In the following table, look for the model of the Percussion Drill and the respective parts of the code
| Percussion Drill PSB 700-2 RE/0 603 162 963 | ||
| # | Part Num. | Description |
| 1 | 2605104600 | Housing Section GREEN |
| 2 | 2604220647 | Field 230V |
| 3 | 2604011166 | Armature 230-240V |
| 3/60 | 2606610029 | Fan |
| 4 | 2607200556 | Switch |
| 6 | 2600707066 | Grommet Ø6,2-Ø6,9x90 MM |
| 9 | 2601117257 | Manufacturer's nameplate PSB 700-2RE |
| 2601115217 | Manufacturer's nameplate PSB 720-2RE | |
| 14 | 2600914019 | Needle bearing |
| 22 | 2602098008 | Change-Over Switch RED |
| 23 | 2603490022 | Torx Oval-Head Screw 4x16 |
| 24 | 2910611002 | Tapping Screw DIN 7981-ST2,2x9,5-C-H |
| 25 | 1900210000 | O-Ring 5,0x1,5 MM |
| 27 | 2603239024 | Damping Element |
| 28 | 2603429006 | Oval-Head Screw |
| 29 | 2608040109 | Handle Cover BLACK |
| 30 | 2606135093 | Drilling Spindle 1/2" |
| 31 | 2600118001 | Locking Washer 0,6 MM |
| 2600118002 | Locking Washer 0,8 MM | |
| 2600118006 | Locking Washer 0,3 MM | |
| 32 | 2604616006 | Compression Spring |
| 33 | 2600301054 | Sintered-Metal Bushing |
| 34 | 2606317082 | Cylindrical Gear |
| 35 | 2606317083 | Cylindrical Gear |
| 36 | 2600100695 | Shim 0,5 MM |
| 37 | 2600101047 | Shim 0,3 MM |
| 38 | 2601329072 | Contact Strap |
| 39 | 2600101084 | Retaining Washer |
| 40 | 2602300034 | Flat Key |
| 41 | 2601098031 | Guiding Plate |
| 42 | 2600190070 | Catch Disk |
| 44 | 1903230010 | Ball DIN 5401-5,5MM-III-ST |
| 45 | 2601990001 | Indexing Disk BLACK |
| 46 | 2601074003 | Pressure Plate |
| 47 | 1600100632 | Shim 0,2 MM THICK |
| 52 | 2600100607 | Shim 0,3 MM |
| 54 | 2600400027 | Bearing Sleeve |
| 55 | 2600100637 | Shim 0,5 MM |
| 56 | 2601990009 | Fork Lever |
| 57 | 2602026091 | Rotary Head |
| 58 | 2600590006 | Ratchet Cap |
| 62 | 2601335001 | Driver Pin |
| 64 | 2600100618 | Shim washer |
| 65 | 2609007376 | Roller Body |
| 67 | 2600190071 | Catch Disk |
| 68 | 2600914010 | Needle bearing Ø6 MM |
| 76 | 2601005011 | Felt Strip |
| 77 | 2601005021 | Felt Strip |
| 80 | 2608572121 | Keyless Chuck 1/2" |
| 90 | 2604448228 | Pvc-Insulated Cable L=120 MM BLUE |
| 91 | 1614431025 | Pvc-Insulated Cable L=95 MM |
| 96 | 2600100066 | Plain Washer |
| 210 | 2601116284 | Reference Plate |
| 654 | 2602025125 | Auxiliary Handle BLACK |
| 655 | 2609005615 | Depth-Gauge |
| 805 | 1607000387 | Power supply cord EU 2,65m 2 x 0,75mm |
| 808 | 2601117336 | Marking Plate |
| 813 | 2600905103 | Deep-Groove Ball Bearing 7x19x6 |
| 816 | 2604337061 | Brush Plate |
| 816/04 | 2604321930 | Carbon-Brush Set |
| 819 | 2910611006 | Tapping Screw DIN 7981-ST2,9x13-C-H |
| 849 | 2606309936 | Toothed Shaft |
| 850 | 2606440900 | Carrier |
| 863 | 2916080007 | Locking Washer DIN 6799-4-FSt |
| 866 | 2605807934 | Bearing Bracket |
| 890 | 2607001305 | Fastening parts kit |
| 891 | 2603410046 | Cross Recessed-Head Screw M3x5 |
