Bosch Spare Parts for Table Saw GTS 10 J - 3601M30500
€1.12
Tax included
Bosch Spare Parts for Table Saw GTS 10 J - 3601M30500
We are BOSCH original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Table Saw - GTS 10 J/230 V/EU - 3601M30500.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Table Saw GTS 10 J - 3601M30500
We are BOSCH original spare parts Dealers at low at unbeatable prices and an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Table Saw - GTS 10 J/230 V/EU - 3601M30500.In the following table, look for the model of the Bench Saw and the respective parts of the code.
| Table Saw - GTS 10 J/230 V/EU - 3601M30500 | ||
| # | Part Num. | Description |
| 2 | 1609203K86 | Field 230V |
| 3 | 1619P03278 | Armature 230V |
| 4 | 2610016997 | Switch |
| 5 | 2610016998 | Power supply cord |
| 6 | 1609203K96 | Cable Clip |
| 7 | 2610014693 | Cable Clip |
| 8 | 2610016764 | Nameplate |
| 10 | 2610018332 | Carbon-Brush Set |
| 13 | 2610004595 | Ball Bearing |
| 14 | 2610911927 | Ball Bearing |
| 16 | 2610911858 | Brush Holder alt |
| 2610013003 | Brush Holder neu | |
| 18 | 2610015078 | Screw |
| 19 | 2610017002 | Screw |
| 22 | 2610014697 | Screw |
| 25 | 2610014698 | Nut |
| 26 | 2610996920 | Connecting Nut |
| 27 | 2610014699 | Handle |
| 28 | 2610015000 | Cam |
| 29 | 2610015001 | Washer |
| 30 | 2610015002 | Spring retaining ring |
| 32 | 2610017003 | Pin |
| 33 | 2610017004 | Rod |
| 34 | 2610017005 | Extension Stand |
| 35 | 2610015006 | Retaining Plate |
| 36 | 2610910015 | Collar bolt |
| 37 | 2610355325 | Spring Washer |
| 38 | 2610910013 | Washer |
| 39 | 2610015008 | Nut |
| 40 | 2610015009 | Handle |
| 41 | 2610015010 | Pointer |
| 42 | 2610950077 | Screw |
| 44 | 2610023173 | Pad |
| 72 | 2610950069 | Screw |
| 73 | 2610015011 | Washer |
| 74 | 2610015012 | Bolt |
| 75 | 2610925438 | Washer |
| 76 | 2610015014 | Supporting foot |
| 77 | 2610015015 | Screw |
| 78 | 2610015016 | Handle |
| 79 | 2610015017 | Holding Plate |
| 80 | 2610015018 | Screw |
| 81 | 2610015019 | Key |
| 82 | 2610911566 | Bearing cover |
| 83 | 2610015021 | Nut |
| 84 | 2610015022 | Workpiece Pusher |
| 86 | 2610017007 | Support bracket |
| 87 | 2610010404 | Screw |
| 88 | 2610017009 | Scale |
| 102 | 1609902670 | Screw |
| 103 | 2610327868 | Nut |
| 109 | 2610998587 | Screw |
| 112 | 2610017013 | End cap |
| 113 | 2610911933 | Connector |
| 117 | 2610998571 | Screw alt |
| 117 | 2610018983 | Attachment Screw neu |
| 118 | 2610950042 | Spring Washer |
| 119 | 2610017014 | Cover |
| 120 | 2610950044 | Screw |
| 121 | 2610996949 | Ball Bearing |
| 122 | 2610017015 | Filter |
| 123 | 2610997281 | Spring retaining ring |
| 124 | 2610998572 | Screw |
| 125 | 2610996875 | Torsion Spring |
| 126 | 2610996874 | Locking Lever |
| 127 | 2610996876 | Shoulder Screw |
| 128 | 2610998588 | Screw |
| 129 | 2610017111 | Insert |
| 130 | 2610017017 | Gear Housing |
| 131 | 2610937293 | Retaining ring |
| 132 | 2610015026 | Sliding Plate |
| 133 | 2610950108 | Screw |
| 134 | 2610015027 | Support Plate |
| 136 | 2610017008 | Retaining clip |
| 137 | 2610017019 | Table |
| 138 | 1600A00724 | Mounting Rail |
| 140 | 1609902054 | Set screw |
| 141 | 2610911929 | Screw |
| 142 | 2610911901 | Self-locking nut |
| 143 | 2610911569 | Insert |
| 144 | 2610996948 | Rubber Ring |
| 145 | 2610950071 | Screw |
| 146 | 2610015030 | End cap |
| 147 | 2610911859 | Brush-Cover Ø 20mm |
| 149 | 2610015031 | Spring retaining ring |
| 150 | 2610996932 | Bearing Sleeve |
| 151 | 2610017001 | Vacuum Connection |
| 152 | 2610997210 | Ball Bearing |
| 153 | 2610997282 | Spring retaining ring |
| 154 | 2610017021 | Spindle |
| 155 | 2610012984 | Woodruff Key |
| 156 | 2610997208 | Toothed Gear |
| 157 | 2610017018 | Bushing |
| 158 | 2610998573 | Spring retaining ring |
| 159 | 2610950427 | Set screw |
| 160 | 2610017022 | Chain |
| 161 | 2610950126 | Mounting Bracket |
| 162 | 2610950070 | Bushing |
| 163 | 2610015035 | Support bracket |
| 164 | 2610017023 | Fastening parts kit |
| 165 | 2610017024 | Holding Plate |
| 166 | 2610017025 | Rod |
| 167 | 2610015038 | Bolt |
| 168 | 2610015039 | Washer |
| 169 | 2610015040 | Support Plate |
| 170 | 2610950055 | Screw |
| 171 | 2610017026 | Rod |
| 172 | 2610015042 | Bevel Gear |
| 173 | 2610013162 | Washer |
| 174 | 2610015043 | Bushing |
| 175 | 2610015044 | Washer |
| 176 | 2610017020 | Fastening parts kit |
| 177 | 2610015045 | Screw |
| 178 | 2610017027 | Shaft |
| 179 | 2610015047 | Support Plate |
| 180 | 2610015048 | Bushing |
| 181 | 2610016557 | Washer |
| 182 | 2610016558 | Nut |
| 183 | 2610015049 | Bushing |
| 184 | 2610013053 | Set screw |
| 185 | 2610016559 | Screw |
| 186 | 2610015050 | Cover |
| 187 | 2610950049 | Screw |
| 188 | 2610017037 | Electronics Module |
| 189 | 2610015051 | Dust-Cover Holder |
| 190 | 2610015052 | Screw |
| 191 | 2610015053 | Spring retaining ring |
| 192 | 2610017028 | Retaining clip |
| 193 | 2610016560 | Stud bolt |
| 194 | 2610016561 | Screw |
| 195 | 2610925187 | Nut |
| 196 | 2610015055 | Guard Plate |
| 197 | 2610950132 | Screw |
| 198 | 2610015073 | Plate |
| 200 | 2610017029 | Screw |
| 201 | 2610017030 | Spring Clip |
| 202 | 2610017033 | Safety Guard |
| 203 | 2610950439 | Screw |
| 204 | 2610015054 | Guard Plate |
| 205 | 2610016562 | Rod |
| 206 | 2610016563 | Contact strap |
| 207 | 2610923830 | Plate |
| 208 | 2610010404 | Screw |
| 209 | 2610017031 | Screw |
| 210 | 2610015058 | Washer |
| 211 | 2610911920 | Rubber Bushing |
| 212 | 2610015059 | Wrench Socket |
| 213 | 2610017032 | Holding Plate |
| 214 | 2610017110 | Washer |
| 215 | 2610347092 | Plain Washer |
| 216 | 2610017046 | Insulator |
| 217 | 2610015061 | Bushing |
| 218 | 2610015062 | Handle |
| 219 | 2610924961 | Nut |
| 220 | 2610015359 | Screw |
| 221 | 2610015063 | Cam |
| 223 | 2610950049 | Screw |
| 225 | 2610015064 | Pointer |
| 226 | 2610015065 | Screw |
| 227 | 2610013054 | Contact strap |
| 228 | 2610015066 | Switch Housing |
| 229 | 2610015067 | Spring |
| 230 | 2610996912 | Fixing Plate |
| 231 | 2610015091 | Sliding Rail |
| 234 | 2610951945 | Screw |
| 235 | 1609203K93 | Clamping Flange |
| 237 | 2610950046 | Washer |
| 238 | 2610358858 | Nut |
| 239 | 2610015069 | Handwheel |
| 242 | 2610950059 | Spacer Tube |
| 243 | 2610950060 | Screw |
| 244 | 2610950389 | Washer |
| 248 | 2610017034 | Safety Cover |
| 252 | 2610017035 | Mitre Fence |
| 253 | 2610017036 | Rod |
| 254 | 2610017052 | Screw |
| 256 | 2610998580 | Screw |
| 257 | 2610017038 | Nut |
| 258 | 2610015070 | Screw |
| 259 | 2610016565 | Contact strap |
| 260 | 2610017039 | Safety Cover |
| 261 | 2610015071 | Switch Housing |
| 262 | 2610017040 | Connecting Cable |
| 263 | 2610017041 | Mitre Fence |
| 264 | 2610015074 | Rail |
| 265 | 2610015075 | Washer |
| 266 | 2610015076 | Device cap |
| 267 | 2610950134 | Bolt |
| 269 | 2610015077 | Plate |
| 270 | 2610950117 | Screw |
| 271 | 2610013365 | Spring Washer |
| 273 | 2610015080 | Screw |
| 274 | 2610950135 | Washer |
| 275 | 2610016566 | Washer |
| 279 | 2610018328 | Protective Cover |
| 280 | 2610017047 | Mitre Fence |
| 281 | 2610015507 | Mitre Gauge |
| 283 | 2610016567 | Hexagon Socket Wrench |
| 285 | 2610023174 | Serrated Lock-Washer |
| 286 | 2610015093 | Lock |
| 287 | 2610017048 | Base |
| 288 | 2610017049 | Riving Knife |
| 289 | 2610017050 | Rod |
| 290 | 2610950389 | Washer |
| 291 | 2610017051 | Washer |
| 292 | 2610950109 | Washer |
| 293 | 2610950108 | Screw |
| 294 | 2610017053 | Holder |
| 295 | 2610017054 | Holder |
| 296 | 2610015065 | Screw |
| 297 | 2610015001 | Washer |
| 298 | 2610017056 | Rod |
| 299 | 2610017057 | Screw |
| 300 | 2610017058 | Torsion Spring |
| 301 | 2610015065 | Screw |
| 302 | 2610017060 | Safety Guard |
| 303 | 2610020856 | Cable Clip |
| 305 | 2610020858 | Baffle |
| 343 | 2610020856 | Cable Clip |
| 344 | 2610020859 | Cable Clip |
| 801 | 1619PB2531 | Motor Housing |
