Bosch Spare Parts for Angle Grinder GWS 1000
Bosch original spare parts, sourced from the manufacturer, at the best price on the web, for to Make Maintenance or Replacement of Broken parts of the Angle Grinder GWS 1000 - 3601H21003.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder GWS 1000/3 601 H21 003 | ||
| # | Part Num. | Description |
| 2 | 1604220283 | Field 220-240V |
| 4 | 1607200086 | On-Off Switch |
| 7 | 1601302017 | Fastening Clamp |
| 9 | 1601118G95 | Manufacturer's nameplate GWS 1000 |
| 12 | 1607328074 | Suppression Capacitor |
| 13 | 2600905032 | Ball Bearing 7x19x6 |
| 14 | 1600905032 | groove ball bearing 8x22x7 |
| 24 | 1605500228 | Cover BLUE |
| 25 | 1605500251 | Housing Cover DARK BLUE |
| 26 | 1600206036 | Rubber Ring |
| 27 | 1600206025 | Rubber Ring |
| 29 | 1600591025 | Air-Deflector Ring |
| 30 | 1600591014 | Air-Deflector Ring |
| 32 | 1603523110 | Grinding Spindle M14, SW17 |
| 33 | 1600210035 | O-Ring 46,0x1,1 MM |
| 35 | 1600136013 | Shim 0,1 MM THICK |
| d | 1600136020 | Shim 0,15 MM THICK |
| d | 1600136014 | Shim 0,2 MM THICK |
| d | 1600136015 | Shim 0,3 MM THICK |
| 37 | 1600290016 | Rotary shaft lip seal |
| 40 | 1600119011 | Retaining clip |
| 41 | 1600200029 | Plain bearing |
| 45 | 1603300016 | Hex Nut M7, SW10 |
| 47 | 2603490021 | Torx Oval-Head Screw 4x12 |
| 49 | 2914491410 | Thread-forming tap. Screw M4x16 |
| 50 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 52 | 1604448013 | Connecting Cable L=90 MM WHITE |
| 53 | 1603435078 | Torx Oval-Head Screw |
| 54 | 1603414026 | Torx Oval-Head Screw 4x30 |
| 80 | 3600150021 | Sealing disk |
| 104 | 1600210044 | O-Ring 4,5x1,0 MM BLUE |
| 105 | 1601008005 | Insulating Plate |
| 301/1 | 1605108249 | Motor Housing DARK BLUE |
| 301/16 | 1601323025 | Brush Holder |
| 301/17 | 1604652013 | Spiral Spring |
| 301/18 | 1602026088 | Switch Handle |
| 301/19 | 1604611026 | Compression Spring |
| 301/20 | 1602319011 | Adjusting Slide |
| 301/48 | 1613435034 | Lens Head Screw 3x10 ST |
| 343 | 1607000742 | Catch Lever |
| 343/44 | 1604611042 | Compression Spring |
| 651 | 1605510355 | Protective Cover Ø115 MM |
| 803 | 1604010A20 | Armature With Fan 230V |
| 805 | 1607000227 | Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F |
| 806 | 1600703040 | Grommet |
| 808 | 160111A3H3 | Nameplate |
| 810 | 1607014176 | Carbon-Brush Set |
| d | 1607000482 | Carbon-Brush Set 10 x 1 607 014 176 |
| 818 | 2910110048 | Pan head screw DIN 85-AM3x6-CUZN |
| 821 | 16058065SC | Gear Housing |
| 828 | 1607000448 | Bearing Flang |
| 828/04 | 3600210109 | O-Ring 47,0x1,5 MM |
| 831 | 1601290013 | Spring Element |
| 835 | 1606610132 | Fan |
| 838 | 1600A0022W | Gear Unit |
| 840 | 1607000A71 | Push-Button |
| 890 | 1600210039 | O-Ring 20,35x1,78 MM |
| 891 | 2602025067 | Auxiliary Handle M10, Ø32,5x105 MM |
| d | 1602025052 | Auxiliary Handle M10 ANTI-VIBRATION |
| 892 | 1603345043 | Round Nut M14 |
| 893 | 1607950052 | Pin-Type Face-Wrench |
| 895 | 2605703014 | Clamping Flange Ø22,3xØ42 MM |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GWS 1000 - 3601H21003
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
