CM Motori genuine spare parts or replacements parts for to repair Engines CM CM 101/125/152 Standard Model.
In the following table, look for the model of the Motor Pump and the respective parts of the code.
Ordered items will be shipped within 7/10 working days approx.
| CM 101-125 Engines Parts | ||
| 1 | 004500 | Crankshaft CM 101/125 |
| 14 | 009500 | Ring pin stop CM 101/125 |
| 25 | 010001 | Oil Seal CM 101/125 |
| 26 | 010002 | Oil Seal CM 101/125 |
| 43 | 020200 | Spark Plug Joint |
| 49 | 022001 | Standard Recoil Assy CM 101/125/152 |
| 151000 | Recoil Assy with Housing CM 101/125 | |
| 028501 | Con Rod Assy CM 101 | |
| 028502 | Con Rod Assy CM 125 | |
| 77 | 035063 | Electronic Coil CM 101/125 |
| 135 | 140010 | Spark Plug NGK BPMR7A |
| 144 | 150500 | Bing Carburetor |
| 148 | 160005 | Recoil Cable |
| 154 | 170010 | Wrenche l.p.f. |
| 153 | 170002 | Fly Wheel Woodruf Key |
| 174 | 215100 | Cylinder CM 101 |
| 174 | 215125 | Cylinder CM 125 |
| 216001 | Cylinder Assy CM 101 | |
| 216002 | Cylinder Assy CM 125 | |
| 184 | 220050 | Collector CM 125 |
| 201 | 250010 | Air conveyor CM 101/125 |
| 238 | 295005 | Recoil Ratchet |
| 258 | 300004 | Ball bearing 6303 |
| 250 | 298130 | Recoil cap CM 101/125 |
| 257 | 300003 | Bearing 6204 CM 101/125 |
| 277 | 310030 | Self-locking nut M6 |
| 276 | 310012 | Nut M12 |
| 275 | 310011 | Flywheel nut M 16 |
| 281 | 328001 | Bearing puller |
| 282 | 328002 | Flywheel puller |
| 313 | 360040 | Bottom Conrod roll bearing CM 101/125 |
| 393 | 410503 | Muffler gasket CM 101/125 |
| 391 | 410501 | Carter gasket CM 101/125 |
| 390 | 410500 | Cylinder gasket CM 101/125 |
| 394 | 410505 | Intake gasket CM 101/125 |
| 392 | 410502 | Head gasket CM 101 |
| 392 | 410504 | Head gasket CM 125 |
| 397 | 425000 | Recoil Handle CM 101/125 |
| 417 | 500006 | Spring |
| 426 | 500005 | Return spring |
| 416 | 500007 | Torsion spring |
| 620001 | Piston assy CM 101 | |
| 620002 | Piston assy CM 125 | |
| 620004 | Increased piston assy CM 101 | |
| 620005 | Increased piston assy CM 125 | |
| 459 | 620500 | Piston naked CM 101 |
| 459 | 620505 | Piston naked CM 125 |
| 490 | 680004 | Cylinder stud CM 101/125 |
| 512 | 705001 | Recoil Pulley CM 101/125 |
| 529 | 740070 | Washer |
| 543 | 740058 | Washer D. 17 |
| 544 | 740080 | Washer D. 6,5X9,5 |
| 528 | 740121 | Washer |
| 548 | 780030 | Bing Drain Gasoline |
| 554 | 810500 | Segment cylinder CM 101 |
| 554 | 810505 | Segment cylinder CM 125 |
| 613 | 850510 | The crankcase. Flywheel CM 101/125 |
| 612 | 850500 | Crankcase l.p.f. CM 101/125 |
| 880435 | Tank CM 101/125 | |
| 890100 | Gasket sets CM 101 | |
| 890125 | Gasket sets CM 125 | |
| 644 | 895050 | Piston pin CM 101 |
| 644 | 895055 | Piston pin CM 125 |
| 684 | 920500 | Cylinder head CM 101 |
| 684 | 920501 | Cylinder head CM 125 |
| 746 | 940012 | Bolt 6X25 |
| 747 | 940017 | Screw TE 6X25 |
| 762 | 980003 | Flywheel CM 101/125 |
| CM 152 Engines Parts | ||
| 1 | 004600 | Crankshaft CM 152 |
| 14 | 009500 | Ring pin stop CM 152 |
| 25 | 010003 | Ring oil seal 20x32x7 |
| 43 | 020200 | Spark Plug joint |
| 49 | 022001 | Standard Recoil Assy CM 101/125/152 |
| 150600 | Recoil Assy with Housing CM 152 | |
| 028503 | Conrod Assy CM 152 | |
| 77 | 035077 | Electronic Coil CM 152 |
| 135 | 140010 | Spark Plug |
| 144 | 150500 | Carburetor Bing |
| 148 | 160005 | recoil Cable CM 101/125/152 |
| 154 | 170010 | Key l.p.f. |
| 153 | 170002 | Stick flying |
| 174 | 215150 | Cylinder CM 152 |
| 216003 | Cylinder Assy CM 152 | |
| 184 | 220050 | Collector CM 152 |
| 201 | 250011 | Air conveyor CM 152 |
| 238 | 295005 | Ratchet recoil CM 101/125/152 |
| 250 | 298130 | Recoil cap CM 101/125/152 |
| 257 | 300003 | Bearing 6204 |
| 258 | 300005 | Bearing 6304 |
| 277 | 310030 | Self-locking nut M6 |
| 276 | 310012 | Nut M12 |
| 275 | 310011 | Flywheel nut M 16 |
| 281 | 328001 | Bearings Puller |
| 282 | 328002 | Flywheel puller |
| 313 | 360006 | Bottom Conrod roll bearing CM 152 |
| 391 | 410601 | Carter Gasket CM 152 |
| 390 | 410600 | Cylinder Gasket CM 152 |
| 394 | 410505 | Intake Manifold Gasket |
| 393 | 410503 | Muffler Gasket |
| 392 | 410602 | Head Gasket CM 152 |
| 397 | 425000 | Recoil handle |
| 417 | 500006 | Spring |
| 426 | 500005 | Spring |
| 416 | 500007 | Spring |
| 620003 | Piston Assy CM 152 D. 59 | |
| 620006 | Increased piston Assy CM 152 D. 59.5 | |
| 459 | 620510 | Naked Piston CM 152 D. 59 |
| 491 | 680002 | Cylinder Stud CM 152 |
| 512 | 705001 | Recoil pulley cable |
| 529 | 740070 | Washer |
| 543 | 740058 | Washer D. 17 |
| 544 | 740080 | Washer D. 6,5X9,5 |
| 528 | 740121 | Washer |
| 548 | 780030 | Bing drain gasoline tap |
| 554 | 810510 | Segment D. 59 |
| 612 | 850600 | Crankcase l.p.f. CM 152 |
| 613 | 850610 | Crankcase I.V. CM 152 |
| 880440 | Tank CM 152 horizontal shaft | |
| 880441 | Tank CM 152 vertical shaft | |
| 890150 | Series gaskets CM 152 | |
| 644 | 895051 | Piston pin CM 152 |
| 684 | 920600 | Head motor CM 152 |
| 746 | 940012 | Allen bolt 6X25 |
| 747 | 940017 | Screw TE 6X25 |
| 762 | 980004 | Flywheel CM 152 |
