CM Motori Spare Parts for Motor Pump CM115
€4.35
Tax included
CM Motori Spare Parts for Engine Pump CM115
CM Motors genuine parts for replacement or to repair Engine pumps CM115
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
CM Motori Spare Parts for Engine Pump CM115
CM Motors genuine parts for replacement or repair of Engine pumps CM115
In the following table, look for the model of the Motor Pump and the respective parts of the code.
Ordered items will be shipped within 7/10 working days approx.
| Engine pump CM115 | ||
| 001.000 | Equipments | |
| 5 | 004.400 | Crankshaft |
| 5 | 004.410 | Crankshaft |
| 5 | 004.420 | Crankshaft |
| 005.000 | Circlip | |
| 12 | 009.400 | Circlip |
| 22 | 010.410 | Oil seal |
| 35 | 018.410 | Shaft |
| 40 | 020.200 | Plug cap assy |
| 46 | 022.020 | Starter recoil |
| 65 | 027.400 | Connecting |
| 72 | 028.410 | Connecting complete |
| 76 | 035.010 | Ignition coil |
| 81 | 036.000 | Bush |
| 85 | 045.003 | Stop button |
| 89 | 050.400 | Bushing |
| 96 | 100.030 | Hexagonal head bolt |
| 101 | 100.080 | Hexagonal head bolt |
| 102 | 100.090 | Hexagonal head bolt |
| 107 | 100.113 | Hexagonal head bolt |
| 108 | 100.119 | Hexagonal head bolt |
| 109 | 100.115 | Hexagonal head bolt |
| 135 | 140.010 | Spark plug NGK BPMR7A |
| 141 | 150.300 | Carburettor |
| 150.400 | Carburettor | |
| 148 | 160.005 | Pulling rope |
| 150 | 170.000 | Key |
| 170.010 | Key | |
| 169 | 216.500 | Cylinder |
| 173 | 216.530 | Complete cylinder with piston |
| 182 | 220.030 | Intake cooler |
| 188 | 240.020 | Stand - in seal |
| 199 | 250.501 | Fan case |
| 222 | 285.020 | Body pump |
| 222 | 285.022 | Body pump |
| 224 | 285.040 | Body pump |
| 224 | 285.070 | Body pump |
| 224 | 285.080 | Body pump |
| 238 | 295.005 | Drivel pawl |
| 241 | 298.020 | Cover air filter |
| 251 | 298.200 | Starter recoil cover |
| 253 | 300.010 | Val bearing |
| 261 | 310.020 | Nut |
| 277 | 310.030 | Nut |
| 264 | 310.050 | Nut |
| 267 | 310.070 | Nut |
| 268 | 310.051 | Nut |
| 315.000 | Spacer carry | |
| 283 | 325.010 | Filtering element |
| 288 | 327.020 | Pole shoe |
| 289 | 330.010 | Clamp fissing air filter |
| 293 | 340.010 | Benzin filter |
| 350.001 | Flange | |
| 350.002 | Flange | |
| 296 | 350.010 | Flange |
| 296 | 350.012 | Flange |
| 311 | 360.020 | Roll - cage |
| 315 | 366.010 | Float carburettor |
| 319 | 369.020 | Casting carburettor |
| 326 | 375.020 | Impeller |
| 330 | 375.060 | Impeller |
| 330 | 375.080 | Impeller |
| 330 | 375.090 | Impeller |
| 338 | 405.010 | Rubber shock absorber |
| 405.020 | Rubber shock absorber | |
| 410.657 | Gasket | |
| 347 | 410.060 | Gasket |
| 351 | 410.100 | Gasket |
| 355 | 410.140 | Gasket |
| 360 | 410.150 | Gasket |
| 364 | 410.180 | Gasket |
| 367 | 410.210 | Gasket |
| 369 | 410.230 | Gasket |
| 380 | 410.281 | Gasket |
| 381 | 410.300 | Gasket |
| 397 | 425.000 | Starter handle |
| 405 | 428.010 | Magnet |
| 411 | 435.030 | Silencer muffler |
| 416 | 500.007 | Spring |
| 417 | 500.006 | Spring |
| 425 | 500.060 | Spring |
| 426 | 500.005 | Spring |
| 431 | 520.010 | Cable holder |
| 445 | 610.100 | Connection pipette benzin tube |
| 455 | 620.400 | Piston |
| 455 | 620.401 | Piston |
| 456 | 620.410 | Piston |
| 456 | 620.420 | Piston |
| 650.400 | Complete pump | |
| 650.410 | Complete pump | |
| 650.420 | Complete pump | |
| 650.430 | Complete pump | |
| 650.440 | Complete pump | |
| 493 | 680.019 | Prisoner |
| 496 | 680.050 | Prisoner |
| 508 | 705.050 | Pulley starter |
| 512 | 705.001 | Spring pulley |
| 705.051 | Pulley starter | |
| 527 | 727.002 | Craburettor register with spring |
| 528 | 740.121 | Washer |
| 529 | 740.070 | Washer |
| 531 | 740.020 | Washer |
| 532 | 740.030 | Washer |
| 533 | 740.050 | Washer |
| 534 | 740.060 | Washer |
| 538 | 740.080 | Washer |
| 540 | 740.100 | Washer |
| 546 | 780.010 | Fuel tap |
| 552 | 810.030 | Piston ring |
| 552 | 810.060 | Piston ring |
| 589 | 820.400 | Crankshaft |
| 589 | 820.420 | Crankshaft |
| 589 | 820.430 | Crankshaft |
| 595 | 820.410 | Crankshaft |
| 609 | 850.410 | Crankcase |
| 621 | 880.400 | Tank |
| 880.410 | Tank | |
| 890.040 | Gasket series | |
| 890.032 | Gasket series | |
| 890.033 | Gasket series | |
| 630 | 891.001 | Tightening carbuettor |
| 635 | 893.010 | Pin closing benzin carburettor |
| 641 | 895.020 | Piston spin |
| 645 | 900.010 | Support |
| 650 | 900.040 | Support |
| 653 | 900.070 | Support |
| 660 | 912.010 | Cap |
| 661 | 912.020 | Cap |
| 664 | 912.050 | Cap |
| 667 | 912.065 | Cap |
| 671 | 917.020 | Seal |
| 674 | 917.050 | Complete mecanical seal |
| 682 | 920.400 | Head |
| 683 | 923.030 | Fuel hose |
| 695 | 926.010 | Chamber carburettor SHA |
| 701 | 930.020 | Ventilating fan |
| 705 | 940.005 | Screw |
| 718 | 940.070 | Screw |
| 722 | 940.110 | Screw |
| 732 | 940.190 | Screw |
| 743 | 940.230 | Screw |
| 744 | 940.250 | Screw |
| 745 | 940.270 | SCREW |
| 751 | 980.010 | Flywheel |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s CM Motori snc websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to CM Motori snc brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
