Bosch Spare Parts for Angle Grinder GWS 14-150C

€2.31
Tax included

Bosch Spare Parts for Angle Grinder GWS 14-150C

We have the original Bosch Spare Parts for Angle Grinder GWS 14-150C, the diagram, parts list and tool repair that help you need to get your tools running like new again

Fix Your Angle Grinder GWS 14-150C - 0601806703. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee

Bosch GWS 14-150C - 0601806703
ITEM CODE: 1600119011
Quantity
Usually Ships in: 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Bosch Spare Parts for Angle Grinder GWS 14-150C

Fix Your Angle Grinder GWS 14-150C - 0601806703. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Angle Grinder and the respective parts of the code.
Bosch GWS 14-150C - 0601806703

Angle Grinder - 0601806703 - GWS 14-150C/230 V/EU
# Part Num. Description
2 1604220284 Field 220-230V
4 1607200137 Switch
7 1601302017 Fastening Clamp
9 1601118A78 Manufacturer's nameplate
12 1607328042 Suppression Filter
13 2600905032 Ball Bearing 7x19x6
14 1600905032 groove ball bearing 8x22x7
24 1605500228 Cover BLUE
25 1605500226 Housing Cover BLUE
26 1600206036 Rubber Ring
27 1600206025 Rubber Ring
29 1600591025 Air-Deflector Ring
30 1600591014 Air-Deflector Ring
32 1603523110 Grinding Spindle M14, SW17
33 3600210124 O-Ring 46,0x1,1 MM RED
35 1600136013 Shim 0,1 MM THICK
35 1600136020 Shim 0,15 MM THICK
35 1600136014 Shim 0,2 MM THICK
35 1600136015 Shim 0,3 MM THICK
37 1600290016 Rotary shaft lip seal
40 1600119011 Retaining clip
41 1600910018 Needle bearing Ø8xØ12x8 MM
45 1603300016 Hex Nut M7, SW10
47 2912401018 Tapping Screw DIN7981-ST3,9x13-C-Z
49 1603435026 Thread-forming tap. Screw
50 2912401420 Tapping Screw DIN7981-ST3,9x19-F-Z
51 1607233107 Speed governor 220-240V
55 1603415005 Oval-Head Screw
80 3600150021 Sealing disk
104 1600210044 O-Ring 4,5x1,0 MM BLUE
105 1601008005 Insulating Plate
301/1 1605108208 Motor Housing BLUE
301/16 1601323025 Brush Holder
301/17 1604652013 Spiral Spring
301/18 1602026057 Switch Handle BLACK
301/19 1604611026 Compression Spring
301/20 1602319011 Adjusting Slide
301/48 2912401005 Tapping Screw DIN7981-ST2,9x9,5C-Z
803 1604010654 Armature With Fan 220-240V
805 1607000227 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F
806 1600703031 Grommet Ø7,3-Ø8,6x67 MM
808 160111A3H3 Nameplate
810 1607014176 Carbon-Brush Set
818 2910110048 Pan head screw DIN 85-AM3x6-CUZN
821 1605806451 Gear Housing
828 1607000348 Bearing Flange Ø 150 MM
835 1606610129 Fan
838 1607000A4P Set Of Gearwheels
840 1607000253 Push-Button BLACK
890 1600210039 O-Ring 20,35x1,78 MM
891 2602025067 Auxiliary Handle M10, Ø32,5x105 MM
891 1602025031  Auxiliary Hand le M10,Ø37x115MM ANTI-VIBRATION
892 1603345043 Round Nut M14
893 1607950052 Pin-Type Face-Wrench
894 1605510308 Protective Cover Ø 150 MM
895 2605703014 Clamping Flange Ø22,3xØ42 MM
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GWS 14-150C - 0601806703
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
New

Download

Diagram Bosch GWS 14-150C

Diagram Bosch GWS 14-150C

Download (209.92KB)
