Ama Spare Parts for Self-Propelled Lawnmower LT 46E
We have the original AMA Garden parts and tool repair help you need to get your tools running like new again.
Fix Your Self-Propelled Lawnmower LT 46E - 84899. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| AMA GARDEN Self-Propelled Lawnmower LT 46E - 84899 | ||
| Upper Handle LT 46E - 84899 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 88566 | Foam Rubber Handle Grip |
| 2 | 84957 | Stop Lever |
| 3 | 84958 | Self-Propelled Lever |
| 4 | 84959 | Upper Handle |
| 5 | 88568 | Rope Guide |
| 6 | 88564 | Cap Nut |
| 7 | 84822 | Brake Cable Assy plate |
| 10 | 84970 | Plastic Stopper |
| 11 | 84971 | Brake Cable |
| 12 | 84836 | Self Propelled Cable |
| 13 | 88234 | Quick Fix Knob |
| 20 | 84973 | Lower Handrail |
| 21 | 88247 | Fastener |
| 23 | 88571 | Head Square Bolts |
| 25 | 84972 | Triangle Knob |
| Chassis Pag.2 | ||
| 1 | 89446 | Deck Welding Assy. |
| 3 | 89447 | Inlet |
| 4 | 89448 | Pipe Connector Nut |
| 6 | 88572 | Right Handle Bracket |
| 7 | 88573 | Left Handle Bracket |
| 10 | 88574 | Height Adjustment Board |
| 12 | 84938 | Rear Drive right Bracket |
| 13 | 84939 | Rear Drive Left Bracket |
| 15 | 73221 | Pull Spring For Pull Rod |
| 16 | 89389 | Height Adjustment Pull Rod |
| 17 | 88625 | R Type Pin |
| 20 | 84842 | Mulching Cap |
| 21 | T375 | Petrol Engine |
| 22 | 89449 | Bracket Plate For Defelctor |
| 23 | 84849 | Mulching Board |
| 24 | 84850 | Side Discharge Cover |
| 25 | 88583 | Mulch Shaft |
| 26 | 88584 | Mulch Board Spring |
| Front Axle Pag.3 | ||
| 1 | 88581 | Front Drive Assy. |
| 2 | 76158 | 7" Front Wheel Assy. |
| 3 | 73848 | Wheel Punch Bearing |
| 4 | 89450 | Self-Locking Nut |
| 5 | 76157 | Outer Cover Of Hub |
| 6 | 88580 | Inner Cover Of Hub |
| Rear Axle Pag.4 | ||
| 0 | 89393 | Rear Drive Assy. |
| 1 | 73201 | Height Adjustment Ball |
| 2 | 89452 | Selfpropelled Assy. |
| 3 | 84984 | Bush |
| 4 | 84985 | Bearing |
| 5 | 88633 | Gasket |
| 6 | 89453 | Inner Cover Of Hub |
| 10 | 84824 | Ratchet Wheel L |
| 11 | 84825 | Ratchet Wheel R |
| 13 | 89392 | Wheel Assy. |
| 14 | 73848 | Wheel Punch Bearing |
| 15 | 89450 | Self-Locking Nut |
| 16 | 89454 | Outer Cover of Hub |
| 17 | 84845 | V Belt |
| 20 | 89457 | Spring |
| Grass Box Pag.5 | ||
| 1 | 84840 | Frame |
| 2 | 84838 | Grass Catcher Cover Substituted by --> 9258 |
| 3 | 84839 | Filter Plate |
| 4 | 84841 | Fabric Grass Bag |
| 5 | 84837 | Rear Discharge Cover |
| 6 | 88419 | Shaft For Rear Discharge Cover |
| 7 | 84987 | Cover Spring |
| 9 | 88575 | Cover Dust Proof Board |
| Blade Pag.6 | ||
| 1 | 84844 | Blade Adapter Assy |
| 2 | 84843 | Double-Edge Blade |
| 3 | 73223 | Blade Washer |
| 4 | 84815 | Inch Hex Flange Bolts |
| 8 | 84846 | Belt Cover |
| Engine Pag.7 | ||
| 2 | RMGP65010210000 | Oil Seal 25 x 38 x 7 |
| 3 | RMGP65010201000 | Crankcase Cover |
| 7 | RMGV410001000 | Gear Shaft of speed limit |
| 9 | RMGP65010203000 | Gear Shaft Assy |
| 11 | RMGP65010202000 | Sliding Sleeve |
| 12 | RMGP65010206000 | Gear Shaft Hold-down Plate |
| 14 | RMGV410008000 | Seal Gasket of Crankcase |
| 15 | RMGP65080300000 | Pin |
| 16 | RMGP65080100000 | Camshaft Assy |
| 17 | RMGV41B100000 | Crankshaft Assy |
| 18 | RMGP65010402000 | Connecting Rod Assy |
| 19 | Ball Bearing 6205 | |
| 20 | Oil Seal 22 x 35 x 7 | |
| 21 | RMGV41D100000 | Crankcase Assy |
| 22 | RMGP650106060004 | Speed Regulator Pull Spring |
| 23 | RMGP70B010600000 | Speed Regulator |
| 25 | RMGP65010603003 | Speed Regulator Rocker |
| 27 | RMGP65010603301 | Handspike of Valve |
| 28 | RMGP65010601000 | Spring of Valve |
| 30 | RMGP65010112000 | Oil Seal 6 x 11 x 4 |
| 31 | RMGP65010105000 | Speed Regulator Rocker Spindle |
| 32 | RMGP65050600000 | Waste Pipe |
| 33 | RMGV450002000 | Front Bracket of Fuel Tank |
| 35 | RMGV470001000 | Back Guide Board |
| 34 | RMGV450003000 | Middle Bracket of Fuel Tank |
| 38 | Oil Pipe | |
| 40 | RMGP65050500000 | Filtering Net |
| 44 | RMGV450006000 | Fuel Tank |
| 45 | RMGP65050102000 | Seal Gasket of Fuel Tank Cap |
| 46 | RMGP65050106000 | Sponge of Fuel Tank Cap |
| 47 | RMGP65050101000 | Fuel Tank Cap - RDY0019 - Before 2014 |
| 48 | RMGP65010104000 | Lubricate Filtering Net |
| 49 | RMGP65010108000 | Valve Element of Respirator Cover |
| 50 | RMGP65010109000 | Gasket of Respirator Cover |
| 51 | RMGP65010107000 | Respirator Cover Plate Assy |
| 52 | RMGV47A100000 | Flywheel Assy |
| 53 | RMGP65070402000 | Fan |
| 54 | RMGP65070200000 | Start-up Hub |
| 55 | Nut M14 x 1.5 | |
| 56 | RMGP65070401000 | Blower Housing |
| 57 | RMGV47B100000 | Recoil Start Assy |
| 58 | RMGP65070403000 | Blower Housing Bush |
| 61 | RMGP65070302000 | Ignition Assy |
| 64 | RMGV41F100000 | Detent Assy |
| 67 | RMGP65060300000 | Muffler Cover Assy |
| 68 | RMGP65060000000 | Muffler Assy |
| 69 | RMGP65060200000 | Heat Insulation Gasket of Muffler |
| 70 | RMGV42A100000 | Gasket of Cylinder Head |
| 72 | RMGP65080600000 | Intake Valve |
| 73 | RMGP65080700000 | Exhaust Valve |
| 74 | RMGP70B010205000 | Cylinder Head Assy |
| 77 | RMGP65080800000 | Spring of Valve |
| 78 | RMGP65080900000 | Spring Coil of Intake Valve |
| 79 | RMGP65020300000 | Gasket of Cylinder Head Cover |
| 80 | RMGP65020100001 | Cylinder Head Cover I |
| 81 | RMGP65020100000 | Cylinder Head Cover II |
| 83 | RMGP65080204000 | Combined Nut |
| 84 | RMGP65080203000 | Adjust Nut of Valve |
| 85 | RMGP65080200000 | Rocker of Valve |
| 86 | RMGP65080202000 | Rocker Support Bolt of Valve |
| 87 | RMGP65080500000 | Guide Board of Handspike |
| 88 | RMGP65080400000 | Handspike |
| 91 | RMGP65030200000 | Paper Gasket I of Carburetor |
| 92 | RMGP65030400000 | Air Inlet Pipe |
| 93 | RMGP65030300000 | Paper Gasket II of Carburetor |
| 94 | RMGV43A100000 | Carburetor Assy |
| 95 | RMGP65030500000 | Steel Gasket |
| 96 | RMGP65040102002 | Air Filter Pedestal |
| 97 | RMGP65040103000 | Exhaust Gas Cover Board |
| 99 | RMGV440001000 | Air Filter Element |
| 100 | RMGP65040106000 | Sponge Filter Element |
| 101 | RMGP65040101000 | Air Filter Upper Cover |
| 102 | RMGP65051000001 | Primer Button |
| 103 | RMGV410002000 | Piston Ring I |
| 104 | RMGV410003000 | Piston Ring II |
| 105 | RMGV410004000 | Guide Rail |
| 106 | RMGV410005000 | Bushing Ring |
| 107 | RMGV410006000 | Piston Pin |
| 108 | RMGV410007000 | Piston |
| 109 | RMGP65010401700 | Circlip of Piston Pin |
| 110 | RMGP65010500000 | Lubricating Setting |
