Alpina Lawnmower AL5 51 SAQ Parts
€22.20
Tax included
Alpina Lawnmower AL5 51 SAQ Spare Parts
For the maintenance and repair of your Self-propelled Lawnmower AL5 51 SAQ - 2L0536844/A21 - 2021, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Lawnmower AL5 51 SAQ Spare Parts
For the maintenance and repair of your Self-propelled Lawnmower AL5 51 SAQ - 2L0536844/A21 - 2021, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.
In the following table, look for the model of the Petrol Lawn Mower and the respective parts of the code.
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Deck pag.1 | ||
| # | Part Num. | Description |
| 1 | 381005195/2 | Bracket-Rh |
| 2 | 381005197/2 | Left Bracket |
| 3 | 112727802/0 | Screw |
| 4 | 322545213/0 | Plate |
| 5 | 322600310/0 | Rear door |
| 6 | 322108329/0 | Rear Conveyor |
| 7 | 112728697/0 | Screw |
| 8 | 322060250/1 | Belt Protection |
| 9 | 112728903/0 | Screw |
| 10 | 322140251/0 | Mulching Deflector |
| 11 | 381005618/0 | Grey Deck |
| 12 | 322820077/1 | Cap |
| 13 | 119035000/0 | Or Ring |
| 14 | 112728450/0 | Screw |
| 15 | 322034002/0 | Washing Connection |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Height Adjusting pag.2 | ||
| 1 | 381302947/0 | Axle, Front Wheels |
| 2 | 322785305/1 | Support |
| 3 | 112728697/0 | Screw |
| 4 | 322869735/0 | Rod, Height Adjustment |
| 5 | 122519823/0 | Pin |
| 6 | 112436050/0 | Plate |
| 7 | 122450494/0 | Spring |
| 8 | 381302849/0 | Rear Wheel Axle |
| 8 | 381302849/1 | Rear Wheel Axle |
| 9 | 381003458/0 | Wheels Rear Adj. Lever |
| 9 | 381003458/1 | Wheels Rear Adj. Lever |
| 10 | 122534131/0 | Pin |
| 11 | 122446192/0 | Spring |
| 12 | 112154510/0 | Nut |
| 13 | 322785500/0 | Support |
| 14 | 181003134/0 | Gear Box |
| 15 | 122753000/0 | Pin |
| 16 | 122570133/0 | Right Pinion |
| 17 | 122570134/0 | Left Pinion |
| 18 | 112608600/0 | Seeger |
| 19 | 322042067/0 | Bushing |
| 20 | 112521371/0 | Washer |
| 22 | 1111-9296-01 | Belt |
| 22 | 135064196/0 | Belt |
| 23 | 122430254/0 | Spring |
| 24 | 322778473/1 | Bracket |
| 25 | 112728699/0 | Screw |
| 28 | 112728697/0 | Screw |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Mask pag.3 | ||
| 1 | 112735410/0 | Screw |
| 2 | 322226313/0 | Mask, Black |
| 3 | 322393780/0 | Front Handle |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Handle, Lower Part pag.4 | ||
| 1 | 381006785/0 | Handle, Lower Part Black |
| 2 | 112155000/0 | Nut |
| 3 | 112521350/0 | Washer |
| 4 | 112369500/0 | Elastic Washer |
| 5 | 112760605/0 | Screw |
| 6 | 381008691/0 | Outfit, Screws |
| 7 | 133320504/0 | Fairlead |
| 8 | 118390020/0 | Conduit Clip |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Handle, Upper Part pag.5 | ||
| 1 | 381006739/2 | Handle,Black Upper Part without sponge handgrip |
| 1 | 381006745/3 | Handle,Black Upper Part with sponge handgrip |
| 2 | 122430313/0 | Guide Spring |
| 3 | 112521330/0 | Washer |
| 4 | 112154510/0 | Nut |
| 5 | 118390020/0 | Conduit Clip |
| 6 | 181003363/1 | Lever, Engine Brake Black |
| 7 | 181030087/0 | Cable, Thread Engine Brake |
| 8 | 112727783/0 | Screw |
| 9 | 112154510/0 | Nut |
| 10 | 181003364/0 | Drive Control Lever |
| 11 | 381030139/0 | Cable Rear Drive |
| 12 | 322551640/0 | Cable Holder |
| 12 | 322551685/0 | Cable Holder ø22 |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Wheel and Hub Cap pag.6 | ||
| 1 | 381007483/1 | Wheel Ø 200 |
| 1 | 381007483/2 | Wheel Ø 200 |
| 2 | 119216035/0 | Bearing |
| 3 | 112521350/0 | Washer |
| 4 | 112155000/0 | Nut |
| 5 | 322110643/0 | Hub Cap Grey |
| 6 | 381007479/2 | Wheel Ø 280 |
| 7 | 112728706/0 | Screw |
| 8 | 322120115/0 | Wheels Crown |
| 9 | 322600145/0 | Protection, Wheel |
| 10 | 322600240/0 | Protection, Wheel |
| 11 | 322110644/0 | Hub Cap Grey |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Ejection-Guard pag.7 | ||
| 1 | 322108309/1 | Side Ejection Conveyor |
| 2 | 381008161/1 | Stone Guard Side Discharge Assy |
| 3 | 112727803/0 | Screw |
| 4 | 322806659/0 | Fulcrum Pin |
| 5 | 112154510/0 | Nut |
| 6 | 118203853/0 | Cap |
| 7 | 122450456/1 | Spring |
| 8 | 122517869/1 | Pin |
| 9 | 112604896/0 | Crown Fastener |
| 10 | 122517876/0 | Pin |
| 11 | 322783013/0 | Safety Button |
| 12 | 122450493/0 | Spring |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Blade pag.8 | ||
| 1 | 112735108/1 | Screw |
| 2 | 1111-9120-01 | Blade Holder (Ø 22.2) |
| 2 | 122465607/4 | Hub With Pulley, Crankshaft Ø 22.2 |
| 3 | 1111-9293-01 | Mulching Blade (STIGA Pack) |
| 3 | 181004459/0 | Blade |
| 4 | 122160400/0 | Elastic Disc |
| 5 | 112523080/0 | Washer |
| 6 | 112735698/0 | Screw |
| 7 | 112139100/0 | Key |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Grass-Catcher pag.9 | ||
| 1 | 322486497/0 | Rear door |
| 2 | 322486496/0 | Grass-Box, Upper Part |
| 3 | 181102422/0 | Black Fabric Box |
| 5 | 122450479/0 | Spring |
| 6 | 122608525/1 | Lower Stiffening |
| 6 | 122608525/2 | Lower Stiffening |
| 7 | 122517884/0 | Pin |
| 8 | 322109594/0 | Stone Guard Support, Black |
| 9 | 112728697/0 | Screw |
| 10 | 322600355/1 | Stone Guard, Black |
| 12 | 381008735/0 | Outfit, Plastic Pin |
| 13 | 381008639/0 | Outfit, Screws |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Engine - Carburettor, Tank pag.10 | ||
| 2 | 112292102/0 | Nut |
| 3 | 118551468/0 | Starter Assy |
| 4 | 118551619/0 | Starter Handle |
| 5 | 118550779/0 | Starting Rope |
| 6 | 118551621/0 | Starter Spring |
| 7 | 118551620/0 | Starter Pulley |
| 8 | 118551626/0 | Spring |
| 9 | 118551622/0 | Ratchet, Starter |
| 10 | 118551625/0 | Spring |
| 11 | 118551623/0 | Cover |
| 13 | 118551624/0 | Stud |
| 14 | 118551788/0 | Blower Housing |
| 15 | 118550907/0 | Pin |
| 16 | 118550906/0 | Pin |
| 17 | 112791500/0 | Screw |
| 18 | 118551474/0 | Elettronic Coil |
| 20 | 1111-9206-01 | Spark Plug (Rc12Yc) |
| 21 | 112789000/0 | Screw |
| 22 | 118551456/0 | Choke Control |
| 23 | 118551459/0 | Control Rod |
| 24 | 118551352/0 | Retainer |
| 25 | 118551450/1 | Carburettor |
| 26 | 118550930/0 | Stud Bolt |
| 27 | 118550929/0 | Gasket |
| 28 | 118550928/0 | Insulator, Carburettor |
| 29 | 118550927/0 | Gasket |
| 30 | 118551124/0 | Gasket |
| 31 | 118551462/0 | Air Cleaner Assy |
| 33 | 118550257/0 | Air Filter |
| 34 | 118551463/0 | Air Cleaner Cover |
| 35 | 112292102/0 | Nut |
| 36 | 118551480/0 | Fuel Pipe |
| 37 | 118550918/0 | Pipe Clip |
| 38 | 118550314/0 | Fuel Filter |
| 39 | 118551453/0 | Tank |
| 40 | 118551455/0 | Fuel Cap |
| 41 | 112791400/0 | Screw |
| 42 | 118551479/0 | Breather Fuel Pipe |
| 43 | 118550933/0 | Arm Governor |
| 46 | 118551458/0 | Spring |
| 49 | 118551457/0 | Governor Link |
| 50 | 118550898/0 | Gasket, Muffler |
| 51 | 118551465/0 | Muffler |
| 52 | 118550930/0 | Stud Bolt |
| 53 | 118551466/0 | Muffler Guard |
| 54 | 118550806/0 | Nut |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Engine - Piston, Crankshaft pag.11 | ||
| 1 | 118550336/0 | Nut |
| 2 | 118550905/0 | Flywheel Ass.Y |
| 3 | 118551277/0 | Bolt |
| 4 | 112791500/0 | Screw |
| 5 | 118551486/0 | Flywheel Brake/Stop Switch Assy |
| 6 | 118551522/0 | Spring |
| 7 | 118550300/0 | Oil Seal |
| 13 | 118551484/0 | Crankshaft |
| 14 | 118550288/0 | Woodruff Key |
| 16 | 118551448/0 | Camshaft Assy |
| 18 | 112789000/0 | Screw |
| 19 | 118551460/0 | Speed Governor Assy |
| 22 | 118550935/0 | Oil Seal |
| 23 | 118550856/0 | Cotter Pin |
| 24 | 118550379/0 | Oil Seal |
| 25 | 118552520/0 | Crankase |
| 27 | 112791500/0 | Screw |
| 28 | 118551276/0 | Bolt |
| 29 | 118550891/0 | Cover Comp., Head |
| 30 | 118550892/0 | Packing Head Cover |
| 31 | 118550893/0 | Valve Arm Set |
| 32 | 118550894/0 | Plate |
| 33 | 118550895/0 | Retainer |
| 34 | 118550896/0 | Spring |
| 35 | 118550910/0 | Valve Assy, Intake + Exhaust |
| 36 | 118551449/0 | Valve Lifter |
| 37 | 118551251/0 | Push Rod |
| 38 | 118551485/0 | Piston ass.y |
| 39 | 118551445/0 | Piston, Ring Set |
| 40 | 118550915/0 | Piston Pin |
| 41 | 118550914/0 | Washer, Piston Pin |
| 42 | 118551446/0 | Connecting Rod Assy |
| 43 | 112791500/0 | Screw |
| 44 | 118551444/0 | Oil Filler Assy |
| Lawnmower AL5 51 SAQ - 2L0536844/A21 Engine, Engine Cover pag.12 | ||
| 1 | 118551442/0 | Engine Assembled |
| 11 | 322055631/0 | Grey Cover |
| 12 | 322055632/0 | Hood, Yellow |
| 13 | 322055628/0 | Grey Cover |
| 201 | 1111-9234-01 | Engine oil, SAE 30 - 0,6 L |
| 201 | 1111-9237-01 | Engine oil, 10W-30 - 0,6 L |
| 201 | 1111-9244-01 | Only for Italian Market |
| 201 | 1111-9244-01 | Only for Italian Market |
| 202 | 1111-9235-01 | Engine oil, SAE 30 - 1 L |
| 203 | 1111-9236-01 | Engine oil, SAE 30 - 1,4 L |
| 203 | 1111-9238-01 | Engine oil, 10W-30 - 1,4 L |
| 203 | 1111-9245-01 | Only for Italian Market |
| 203 | 1111-9245-01 | Only for Italian Market |
AL5 51 SAQ - 2L0536844/A21
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
