Parts for Pressure Washer ARSG PROLINER RS 11.20 TSS - 23145
€22.01
Tax included
Parts for Pressure Washer ARSG PROLINER RS 11.20 TSS - 23145
Genuine replacement parts Annovi Reverberi Farmer's Division for to fix damaged parts, for Pressure Washer RS 11.20 TSS - 23145.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Parts for Pressure Washer ARSG PROLINER RS 11.20 TSS - 23145
Genuine replacement parts Annovi Reverberi Farmer's Division for to fix damaged parts, for Pressure Washer RS 11.20 TSS - 23145.
In the following tables, look for the spare part and its respective code.
| Casing RS 11.20 TSS - 23145 Pag.1 |
||
| # | Part Num. | Description |
| 1 | 2500371 | Yellow Casing |
| 3 | 2500310 | Knob |
| 4 | 2500050 | Hook |
| 5 | 2500380 | Bowl |
| 6 | 1680880 | Washer |
| 7 | 2500320 | Wheel |
| 9 | 2500410 | Plate |
| 10 | 850370 | Screw |
| 11 | 2100300 | Screw |
| 12 | 2600100 | Strain Relief |
| 13 | 2100300 | Screw |
| 14 | 2500020 | Handle |
| 15 | 2500130 | Grommet |
| 16 | 880280 | Screw |
| 17 | 2180300 | Washer |
| 18 | 2500120 | Axle |
| 19 | 2500110 | Tank |
| 20 | 2500010 | Base |
| 21 | 42113 | Pre-Assembly Plug |
| 22 | 1261560 | Screw |
| 23 | 2500440 | Protection |
| 24 | 2000110 | Screw |
| 25 | 40741 | Manometer |
| 26 | 2500330 | Tube Cleaner |
| 27 | 2500330 | Tube Cleaner |
| 28 | 2000230 | Filter |
| 29 | 2509000 | Pre-Assembly Base |
| Pump RS 11.20 TSS - 23145 Pag.2 |
||
| 1 | 1980300 | Nut |
| 2 | 1980470 | Screw |
| 3 | 2760700 | Insert |
| 4 | 1980220 | Disk |
| 5 | 2760410 | Spring |
| 6 | 2760400 | Piston |
| 7 | 2260100 | O-Ring |
| 8 | 660190 | O-Ring |
| 9 | 2760210 | Ring |
| 10 | 2760570 | Guide |
| 11 | 1200690 | O-Ring |
| 12 | 394280 | O-Ring |
| 13 | 2260070 | Shutter |
| 14 | 2760090 | Venue |
| 15 | 770140 | O-Ring |
| 16 | 1982520 | Hose |
| 17 | 480480 | O-Ring |
| 18 | 1250280 | Sphere |
| 19 | 1560520 | Spring |
| 20 | 2760230 | Junction |
| 21 | 2760270 | O-Ring |
| 22 | 1470210 | O-Ring |
| 23 | 2760120 | Insert |
| 24 | 2760200 | Spring |
| 25 | 2760130 | Shutter |
| 26 | 1460430 | O-Ring |
| 27 | 801080 | Screw |
| 28 | 1381550 | Washer |
| 29 | 2760500 | Top |
| 33 | 2760260 | Stopper |
| 34 | 2760180 | Stopper |
| 35 | 2769050 | Complete Valve |
| 36 | 1780140 | Ring |
| 37 | 1260220 | Watertight |
| 39 | 1320351 | Piston Guide |
| 40 | 1260420 | O-Ring |
| 41 | 1260450 | Watertight |
| 42 | 480440 | O-Ring |
| 43 | 2760600 | Spacer |
| 44 | 2460170 | Oil Seal |
| 45 | 2760460 | Pump Housing |
| 46 | 1266740 | Oil Seal |
| 47 | 1260790 | Ring |
| 48 | 1780550 | Ring |
| 49 | 1780490 | Bearing |
| 51 | 2760450 | Piston |
| 52 | 1780050 | Thorn |
| 53 | 1780040 | Piston Rod |
| 54 | 2760280 | O-Ring |
| 55 | 802190 | Screw |
| 56 | 2760110 | Cover |
| 57 | 2760520 | Shaft |
| 58 | 1321190 | Bearing |
| 59 | 1321080 | Ring |
| 60 | 1260750 | Ring |
| 61 | 650250 | Tongue |
| 62 | 2769208 | Pre-Assembly Head |
| 63 | 1080190 | O-Ring |
| 64 | 1981320 | Spring |
| 65 | 660190 | O-Ring |
| 66 | 1540881 | Piston |
| 67 | 880840 | O-Ring |
| 68 | 1540870 | Cork |
| 69 | 1260820 | O-Ring |
| 70 | 2022201 | Fork |
| 71 | 2029758 | Pre-Assembly Box TSS |
| 72 | 1981190 | Screw |
| 73 | 2760560 | Cork |
| 74 | 1340260 | Filter |
| 75 | 2500490 | Junction |
| 76 | 480440 | O-Ring |
| 77 | 1122260 | Junction |
| 78 | 2500210 | Knob |
| 79 | 740290 | O-Ring |
| 80 | 1980740 | Cork |
| 81 | 40393 | Junction |
| 82 | 2500550 | Cotter Pin |
| 83 | 23204 | Pre-Installing Pump |
| 84 | 42458 | Kit TSS |
| A | 2186 | Valve Kit |
| B | 42154 | Piston Kit |
| C | 42194 | Oil Seals Kit |
| E | 42155 | Kit Held Water |
| F | 2190 | Seal Kit |
| G | 2745 | Kit Support Rings |
| Motor RS 11.20 TSS - 23145 Pag.3 |
||
| 1 | 50068 | Gasket |
| 2 | 1700080 | Plate |
| 3 | 1940410 | O-Ring |
| 4 | 1700740 | Mini-Contactor |
| 5 | 1261570 | Screw |
| 6 | 1460460 | Screw |
| 7 | 2320280 | Switch |
| 8 | 2180650 | Cable |
| 9 | 1261560 | Screw |
| 10 | 1080190 | O-Ring |
| 11 | 1700930 | Cover |
| 12 | 1700590 | Nut |
| 13 | 880270 | O-Ring |
| 14 | 1382380 | Strain Relief |
| 15 | 1700640 | Cable |
| 16 | 44079 | Engine |
| Accessories RS 11.20 TSS - 23145 Pag.4 |
||
| 1 | 41046 | Gun |
| 2 | 40551 | Lance + Nozle |
| 3 | 1271960 | High Pressure Tube |
| 4 | 2000770 | O-Ring |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Annovi & Reverberi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Annovi & Reverberi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
