Bosch Spare Parts for Jig Saw GST 75 BE
Bosch original spare parts for to replace broken parts for to fix Jig Saw GST 75 BE - 0603382704.
In the following table, look for the model of the jig Saw and the respective parts of the code.
| GST 75 BE/0 603 382 704 | ||
| # | Part Num. | Description |
| 2 | 2604220655 | Expanding Polar 220-240V |
| 3 | 2604011234 | Armature 220-240V |
| 3/50 | 2606610029 | Fan |
| 4 | 2607200581 | Switch Opens Closes |
| 6 | 2600703017 | Nozzle Ø6.4 MM-Ø7,2x76 |
| 13 | 2600905021 | Rigid bearing 9x24x7 BALL |
| 14 | 2605805008 | A support flange |
| 16 | 2604337085 | As a stand brush holder |
| 25 | 2603105080 | Adjustment Bolt |
| 29 | 2600914022 | Needle roller bearings |
| 30 | 2600101048 | Washer Compensation 0.5 MM |
| 32 | 2600101077 | Washer Compensation 0.5 MM |
| 33 | 2601923012 | A lever Intaglio |
| 35 | 2603105091 | Adjustment Bolt |
| 36 | 2600100588 | Washer Compensation 0.5 MM |
| 37 | 2601098060 | Counterweight |
| 38 | 1903201054 | Roll 4x15,8 MM |
| 40 | 2600780147 | Rod Lift |
| 41 | 2605801038 | Bearing Radente |
| 42 | 2604613004 | Compression spring |
| 43 | 2603201089 | Roll |
| 44 | 2603105084 | Adjustment Bolt |
| 45 | ||
| 46 | 2602317037 | Profiled strip |
| 47 | 2600040003 | Plate Fasteners |
| 48 | 2603413034 | Socket Head Screw |
| 58 | 2601321051 | Lever Roller |
| 59 | 2917550101 | Cylindrical pin DIN 6325-4m6x20 |
| 60 | 2601015077 | PLATE SEAL |
| 64 | 2600590006 | Cap Crash |
| 65 | 2601038111 | Element Crash |
| 67 | 2602026096 | Switching element |
| 69 | 2603490022 | A Torx Head Sego 4x16 |
| 71 | 2608040148 | Shell To Handle |
| 75 | 2605510169 | Hood |
| 78 | 2603105088 | Safety pin |
| 82 | 2604448127 | Connection Cable L = 220 MM WHITE |
| 219 | 2603490022 | A Torx Head Sego 4x16 |
| 801 | 2605105929 | Shell casing BLUE |
| 805 | 1607000386 | Line Connection EU 230V 4,15m 2 x 1.0mm H05 RN-F |
| 808 | 2601117575 | Nameplate Indictor |
| 809 | 2601116649 | Targa manufacturing |
| 816/070 | 2604321925 | Brushes series |
| 826 | 2605807936 | Beam Carrier |
| 827 | 2606320904 | On the eccentric gear |
| 834 | 2916640001 | Ring DIN held 471-4x0,4-FSt |
| 839 | 2916640005 | Ring DIN held 471-8x0,8 FSt |
| 891 | 2603410046 | Screw Phillips M3x5 |
| 895 | 2601320027 | Closing |
