 135 | 7002001 | STOP VALVE |
| 137 | 7002009 | PORT INJECTOR |
| 138 | 7002018 | WASHER DlSTANZIALE |
| 139 | 7002011 | DISTANCE |
| 140 | 7010400 | TAP TANK |
| 22003300 | BATTERY | |
| 7000002 | BLOCK KEY START | |
| 7007100 | AIR FILTER CARTRIDGE | |
| 7007000 | AIR FILTER COMPLETE | |
| FA302974 | FILTER WET ELECTRIC START | |
| FA202921 | FILTER WET STARTING STANDARD | |
| 7000000 | FLANGE ADAPTATION | |
| 7001000 | SET GASKETS | |
