Bosch Spare Parts for Jig Saw PST 1000 PEL
€11.74
Tax included
Bosch Spare Parts for Jig Saw PST 1000 PEL
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Jig Saw PST 1000 PEL - 3603CA0300.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Jig Saw PST 1000 PEL
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Jig Saw PST 1000 PEL - 3603CA0300.
In the following table, look for the model of the Jig Saw and the respective parts of the code.
| Jig Saw PST 1000 PEL/3 603 CA0 300 | ||
| # | Part Num. | Description |
| 1 | 2609003458 | Housing Section GREEN |
| 2 | 2609003671 | Field 230-240V |
| 3/9 | 2606610123 | Fan |
| 4 | 1607200218 | Switch |
| 6 | 2609003080 | Grommet Ø6,4-Ø7,2x76 MM |
| 9 | 2609003621 | Manufacturer's nameplate PST 1000 PEL |
| 13 | 3130900020 | groove ball bearing 8x22x7 608-2Z/C3 |
| 14 | 2600905110 | groove ball bearing 8x22x7 |
| 16 | 2609006435 | Brush Holder |
| 24 | 2609003644 | Cover |
| 25 | 2603105080 | Bearing bolt |
| 27 | 2606320093 | Eccentric Cog Wheel |
| 28 | 2600914022 | Needle bearing |
| 29 | 2600101048 | Shim 0,5 MM |
| 31 | 2600913040 | Needle-Roller Assembly |
| 32 | 2600101077 | Shim 0,5 MM |
| 33 | 2601923012 | Fork Lever |
| 34 | 2916640001 | Spring retaining ring DIN 471-4x0,4-FSt |
| 35 | 2603105091 | Bearing bolt |
| 36 | 2600100588 | Shim 0,5 MM |
| 37 | 2601098098 | Counterweight |
| 38 | 1903201055 | Needle Roller |
| 39 | 2916640905 | Spring retaining ring 8x0,8 N31A MR7 |
| 40 | 2600780149 | Lifting Rod |
| 41 | 2605801038 | Plain bearing |
| 42 | 160461201E | Compression Spring |
| 43 | 2603201089 | Needle Roller |
| 45 | 2603105084 | Bearing bolt |
| 46 | 2609001608 | Roller Lever |
| 51 | 2602317052 | Profile Beading |
| 52 | 2602098016 | Tensioning Lever |
| 54 | 2600040003 | fixing plate |
| 57 | 2609003462 | Base Plate |
| 58 | 2609003463 | Work Board |
| 59 | 2603421014 | Thread-forming tap. Screw |
| 60 | 2601015077 | Sealing Plate |
| 62 | 2609003447 | Change-Over Switch |
| 63 | 2603124155 | Control Shaft |
| 64 | 2600590006 | Ratchet Cap |
| 65 | 2609002725 | Straight Pin |
| 67 | 2609003337 | Switch Slide RED |
| 68 | 2603490022 | Screw 4x16 |
| 69 | 2603490022 | Screw 4x16 |
| 70 | 2601035001 | Cable Clip |
| 71 | 2603490021 | Torx Oval-Head Screw 4x12 |
| 75 | 2609003464 | Covering hood |
| 78 | 2609003350 | Protecting Cover BLACK |
| 85 | 1607233368 | Led Board |
| 86 | 2609003465 | Lens |
| 91 | 2609003553 | Pad |
| 658 | 2609003511 | Support |
| 659 | 2609003512 | Window |
| 668 | 2601016065 | Splintering Protector |
| 803 | 2609001928 | Armature 230-240V |
| 805 | 1607000387 | Power supply cord CN 2,65m 2 x 0,75mm H05 W-F |
| 808 | 160111A2KF | Nameplate |
| 810 | 2610391290 | Carbon-Brush Set |
| 826 | 2609003887 | Bearing Bracket |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch PST 1000 PEL - 3603CA0300
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
