Loncin Spare Parts for Engine 196 cc 6.5 Hp LC1P170FAD
€35.80
Tax included
Loncin Spare Parts for Engine 196 cc 6.5 Hp LC1P170FAD
Ama genuine spare parts or replacements parts for to repair Engine Loncin 196 cc 6.5 Hp LC1P170FAD x Lawn Tractor RIDER ARR62L - 84890.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Loncin Spare Parts for Engine 196 cc 6.5 Hp LC1P170FAD
Ama genuine spare parts or replacements parts for to repair Engine Loncin 196 cc 6.5 Hp LC1P170FAD x Lawn Tractor RIDER ARR62L - 84890.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| Engine Loncin LC1P170FAD x Lawn Tractor RIDER ARR62L - 84890 |
||
| CYLINDER HEAD | ||
| -------------> | Lawn Tractor RIDER ARR62L - 84890 | |
| # | Part Num. | Description |
| 1 | 380020070-0001 | Hexagon shaft shoulder bolt |
| 2 | 120230083-0001 | Cylinder head cover |
| 3 | 120250032-0001 | Gasket for cylinder head cover |
| 4 | 270960014-0001 | Spark plug |
| 5 | 380140338-0001 | Hexagon bolt with flange |
| 6 | 120080279-0001 | Cylinder head |
| 7 | 380180101-0001 | Stud |
| 8 | 380180093-0001 | Stud |
| 9 | 120150087-0001 | Gasket for cylinder head |
| 10 | 380600117-0001 | Location pin |
| FLYWHEEL | ||
| 1 | 270920335-0001 | Coil assy, Ignition |
| 2 | 380140086-0002 | Hexagon bolt with flange |
| 3 | 270020128-0001 | Flywheel Comp |
| 4 | 160180015-0001 | Impeller |
| 5 | 193590005-0001 | Starting disc |
| 6 | 380370051-0001 | Hexagon nut with flange |
| 7 | 380600121-0001 | Location pin |
| 8 | 270360051-0001 | Components of starting motor |
| 9 | 380140024-0006 | Hexagon bolt with flange |
| 10 | 270370034-0001 | Wire bundle of starting motor |
| 11 | 270190036-0001 | Components of charging current |
| 12 | 270280012-0001 | Tension disc for wire bundle |
| AIR CLEANER | ||
| 1 | 180020763-0001 | Air filter |
| Starter Assy | ||
| 1 | 380370066-0001 | Hexagon nut with flange |
| 2 | 380310135-0001 | Tapping screw |
| 3 | 193490062-0001 | Manual starting assembly |
| 4 | 160210102-0001 | Fan cover comp. |
| GOVERNOR | ||
| 1 | 171650005-0001 | Choke valve pull rod |
| 2 | 171610015-0001 | Throttle return spring |
| 3 | 171590015-0001 | Throttle rod |
| 4 | 171680076-0001 | Throttle handle combination |
| 5 | 171600033-0001 | Governing spring |
| 6 | 380140067-0003 | Hexagon bolt with flange |
| 7 | 380250002-0001 | Square head set screw with flat point |
| 8 | 171620016-0003 | Speed regulating bracket |
| 9 | 380370048-0001 | Hexagon nut with flange |
| CARBURETOR | ||
| 1 | 170430157-0001 | Carburetor gasket |
| 2 | 170440056-0001 | Heat insulating pad for carburetor |
| 3 | 170430147-0001 | Carburetor gasket |
| 4 | 170450001-0001 | Heat insulating plate for carburetor |
| 5 | 170020910-0002 | Carburetor |
| 6 | 170430067-0001 | Carburetor gasket |
| FUEL TANK | ||
| 1 | 170870094-0001 | Tank cover |
| 2 | 380370048-0001 | Hexagon nut with flange |
| 3 | 380450444-0002 | Flat washer |
| 4 | 170490149-0001 | Tank |
| 5 | 380140013-0005 | Hexagon bolt with flange |
| 6 | 380850003-0001 | Stay stud |
| 7 | 170010017-0001 | Fuel filter |
| 8 | 380930025-0001 | Location wire nail |
| 9 | 380750202-0001 | Oil tube |
| 10 | 380950190-0001 | Pipe clip |
| VALVE | ||
| 1 | 140450022-0001 | Valve rocker combination |
| 2 | 140320001-0001 | Valve adjustment cap |
| 3 | 140380017-0001 | Retainer, valve spring |
| 4 | 140340022-0001 | Inner spring of valve |
| 5 | 500550029-0001 | Valve Kit |
| 6 | 140710004-0003 | Plate, push rod guide |
| 7 | 140670032-0001 | Push rod |
| 8 | 140690002-0001 | Lifter, Valve |
| 9 | 140020048-0001 | Camshaft assy |
| 10 | 380450534-0001 | Flat washer |
| CRANKSHAFT | ||
| 1 | 130070142-0001 | Piston ring combination |
| 2 | 130030160-0001 | Piston |
| 3 | 130060031-0001 | Piston pin |
| 4 | 380560056-0001 | Steel cable baffle ring |
| 5 | 130150052-0001 | Connecting rod |
| 6 | 380630137-0002 | Bearing |
| 7 | 130290316-0001 | Crankshaft |
| 8 | 380450518-0001 | Flat washer |
| 9 | 380620118-0001 | Key |
| VALVE | ||
| 1 | 140300065-T381 | Valve,In. |
| 2 | 140310064-T381 | Valve,Ex. |
| 3 | 140360010-T110 | Seat,Valve Spring |
| 4 | 140400012-T110 | Seal,Valve Stem |
| 5 | 140340025-T11D | Spring,Valve |
| 6 | 140380021-T11D | Retainer,Ex.Valve Spring |
| 7 | 140390015-T11D | Valve Keeper |
| 8 | 140460039-T381 | Rocker Arm |
| 9 | 140490012-T040 | Pivot Rocker Arm |
| 10 | 140470001-T040 | Nut,Pivot Adjusting |
| 11 | 140480012-T040 | Bolt Povit |
| 12 | 140710011-T381 | Plate,Assy |
| 13 | 140670030-T370 | Rod Push |
| 14 | 140690004-T110 | Lifter,Valve |
| 15 | 140020055-T370 | Camshaft |
| 16 | 140450041-T381 | Valve Rocker Assy |
| CRANKSHAFT COVER | ||
| 1 | 110820026-0001 | Crankcase cover |
| 2 | 380140148-0005 | Hexagon bolt with flange |
| 3 | 380650347-0001 | Oil seal |
| 4 | 171640003-0001 | Governor gear pressing plate |
| 5 | 380600121-0001 | Location pin |
| 6 | 380140077-0005 | Hexagon bolt with flange |
| 7 | 174280001-0001 | Components of governor gear |
| 8 | 380600120-0001 | Location pin |
| 9 | 110830057-0001 | Crankcase cover gasket |
| 10 | 380140100-0003 | Hexagon bolt with flange |
| 11 | 110690016-0002 | Oil rule combination |
| 12 | 110260025-0001 | Sealing plug screw |
| 13 | 380450514-0001 | Flat washer |
| 14 | 150570002-0001 | Engine oil return block |
| CRANKCASE | ||
| 1 | 110810194-0001 | Crank Case |
| 2 | 150290026-0001 | Engine oil Strainer |
| 3 | 380940346-0001 | Cable cleat |
| 4 | 380850027-0001 | Stay stud |
| 5 | 380850028-0001 | Stay stud |
| 6 | 380650335-0001 | Oil seal |
| 7 | 140250006-0001 | Leaf valve |
| 8 | 380140037-0003 | Hexagon bolt with flange |
| 9 | 380140441-0001 | Hexagon bolt with flange |
| 10 | 110840011-0001 | Cap,Breather chamber |
| 11 | 110850011-0001 | Packing, Breather chamber |
| 12 | 160200037-0001 | Plate |
| 13 | 380821590-0001 | Bushing |
| 14 | 380140086-0002 | Hexagon bolt with flange |
| 15 | 380740465-0001 | Breather tube |
| 16 | 171630010-0001 | Speed regulating arm |
| 17 | 380450527-0001 | Flat washer |
| 18 | 380650338-0001 | Oil seal |
| 19 | 381350004-0001 | Pin clip |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Ama websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Ama brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
