Bosch Spare Parts for Router GOF 1300 CE
€1.56
Tax included
Bosch Spare Parts for Router GOF 1300 CE
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Router GOF 1300 CE - 0601613603.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Router GOF 1300 CE
We are BOSCH original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Router GOF 1300 CE - 0601613603.
In the following table, look for the model of the Router and the respective parts of the code.
| GOF 1300 CE/0 601 613 603 | ||
| # | Part Num. | Description |
| 1 | 3605108584 | Motor Housing BLUE |
| 2 | 2610941203 | Field 230V |
| 3 | 2610941202 | Armature 230V |
| 4 | 1607000231 | On-Off Switch |
| 5 | 3604460557 | Power supply cord EU 4,25m 2 x 1,0mm H07 RN-F |
| 6 | 3600703508 | Grommet Ø 9,4 MM |
| 7 | 2601035001 | Cable Clip |
| 8 | 2610907694 | Nameplate |
| 9 | 2610998943 | Reference Plate |
| 12 | 1617328025 | Suppression Filter |
| 13 | 3600905513 | Deep-Groove Ball Bearing |
| 14 | 3600905512 | Deep-Groove Ball Bearing |
| 19 | 2610910566 | Tapping Screw |
| 22 | 2610997096 | Housing |
| 23 | 3600590508 | Air-Deflector Ring |
| 24 | 2916011892 | Plain Washer DIN 9021-B 4,3-ST |
| 25 | 3603300502 | Hex Nut |
| 27 | 2610997099 | Cover Plate |
| 28 | 2610997093 | Rod |
| 29 | 2610997094 | Pointer |
| 30 | 3605500598 | Housing Cover |
| 33 | 3601021510 | Swing-Plate |
| 34 | 3604651502 | Torsion Spring |
| 35 | 3603415556 | Pan head screw M4 |
| 36 | 3603231539 | Knob |
| 37 | 3600209500 | Indicator Ring |
| 38 | 3600100528 | Spring Washer |
| 39 | 3600100527 | Washer |
| 40 | 3600360507 | Adjusting Sleeve |
| 41 | 3600400507 | Locking Piece |
| 42 | 2916690003 | Spring Lock Washer DIN 128-A4-FST |
| 43 | 3602000510 | Locking Lever |
| 44 | 3603450504 | Lock Bolt |
| 45 | 3604651503 | Compression Spring |
| 46 | 2610997191 | Depth-Gauge |
| 47 | 2600590006 | Ratchet Cap |
| 48 | 3916060500 | Spring Washer |
| 49 | 2910641122 | Oval-Head Screw DIN 7985-M4X12-4.8-H |
| 50 | 1613480008 | Wing Screw M6x20 MM |
| 51 | 2610997100 | Compression Spring |
| 52 | 3605133531 | Handle Cover LT |
| 53 | 3605133530 | Handle Cover RT |
| 54 | 2610915161 | Screw |
| 55 | 2916650003 | Spring retaining ring DIN 471-12x1-FSt |
| 56 | 2610912599 | Chip Deflector |
| 57 | 3604613508 | Compression Spring |
| 58 | 3603120502 | Guide Piece |
| 59 | 3605510548 | Bellows |
| 60 | 3601010519 | Cover |
| 61 | 1604477005 | Blade terminal |
| 62 | 3604680502 | Retaining snap ring |
| 63 | 2610991306 | Tapping Screw |
| 64 | 3600210507 | O-Ring |
| 65 | 2610945855 | Cable |
| 66 | 2610945856 | Cable |
| 67 | 3600150501 | Spring Lock Washer |
| 68 | 1607233153 | Control Unit 230V |
| 69 | 2610912471 | Nameplate |
| 70 | 3603410504 | Socket head cap screw |
| 71 | 1903230007 | Ball DIN 5401-4 MM-III-ST |
| 73 | 2610996090 | Set ring |
| 74 | 2603490017 | Torx Oval-Head Screw 3x10 |
| 77 | 3601010521 | Insert |
| 91 | 1610210233 | O-Ring 12,0x2,0 MM |
| 650/1 | 2610992417 | Single-Head Eng. Wrench |
| 731 | 2608570108 | Collet 1/2" |
| 731 | 2608570107 | Collet 12 MM |
| 731 | 2608570106 | Collet 3/8" |
| 731 | 2608570105 | Collet 8 MM |
| 731 | 2608570104 | Collet 1/4" |
| 731 | 2608570103 | Collet 6 MM |
| 731 | 2608570125 | Collet 10 MM |
| 810 | 2610007957 | Carbon-Brush Set |
| 816 | 2610013632 | Brush Holder |
| 821 | 3604652501 | Spiral Spring |
| 826 | 2610997115 | Base |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s BOSCH websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to BOSCH brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GOF 1300 CE 0601613603
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N BOSCH:
- BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
