AR Farmer's Division Parts for Pressure PROLINER XPRO 15.15 M

€30.06
Tax included

AR Farmer's Division Parts for Pressure PROLINER XPRO 15.15 M

We supply AR Farmer's Division original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for& Pressure Washer XPRO 15.15 M TSS - 21298 - XPRO 15.15 M TSS RLW - 22244.
ITEM CODE: 1864
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

AR Farmer's Division Parts for Pressure PROLINER XPRO 15.15 M

We supply AR Farmer's Division original spare parts on offer at unbeatable prices, we are a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for& Pressure Washer XPRO 15.15 M TSS - 21298 - XPRO 15.15 M TSS RLW - 22244.

In the following tables, look for the spare part and its respective code.
AR Farmer's Division Parts for Pressure PROLINER XPRO 15.15 M
Bonnet 15.15 M TSS - 21298 Bonnet 15.15 M TSS RLW - 22244
1 2360631 Bonnet Yellow 1 2360631 Bonnet Yellow
2 2360020 Handle 3 2360360 Screw
3 2360360 Screw 5 2360090 Hook
4 2360300 Cork 7 2360100 Support
5 2360090 Hook 8 2100300 Screw
6 2360170 Cork 9 2360270 Knob
7 2360100 Support 10 2000110 Screw
8 2100300 Screw 11 2360040 Bonnet Black
9 2360270 Knob 12 2360370 Gasket
10 2000110 Screw 13 2360340 Standoff
11 2360040 Bonnet Black 14 2360050 Plate
12 2360370 Gasket 15 380240 Nut
13 2360340 Standoff 16 1680930 Cork
14 2360050 Plate 17 2360010 Base
15 380240 Nut 18 2360560 Axle
16 1680930 Cork 19 2360570 Wheel
17 2360010 Base 20 380620 Washer
18 2360560 Axle 21 1470220 Screw
19 2360570 Wheel 22 1682420 Cork
20 380620 Washer 23 2000240 O-Ring
21 1470220 Screw 24 2000230 Filter
22 1682420 Cork 25 1270960 Tube Cleaner
23 2000240 O-Ring 26 2360110 Clamp
24 2000230 Filter 27 2100300 Screw
25 1270960 Tube Cleaner 28 850250 Screw
26 2360110 Clamp 29 1270910 Cork
27 2100300 Screw 30 2360760 Knob
28 850250 Screw 31 2360670 Standoff
29 1270910 Cork 33 2360780 Antivibration
30 2360760 Knob Pump 15.15 M TSS RLW - 22244
31 2360670 Standoff 1 960160 O-Ring
33 2360780 Antivibration 2 1260162 Cork
Pump 15.15 M TSS - 21298 3 1269050 Valve Complete
1 960160 O-Ring 4 880830 O-Ring
2 1260162 Cork 5 620301 Cork
3 1269050 Valve Complete 6 1780140 Ring
4 880830 O-Ring 7 1260220 Watertight
5 620301 Cork 8 1780110 Piston Guide
6 1780140 Ring 9 1780010 Body Pump
7 1260220 Watertight 10 1266740 Oil Seal
8 1780110 Piston Guide 11 1260790 Ring
9 1780010 Body Pump 12 1780550 Ring
10 1266740 Oil Seal 13 1780490 Bearing
11 1260790 Ring 14 1682420 Cork
12 1780550 Ring 15 1780050 Plug
13 1780490 Bearing 16 1780510 O-Ring
14 1682420 Cork 17 1200430 Screw
15 1780050 Plug 18 1789010 Cover
16 1780510 O-Ring 19 1780040 Piston Rod
17 1200430 Screw 20 1780060 Piston
18 1789010 Cover 21 480480 O-Ring
19 1780040 Piston Rod 22 1260091 Disk
20 1780060 Piston 23 1780080 Piston
21 480480 O-Ring 24 1260100 Washer
22 1260091 Disk 25 1260110 Nut
23 1780080 Piston 27 740290 O-Ring
24 1260100 Washer 28 1980740 Cork
25 1260110 Nut 30 1260460 Oil Seal
27 740290 O-Ring 31 1780120 Piston Guide
28 1980740 Cork 32 770260 O-Ring
30 1260460 Oil Seal 33 1260450 Watertight
31 1780120 Piston Guide 34 820361 Cork
32 770260 O-Ring 35 180101 O-Ring
33 1260450 Watertight 36 1780020 Head
34 820361 Cork 37 1381550 Washer
35 180101 O-Ring 38 1322730 Screw
36 1780020 Head 40 1321190 Bearing
37 1381550 Washer 41 1321080 Ring
38 1322730 Screw 44 180030 Screw
40 1321190 Bearing 45 1780180 Shaft
41 1321080 Ring 46 1380520 Tab
44 180030 Screw 47 1260750 Ring
45 1780180 Shaft 57 1789202 Pre-Assembly Head
46 1380520 Tab 58 3232 Manometer
47 1260750 Ring 59 7906 Pump Pre-Assembly
57 1789202 Pre-Assembly Head A 1864 Valve Kit
58 3232 Manometer B 2746 Piston Kit
59 7906 Pump Pre-Assembly C 2786 Oil Seals Kit
A 1864 Valve Kit E 2747 Kit Held Water
B 2746 Piston Kit G 2745 Kit Support Rings
C 2786 Oil Seals Kit Valve 15.15 M TSS RLW - 22244
E 2747 Kit Held Water 2 392840 Screw
G 2745 Kit Support Rings 3 1980300 Nut
Valve 15.15 M TSS - 21298 4 2500540 Insert
2 392840 Screw 5 1980220 Disk
3 1980300 Nut 6 1271070 Spring
4 2500540 Insert 7 1080041 Piston
5 1980220 Disk 8 1080070 Plug
6 1271070 Spring 9 1080401 Ring
7 1080041 Piston 10 1080250 O-Ring
8 1080070 Plug 11 2500550 Cotter Pin
9 1080401 Ring 12 1980210 Piston Guide
10 1080250 O-Ring 13 740290 O-Ring
11 2500550 Cotter Pin 14 800560 O-Ring
12 1980210 Piston Guide 15 880830 O-Ring
13 740290 O-Ring 16 1271170 Ring
14 800560 O-Ring 17 1080190 O-Ring
15 880830 O-Ring 18 1271160 Piston
16 1271170 Ring 19 2460420 Office
17 1080190 O-Ring 20 1080250 O-Ring
18 1271160 Piston 21 1540272 Screw
19 2460420 Office 22 390080 O-Ring
20 1080250 O-Ring 23 1540660 Valve Body
21 1540272 Screw 24 1140450 O-Ring
22 390080 O-Ring 25 1460430 O-Ring
23 1540660 Valve Body 26 1540170 Shutter
24 1140450 O-Ring 27 1080091 Spring
25 1460430 O-Ring 28 394280 O-Ring
26 1540170 Shutter 29 1560660 Ring
27 1080091 Spring 30 2360650 Knob
28 394280 O-Ring 31 480560 O-Ring
29 1560660 Ring 32 800560 O-Ring
30 2360650 Knob 34 1560650 Hose
31 480560 O-Ring 35 480480 O-Ring
32 800560 O-Ring 36 1250280 Ball
34 1560650 Hose 37 1560520 Spring
35 480480 O-Ring 38 1540580 Junction
36 1250280 Ball 39 1540300 Nut
37 1560520 Spring 41 1540280 Collector
38 1540580 Junction 42 1540630 O-Ring
39 1540300 Nut 44 880270 O-Ring
41 1540280 Collector 45 2260420 Screw
42 1540630 O-Ring 46 480440 O-Ring
44 880270 O-Ring 47 1560900 Junction
45 2260420 Screw 48 40393 Junction
46 480440 O-Ring 50 1340260 Filter
47 1560900 Junction 52 1981190 Screw
48 40393 Junction 53 1260820 O-Ring
50 1340260 Filter 54 1540881 Piston
52 1981190 Screw 55 1981320 Spring
53 1260820 O-Ring 56 2022201 Fork
54 1540881 Piston 57 2029758 Pre-Assembly Box TSS
55 1981320 Spring 58 660190 O-Ring
56 2022201 Fork 59 880840 O-Ring
57 2029758 Pre-Assembly Box TSS 60 1540870 Cork
58 660190 O-Ring 61 22078 Valve Complete
59 880840 O-Ring 62 1123960 Junction
60 1540870 Cork 63 1569210 Pre-Assembly IDR
61 22078 Valve Complete 64 1120681 O-Ring
62 1123960 Junction 65 42458 Kit TSS
63 1569210 Pre-Assembly IDR 66 1080192 O-Ring
64 1120681 O-Ring F 42451 Seal Kit
65 42458 Kit TSS Engine 15.15 M TSS RLW - 22244
66 1080192 O-Ring 1 1700110 O-Ring
F 42451 Seal Kit 2 1700080 Plate
Engine 15.15 M TSS - 21298 3 1940410 O-Ring
1 1700110 O-Ring 4 1700740 Mini-Contactor
2 1700080 Plate 5 1261570 Screw
3 1940410 O-Ring 6 2360590 Card
4 1700740 Mini-Contactor 7 1460460 Screw
5 1261570 Screw 8 1700590 Nut
6 2360590 Card 9 2180650 Cable
7 1460460 Screw 10 1700930 Cover
8 1700590 Nut 11 2360730 Switch
9 2180650 Cable 12 880270 O-Ring
10 1700930 Cover 13 1382380 Strain Relief
11 2360730 Switch 14 1261560 Screw
12 880270 O-Ring 15 1080190 O-Ring
13 1382380 Strain Relief 16 1700640 Cable
14 1261560 Screw 17 44121 Engine
15 1080190 O-Ring 18 1341140 Gasket
16 1700640 Cable RLW 15.15 M TSS RLW - 22244
17 44121 Engine 1 40646 Pre Mounting Hose Reel
18 1341140 Gasket 2 40681 Hose Pre-Assembly
Accessories 15.15 M TSS - 21298 3 2360360 Screw
1 40925 Gun 4 2360150 Lever
2 40115 Lance + Nozle 5 650500 Ring
3 3095 Nozzle 6 2360190 Disk
4 40541 Lance + Head Without Nozzle 7 2360160 Stirrup
5 40958 Lance + Head 8 2360280 Pin
6 2000770 O-Ring 9 1681280 Screw
7 1271960 High Pressure Tube 10 2360230 Disk
11 380420 Ring
12 2500390 High Pressure Tube
13 2360210 Pin
14 390080 O-Ring
15 2360220 Junction
16 2360320 Ring
17 2360080 Stirrup
18 820510 O-Ring
19 2360310 Junction
20 2360250 High Pressure Tube
21 2360020 Handle
Accessories 15.15 M TSS RLW - 22244
1 40925 Gun
2 40115 Lance + Nozle
3 3095 Nozzle
4 40541 Lance + Nozle Without Nozzle
5 40958 Lance + Nozle
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
XPRO 15.15 M 21298 - RLW 22244
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N AR:
AR S/N START WITH ( 1 or 2 ) and have 5 DIGITS
New

Download

Diagram AR Farmer's 15.15 M TSS

Diagram AR Farmer's 15.15 M TSS

Download (539.92KB)

Diagram AR Farmer's 15.15 M RLW

Diagram AR Farmer's 15.15 M RLW

Download (615.55KB)
