Annovi & Reverberi Parts for Pressure Washer AR3590
€10.53
Tax included
Annovi Reverberi Parts for Pressure Washer AR3590
Annovi & Reverberi genuine spare parts or replacements parts for to repair Pressure Washer Blue Clean AR 3590 -24425.Fix Your Pressure Washer Blue Clean AR 3590. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Annovi Reverberi Parts for Pressure Washer AR3590
Fix Your Pressure Washer Blue Clean AR 3590 - 24425. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following tables, look for the spare part and its respective code.
| Pressure Washer Blue Clean AR 3590 - 24425 | ||
| Casing Pag.1 |
||
| # | Part Num. | Description |
| 1 | 3520091 | Casing |
| 2 | 3520520 | Foot |
| 3 | 3520260 | Fairlead |
| 4 | 3520230 | Wheel |
| 5 | 3520240 | Washer |
| 6 | 3520254 | Protection |
| 7 | 3520170 | Tank |
| 8 | 3520180 | Stopper |
| 9 | 3520070 | Knob |
| 10 | 3520081 | Blue Casing |
| 11 | 3520060 | Handle |
| 12 | 3520870 | Cable |
| Pump 3590 Pag.2 |
||
| 1 | 800220 | Screw |
| 2 | 2900430 | Head |
| 3 | 2849051 | Complete Valve |
| 4 | 2200141 | Tenuta Water |
| 5 | 770590 | O-Ring |
| 6 | 2840550 | Bushing |
| 7 | 2840540 | Bushing |
| 8 | 1683500 | Oil Seal |
| 9 | 480560 | O-Ring |
| 10 | 2900500 | Screw |
| 11 | 2900020 | Piston Guide |
| 12 | 2901170 | Spring |
| 13 | 2840530 | Piston |
| 14 | 2840050 | Firm |
| 15 | 2840470 | Screw |
| 16 | 2900350 | Stopper |
| 17 | 740290 | O-Ring |
| 18 | 2840130 | Stopper |
| 19 | 2840150 | Office |
| 20 | 600180 | O-Ring |
| 21 | 2900100 | Junction |
| 22 | 1460430 | O-Ring |
| 23 | 2909005 | Pre-Assembly Spring |
| 24 | 2901070 | Shutter |
| 25 | 2900130 | Junction |
| 26 | 2022201 | Fork |
| 27 | 2029753 | Pre-Assembly Box TSS |
| 28 | 880581 | Stopper |
| 29 | 620301 | Stopper |
| 30 | 1080091 | Spring |
| 31 | 800560 | O-Ring |
| 32 | 2901060 | Injector |
| 33 | 2909137 | Pre-Assembly Head |
| A | 2233 | Kit Valves |
| B | 2313 | Piston Kit |
| C | 42124 | Kit Oil Seals |
| F | 42150 | Gasket Kit |
| Engine 3590 Pag.3 |
||
| 1 | 3040270 | O-Ring |
| 2 | 2900170 | Thrust Bearing |
| 3 | 2900520 | Disk |
| 4 | 1780490 | BALL Bearing |
| 5 | 2320090 | Screw |
| 6 | 2900010 | Pump Housing |
| 7 | 1462400 | Colonnetta |
| 8 | 1460530 | Oil Seal |
| 9 | 1460590 | Bearing |
| 10 | 1460040 | Shield |
| 11 | 1461200 | Oil Seal |
| 12 | 394280 | O-Ring |
| 13 | 1460370 | Fan |
| 14 | 1460340 | Conveyor |
| 15 | 1680960 | Washer |
| 16 | 1460460 | Screw |
| 17 | 3520050 | Pressure Switch |
| 18 | 660170 | O-Ring |
| 19 | 2320131 | Box |
| 20 | 1260490 | Washer |
| 21 | 2020570 | Screw |
| 22 | 2320271 | Cover |
| 23 | 1462900 | Fairlead |
| 24 | 1982590 | Condenser |
| 25 | 2320640 | O-Ring |
| 26 | 44518 | Motor 240V |
| 27 | 24230 | Pre-Assembly Electric |
| 28 | 3523500 | Connector |
| 29 | 1262400 | Washer |
| Boiler 3590 Pag.4 |
||
| 1 | 3520630 | Resistance |
| 2 | 3520620 | Plug |
| 3 | 3520610 | Band |
| 4 | 3520600 | Disk |
| 5 | 3520590 | Disk |
| 6 | 3520330 | Cover |
| 7 | 3520790 | Valve |
| 8 | 3520800 | Fan - Substituited by Kit 3524390 |
| 9 | 3520320 | Box - Substituited by Kit 3524390 |
| 10 | 3520810 | Motor - Substituited by Kit 3524390 |
| 11 | 3520310 | Cover |
| 12 | 3521300 | Boiler |
| 13 | 3520860 | Transformer |
| 14 | 3520770 | Cable |
| 15 | 3520650 | Gasket |
| 16 | 3520660 | Element |
| 17 | 3520670 | Support |
| 18 | 3520680 | Nozzle |
| 19 | 3520690 | Flange |
| 20 | 3520710 | Plate |
| 21 | 3520700 | Electrode |
| 22 | 3520820 | Cover |
| Circuit Cartburante 3590 Pag.5 |
||
| 1 | 3522760 | Pump |
| 2 | 3520730 | Hose |
| 3 | 3520740 | Band |
| 4 | 3520750 | Tube |
| 5 | 3520760 | Filter |
| 6 | 3520750 | Tube |
| Circuit Water 3590 Pag.6 |
||
| 1 | 3521470 | Tube |
| 2 | 3520490 | Fork |
| 3 | 3520420 | Fitting |
| 4 | 3520430 | Piston |
| 5 | 3520440 | Spring |
| 6 | 3520450 | Bushing |
| 7 | 3520460 | O-Ring |
| 8 | 3520510 | Fork |
| 9 | 3520480 | Stopper |
| 10 | 3520500 | O-Ring |
| 11 | 3520540 | Ring |
| 12 | 3520240 | Washer |
| 13 | 3520410 | O-Ring |
| 14 | 3520530 | Fitting |
| 15 | 3520370 | Fitting |
| 16 | 3520360 | Fitting |
| 17 | 3520580 | Washer |
| 18 | 3520570 | Screw |
| 19 | 3520930 | Thermostat |
| 20 | 3520470 | O-Ring |
| Circuit Electric 3590 Pag.7 |
||
| 1 | 3520270 | Knob |
| 2 | 3520280 | Thickness |
| 3 | 3520300 | Element |
| 4 | 3520290 | O-Ring |
| 5 | 3520340 | O-Ring |
| 6 | 3520350 | Fuse Holder |
| 7 | 3520850 | Switch |
| 8 | 3520840 | Card |
| Accessories 3590 Pag.8 |
||
| 1 | 41047 | Gun |
| 2 | 50690 | Lance |
| 3 | 3729 | Nozzle |
| 4 | 40320 | Tank |
| 5 | 3520550 | High Pressure Hose |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Annovi Reverberi 3590 -24425
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N AR:
- AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
