- On sale!
Annovi & Reverberi Parts for Pressure Washer AR KDB 940
€22.00
Tax included
Annovi & Reverberi Parts for Pressure Washer AR KDB 940
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Pressure Washer Annovi & Reverberi AR KDB 940 - 26777.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi & Reverberi Parts for Pressure Washer AR KDB 940
Annovi & Reverberi Genuine spare parts or replacement parts for to repair Pressure Washer Annovi & Reverberi AR KDB 940 - 26777.
In the following tables, look for the spare part and its respective code.
| Casing | ||
| 1 | 4008610 | Axle |
| 2 | 160311 | Nut |
| 3 | 390311 | Washer |
| 4 | 4000030 | Support |
| 5 | 180432 | Screw |
| 6 | 4000610 | Cover |
| 7 | 380620 | Washer |
| 8 | 4000320 | Wheel |
| 9 | 621780 | Screw |
| 10 | 4000210 | Accessories carrier |
| 11 | 2060200 | Screw |
| 12 | 4000230 | Guard |
| 13 | 4000260 | Accessories carrier |
| 14 | 2100300 | Screw |
| 15 | 4000220 | Support |
| 16 | 4000790 | Nozzle holder |
| 17 | 4000060 | Handle |
| 18 | 50019 | Knob |
| 19 | 4000360 | Screw |
| 20 | 4000860 | Washer |
| 21 | 4000010 | Frame |
| 22 | 4000830 | Screw |
| 23 | 4000350 | Spacer |
| 24 | 4000780 | Spacer |
| 25 | 550331 | Washer |
| 26 | 3000170 | Nut |
| 27 | 4000370 | Screw |
| 28 | 4000240 | Accessories carrier |
| 29 | 1270960 | Detergent hose |
| 30 | 4000750 | Plug |
| 31 | 2000230 | Filter |
| 32 | 4000160 | Tank |
| 33 | 4000180 | Guard |
| 34 | 4000050 | Frame |
| 35 | 4000400 | Foot |
| 36 | 4000770 | Knob |
| Pump | ||
| 1 | 3200110 | Plug |
| 2 | 1200690 | O-ring |
| 3 | 2769050 | Complete valve |
| 4 | 800410 | Screw |
| 5 | 1381550 | Washer |
| 6 | 3200930 | Head |
| 7 | 820440 | Screw |
| 8 | 42712 | Valve kit adjustment |
| 9 | 740290 | O-ring |
| 10 | 1980740 | Plug |
| 11 | 2760220 | Ring |
| 12 | 1342761 | Water seal |
| 13 | 3200160 | Piston guide |
| 14 | 3200690 | Gasket |
| 15 | 3200700 | Ring |
| 16 | 770590 | O-ring |
| 17 | 3200150 | Piston guide |
| 18 | 3200010 | Pump body |
| 19 | 1780490 | Bearing |
| 20 | 1260790 | Ring |
| 21 | 1780550 | Ring |
| 22 | 395081 | O-ring |
| 23 | 3209615 | Oil level assembly |
| 24 | 1122260 | Fitting |
| 25 | 3200070 | Support |
| 26 | 1200430 | Screw |
| 27 | 880130 | Plug |
| 28 | 1260110 | Nut |
| 29 | 1260100 | Washer |
| 30 | 1260120 | Piston |
| 31 | 1260091 | Plate |
| 32 | 1260460 | Oil seal |
| 33 | 480480 | O-ring |
| 34 | 3200060 | Piston |
| 35 | 3200040 | Connecting-rod |
| 36 | 1780050 | Pin |
| 37 | 2760280 | O-ring |
| 38 | 3200030 | Cover |
| 39 | 820510 | O-ring |
| 40 | 880581 | Plug |
| 41 | 3200220 | Screw |
| 44 | 1321190 | Bearing |
| 45 | 3200350 | Shaft |
| 47 | 480671 | Ring |
| 48 | 1320050 | Flange |
| 49 | 1200430 | Screw |
| 50 | 2761380 | Valve |
| 51 | 3209222 | Head assembly |
| 52 | 2841070 | Fitting |
| 53 | 180101 | O-ring |
| 55 | 3201860 | Ring |
| 56 | 2760230 | Fitting |
| 57 | 394280 | O-ring |
| 58 | 2760270 | O-ring |
| 59 | 1470210 | O-ring |
| 60 | 2761550 | Injector |
| 61 | 2760200 | Spring |
| 62 | 2760130 | Shutter |
| 63 | 1460430 | O-ring |
| 64 | 1560520 | Spring |
| 65 | 1250280 | Ball |
| 66 | 480480 | O-ring |
| 67 | 1982520 | Hose tail |
| 68 | 3200560 | Guide |
| 69 | 3200590 | Ball |
| 70 | 770140 | O-ring |
| 71 | 3200550 | Seat |
| 72 | 660191 | O-ring |
| 73 | 1080401 | Ring |
| 74 | 480560 | O-ring |
| 75 | 3200510 | Piston |
| 76 | 3201820 | Pin |
| 77 | 770090 | O-ring |
| 78 | 3200540 | Ring |
| 79 | 394280 | O-ring |
| 80 | 1200690 | O-ring |
| 81 | 3200530 | Piston guide |
| 82 | 1980300 | Nut |
| 83 | 3201340 | Spring |
| 84 | 3200600 | Washer |
| 85 | 3200480 | Knob |
| 86 | 3000170 | Nut |
| 87 | 3200520 | Bushing |
| 88 | 3200500 | Plug |
| 89 | 2840890 | O-ring |
| A | 2186 | Valve kit |
| B | 42475 | Piston kit |
| C | 42474 | Oil seal kit |
| E | 42476 | Water seal kit |
| F | 42470 | Gasket kit |
| G | 2191 | Support ring kit |
| Motor | ||
| 1 | 44941 | Motor |
| 2 | 51796 | Start |
| 3 | 51795 | Filter |
| 4 | 51803 | Coil |
| 5 | 51802 | Carburetor |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
KDB 940 - 26777
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
