Bosch Spare Parts for Cordless Impact Drill PSB 9,6 VES-2
€3.12
Tax included
Bosch Spare Parts for Cordless Impact Drill PSB 9,6 VES-2
Bosch genuine spare parts for replacing or repairing Cordless Impact Drill PSB 9,6 VES-2 /EU - 0603926627.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Cordless Impact Drill PSB 9,6 VES-2
Bosch genuine spare parts for replacing or repairing Cordless Impact Drill PSB 9,6 VES-2 /EU - 0603926627.
In the following table, look for the model of the Cordles Drill and the respective parts of the code.
| Cordless Impact Drill PSB 9,6 VES-2 /EU - 0603926627 | ||
| # | Part Num. | Description |
| 4 | 2607200309 | On-Off Switch |
| 9 | 2601118384 | Manufacturer's nameplate SUNNY SIDE |
| 20 | 2601118385 | Reference Plate SHADOW SIDE |
| 27 | 1900905120 | groove ball bearing 10x26x8 |
| 28 | 2605719006 | Adapter |
| 29 | 2605510147 | Insert Piece BLACK |
| 32 | 2601099032 | Adjusting Slide |
| 33 | 2604601004 | Retaining ring |
| 34 | 2602210014 | Eccentric |
| 35 | 2602329024 | Roller Body |
| 37 | 2606440002 | Carrier |
| 42 | 1609340007 | Set Of Gears Z=58/67 |
| 47 | 2606316120 | Pinion Z=14 |
| 49 | 2605510117 | Insert Piece BLACK |
| 50 | 2605190037 | Adjusting Screw |
| 53 | 2608005045 | Clamping Sleeve |
| 54 | 2603410043 | Thread-forming tap. Screw |
| 55 | 2600190056 | Locating Washer |
| 60 | 2604618001 | Compression Spring |
| 68 | 1900905122 | groove ball bearing 15x32x9 |
| 69 | 2916650001 | Spring retaining ring DIN 471-10x1MM-FSt |
| 70 | 2600100569 | Shim 1,0 MM |
| 71 | 2600290023 | Backup ring |
| 73 | 2606490060 | Catch Disk |
| 77 | 2600190064 | Corrugated Washer |
| 78 | 2600101516 | Thrust Bearing Disc |
| 79 | 2600923003 | Ball Cage |
| 94 | 2600301011 | Sintered-Metal Bushing |
| 95 | 2600302002 | Sintered-Metal Bushing |
| 96 | 2600290022 | Insert |
| 100 | 2601322016 | Clamp Spring |
| 101 | 2603490022 | Torx Oval-Head Screw 4x16 |
| 102 | 2601329041 | Retaining Bracket |
| 104 | 2608018004 | Contact retainer |
| 107 | 2603421218 | Countersunk-Head Screw M6x38/12(Ø10) LEFTHAND THREADS |
| 725 | 2608572053 | Keyless Chuck Ø 1,5-10 MM,1/2" |
| 753 | 2607224708 | Fast Charger USA 120/7,2-14,4V, 30 MIN. |
| 753 | 2607224431 | Fast Charger USA 120/7,2-24V, 1h |
| 753 | 2607224701 | Fast Charger EU 230/7,2-14,4V, 30 MIN. |
| 753 | 2607224425 | Fast Charger EU 230/7,2-24V, 1h |
| 753 | 2607224703 | Fast Charger GB 230/7,2-14,4V, 30 MIN. |
| 753 | 2607224427 | Fast Charger GB 230/7,2-24V, 1h |
| 753 | 2607224705 | Fast Charger AUS 240/7,2-14,4V, 30 MIN. |
| 753 | 2607224443 | Fast Charger AUS 240/7,2-14,4V, 1h |
| 791 | 2607336143 | Slide-In Accu Package 9,6V, 1,5 Ah, NiCd |
| 791 | 2607336143 | Slide-In Accu Package 9,6V, 1,5 Ah, NiCd |
| 793 | 1609200147 | Screwdriver Blade 6 MM |
| 797 | 2601398009 | Carrying Loop |
| 801 | 2605104852 | Housing Section GREEN |
| 802 | 2607022921 | DC motor 9,6-12V |
| 826 | 2606309920 | Drilling Spindle 1/2",BIT-1/4",M6 LEFTHAND THREADS |
| 836 | 2600202025 | Ring |
| 838 | 2606309918 | Splined Shaft |
| 840 | 2606308914 | Toothed Shaft Z= 10/19/63 |
| 852 | 2600499903 | Guide Sleeve |
