Bosch Spare Parts for Lawnower UniversalRotak 450
€22.28
Tax included
Bosch Spare Parts for Lawnower UniversalRotak 450
Bosch original spare parts for to replace broken parts for to fix Lawnmower Universal Rotak 450 - 3600HB9000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Lawnower UniversalRotak 450
Bosch original spare parts for to replace broken parts for to fix Lawnmower Universal Rotak 450 - 3600HB9000.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| Lawnower UniversalRotak 450 | ||
| # | Part Num. | Description |
| 32 | F016L37433 | Self-Cutting Screw |
| 39/16 | F016L66895 | Cable Clip |
| 39/801 | F016105285 | Clamping Lever |
| 40 | F016L90015 | Mower deck |
| 41 | F016L90441 | Housing 36 cm |
| 41/2 | F016L67442 | Bearing 6002-2RS |
| 43/1 | F016L90017 | Motor Hood |
| 43/2 | F016L90018 | Carrying Handle |
| 43/3 | F016L90081 | Cover |
| 43/4 | F016L90432 | Transparent Cover |
| 43/5 | F016L90434 | Indicator |
| 43/6 | F016L90019 | Button |
| 43/7 | F016L90071 | Button Spring |
| 43/8 | F016L90022 | Guard Flap |
| 43/9 | F016L66165 | Spring |
| 43/10 | F016L90020 | grille |
| 43/11 | F016L90076 | Sticker logo l |
| 43/12 | F016L90077 | Sticker logo r |
| 49 | F016L90027 | Linkage part |
| 52/1 | F016L90005 | Axle |
| 52/2 | F016L90033 | Link Piece |
| 52/3 | F016L90037 | Link Piece |
| 52/4 | F016L68095 | Ratchet Cap |
| 52/805 | F016105108 | Wheel |
| 55 | F016L69570 | Cutter Blade 36 cm |
| 58 | F016L18181 | Locking Washer 1/2" |
| 59 | F04N004003 | Hex Screw |
| 61/1 | F016L90004 | Axle |
| 61/2 | F016L90032 | Link Piece |
| 61/3 | F016L90036 | Spacer |
| 61/4 | F016L68095 | Ratchet Cap |
| 61/805 | F016105110 | Wheel |
| 75/1 | F016L90608 | Handle |
| 75/3 | F016L90702 | wiring unit |
| 75/3/1 | F016L67217 | Switch Housing |
| 75/3/2 | F016L90781 | Terminal Block |
| 75/3/3 | F016L90708 | Connection Cable |
| 75/3/804 | F016104371 | Switch Kit |
| 75/3/805 | F016104213 | Cable Guide |
| 75/14 | F016L36542 | Screw M5x8 Csk Hd. |
| 75/15 | F016L68124 | Torx head screw |
| 75/802 | F016105314 | Nut Holder |
| 75/804 | F016105287 | Switching Unit |
| 75/805 | F016104361 | Sleeve |
| 78/1 | F016L91163 | Bracket |
| 78/2 | F016L90890 | Handle |
| 78/3 | F016L36542 | Screw M5x8 Csk Hd. |
| 79/1 | F016L91164 | Bracket |
| 79/2 | F016L90891 | Handle |
| 79/3 | F016L36542 | Screw M5x8 Csk Hd. |
| 99 | F016L69400 | Balance Weights |
| 106 | F016L90419 | Wire Guide |
| 108 | F016L67627 | Bearing cover |
| 110 | F016L90089 | Baffle |
| 121 | F016L90029 | Clip |
| 122 | F016L59327 | Spring |
| 123 | F016L90721 | Plastic Insert |
| 124 | F016L90701 | Button Spring |
| 125 | F016L90197 | Button |
| 126 | F016L90198 | Button |
| 130 | F016L90872 | front cover P1 DARK GREY |
| 131 | F016L90163 | Cover |
| 132 | F016L90167 | Cover |
| 500 | F016L68124 | Torx head screw |
| 801 | F016105105 | Motor |
| 801/1/21 | F016L65351 | Drive Belt |
| 801/1/817 | F016103758 | Drive Shaft |
| 801/1/2/2 | F016L64594 | Bearing |
| 801/2 | F016L90879 | Thermal protector |
| 883 | F016105282 | Collection box |
| 883/1/2 | F016L90040 | Handle |
| 883/1/3 | F016L90557 | Cover |
| 883/1/4 | F016L90558 | Pivot Plate |
| 883/1/10 | F016L90638 | Pin |
| 883/1/11 | F016L90639 | Socket insert |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
