Hitachi Spare Parts for Engine Chainsaw CS30EH(S) / CE35EH(S)
€5.24
Tax included
Hitachi Spare Parts for Engine Chainsaw CS30EH(S) / CE35EH(S)
Hitachi-HIKOKI Tanaka original spare parts for to replace broken parts for to fix 65mm Pruning Chainsaw CS30EH(S) / CE35EH(S).Fix Your Pruning Chainsaw. All Spares can be supplied at low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Chainsaw CS30EH(S) / CE35EH(S)
Hitachi-HIKOKI Tanaka original spare parts for to replace broken parts for to fix 65mm Pruning Chainsaw CS30EH(S) / CE35EH(S).
In the following table, look for the model of the Chainsaw and ripettivo spare part.
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.1 | ||
| # | Part Num. | Description |
| 1 | 6687479 | SPARK PLUG CAP |
| 6 | 6685460 | CYLINDER W/GASKET |
| 7 | 6684586 | SCREW M5X18 / S |
| 9 | 6685725 | CYLINDER GASKET |
| 10 | 6686122 | PISTON RING |
| 11 | 6685880 | PISTON W / RINGS (2) + CIRCLIPS (2) |
| 12 | 6686008 | PISTON PIN |
| 13 | 6685078 | CIRCLIP |
| 16 | 6686172 | CRANKSHAFT W / BEARING |
| 17 | 6695592 | ROLLER BEARING F-910 |
| 18 | 6684899 | KEY WOODRUFF 3X13X4.5 |
| 31 | 6695407 | SCREW 4X18WS |
| 32 | 6685089 | IGNITION COIL |
| 33 | 6687890 | HIGHTENSION SION CORD 110L (OLD 178 |
| 34 | 6684602 | RUBBER SLEEVE |
| 35 | 6687667 | COMPLETE IGNITION COIL |
| 66 | 6692900 | PROTECTION TUBE |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.2 | ||
| 19 | 6685099 | THICKNESS S T 0.3 |
| 19 | 6685098 | THICKNESS S T 0.2 |
| 21 | 6685104 | FLYWHEEL NUT |
| 22 | 6695222 | WASHER |
| 23 | 6685103 | WASHER M7 |
| 24 | 6685102 | FLYWHEEL W / RATCHETS |
| 26 | 6685334 | PAWL |
| 27 | 6685105 | RATCHER SPRING |
| 28 | 6685101 | LOCKING RING D4E |
| 36 | 6684668 | SCREW M5X20 / S |
| 41 | 6686524 | COMPLETE CRANKSHAFT CASE |
| 42 | 6684607 | OIL SEAL TB 12227 |
| 43 | 6686702 | GASKET |
| 44 | 6685096 | BALL BEARING 6201 A2C3 |
| 46 | 6685095 | NEEDLE ROLLER 2.5X9.8 |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.3 | ||
| 47 | 6687421 | FILTER SUPPORT |
| 48 | 6689876 | SEAL |
| 49 | 6685202 | INTAKE MANIFOLD FLANGE |
| 50 | 6689787 | INTAKE MANIFOLD |
| 51 | 6691367 | MOTOR HOUSING W / BREATHER VALVE |
| 52 | 6685173 | BREATHER VALVE |
| 53 | 6685203 | SPOUT |
| 54 | 6685175 | VALVE |
| 57 | 6684634 | SCREW 5X20 / PS |
| 58 | 6690843 | VALVE |
| 59 | 6692411 | LEVER |
| 60 | 6692596 | THICKNESS 0.8 |
| 61 | 6692591 | RUBBER |
| 62 | 6692514 | AIR CHOKE |
| 64 | 6687959 | PLUG |
| 65 | 6685224 | SPONGE |
| 67 | 6686304 | AIR FILTER COVER |
| 68 | 6689735 | SCREW |
| 69 | 6690074 | AIR CLEANER ELEMENT |
| 70 | 6684595 | SCREW M4X12 / S |
| 71 | 6685153 | SCREW |
| 73 | 6695428 | SCFREW - SEE 994-16050-402 |
| 74 | 6695505 | SCREW 5X18PS |
| 75 | 6685853 | RUBBER |
| 77 | 6684864 | WASHER |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.4 | ||
| 26 | 6695054 | BOLT 5X40 |
| 27 | 6684662 | WASHER |
| 28 | 6692448 | COMPLETE MUFFLER |
| 29 | 6692628 | MUFFLER BODY |
| 30 | 6692679 | INTERNAL MUFFLER BODY |
| 31 | 6692834 | SEAL |
| 32 | 6692608 | MUFFLER BODY |
| 33 | 6692735 | MUFFLER BODY |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.5 | ||
| 1 | 6691121 | OIL TUBE |
| 2 | 6692312 | RING |
| 3 | 6684661 | WASHER M5 |
| 4 | 6690919 | OIL FILTER (SPONGE) |
| 5 | 6685249 | INTAKE OIL COMPLETE |
| 10 | 6685196 | FITTING |
| 11 | 6685139 | PRIMER |
| 12 | 6685267 | TUBE MIX |
| 13 | 6692353 | MIX TUBE |
| 14 | 6697632 | SERIAL MIXED TUBE ED90001 |
| 14 | 6697174 | RUBBER PIPE (OLD 678-56300-20 / 66852 UP TO SERIAL EN90065 |
| 16 | 6688155 | MIX TUBE |
| 17 | 6685199 | iNTAKE FUEL |
| 35 | 6685180 | MIXING CAP |
| 37 | 6685179 | GASKET CAP |
| 60 | 6697756 | OIL TANK CAP |
| 62 | 6697888 | OIL TANK CAP PACKING |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.6 | ||
| 0 | 6692911 | RECOIL STARTER ASSY |
| 1 | 6684679 | SCREW |
| 2 | 6685183 | RECOIL STARTER SPRING WITHOUT-START |
| 3 | 6685184 | RECOIL STARTER PULLEY |
| 4 | 6685186 | ROPE (OLD 783-01761-20) |
| 5 | 6685185 | RECOIL STARTER SPRING WITH / HOUSING |
| 7 | 6685188 | RECOIL STARTER HANDLE |
| 8 | 6687481 | RUBBER |
| 9 | 6686952 | RECOIL STARTER CARTER |
| 10 | 6685191 | SCREW D4.5X20 * 6684636 |
| 11 | 6687183 | RUBBER |
| 12 | 6687327 | CONVEYOR |
| 14 | 6685182 | PLATE |
| 15 | 6685189 | STOP ROPE |
| 16 | 6685153 | SCREW |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.7 | ||
| 0 | 6690650 | CARBURETOR WT553 |
| 2 | 6684700 | FILTER NET |
| 3 | 6691416 | PUMP BODY EX 575-25006-200 |
| 4 | 6685210 | SCREW |
| 5 | 6685212 | PUMP GASKET |
| 6 | 6685213 | PUMP MEMBRANE |
| 9 | 6685217 | ROCKER |
| 10 | 6685218 | SCREW |
| 11 | 6690872 | SPRING |
| 12 | 6685219 | ROCKER PIN |
| 13 | 6685222 | COVER |
| 14 | 6690827 | DISC MEMBRANE |
| 15 | 6685220 | DISC GASKET |
| 16 | 6685215 | NEEDLE |
| 21 | 6685297 | SPRING |
| 22 | 6685298 | MINIMUM ADJUSTING SCREW |
| 25 | 6685223 | DISC GASKET |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.8 | ||
| 8 | 6695416 | SCREW 5X14 |
| 11 | 6686764 | PUMP COVER |
| 12 | 6691223 | OIL PIPE A |
| 13 | 6686645 | WORM SCREW |
| 14 | 6685156 | SPONGE |
| 15 | 6687325 | OIL PUMP ASS'Y |
| 16 | 6690957 | RUBBER |
| 17 | 6691070 | OIL PUMP ADJUSTMENT SCREW |
| 18 | 6697917 | O-RING |
| 19 | 6686681 | OIL PUMP CASE |
| 20 | 6697917 | O-RING * 6697917 |
| 36 | 6685275 | SCREW D5X14 |
| 38 | 6685154 | MIX TUBE |
| 39 | 6685155 | CHAIN LOCK |
| 42 | 6685152 | SCREW D4.5X14 |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.9 | ||
| 2 | 6685166 | BLADE FIXING NUT |
| 4 | 6685142 | COMPLETE CLUTCH |
| 5 | 6685143 | ROLLER BEARING |
| 6 | 6685144 | CLUTCH DRUUM 3/8 |
| 7 | 6685145 | WASHER |
| 21 | 6689491 | CLUTCH ARM |
| 22 | 6689496 | CLUTCH CENTER |
| 23 | 6689424 | CLUTCH SPRING |
| 24 | 6689527 | PLATE |
| 25 | 6695240 | RIVET |
| 31 | 6685161 | SCREW D4X10 |
| 32 | 6697599 | GUIDE PLATE |
| 37 | 6685146 | SPACER |
| 45 | 6685161 | SCREW D4X10 |
| 46 | 6686110 | COMPLETE CHAIN CARTER |
| 47 | 6690756 | GUIDE PLATE |
| 48 | 6695269 | SCREW |
| 49 | 6697958 | *HANDLE GUARD |
| 50 | 6695906 | CHAIN TENSIONER |
| 51 | 6685168 | CHAIN TENSIONER GEAR |
| 52 | 6689712 | CARTER |
| 54 | 6689705 | SPRING |
| 55 | 6685119 | LEVER |
| 56 | 6685141 | PIN 3X9.8 |
| 57 | 6685121 | LEVER |
| 58 | 6689728 | BRAKE BAND |
| 59 | 6690805 | BUSHING |
| 60 | 6685120 | BUSHING |
| 61 | 6686046 | CHAIN CARTER |
| 62 | 6685122 | SPRING |
| 63 | 6685148 | SCREW D4X15 |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.10 | ||
| 6 | 6695107 | SCREW 5X35 |
| 9 | 6690805 | BUSHING |
| 10 | 6688263 | DAMPER |
| 11 | 6695108 | SCREW 5X40 |
| 12 | 6688481 | SPACER |
| 15 | 6685074 | SCREW D5X16 |
| 16 | 6685651 | SEMI HANDLE (RIGHT) |
| 17 | 6692680 | BUTTON |
| 18 | 6686447 | SPRING |
| 20 | 6686430 | PLUG |
| 26 | 6688363 | SAFETY LEVER |
| 27 | 6686395 | THROTTLE TRIGGER |
| 28 | 6686416 | THROTTLE LEVER SPRING |
| 33 | 6685623 | SEMI HANDLE (LEFT) |
| 39 | 6685148 | SCREW D4X15 |
| 41 | 6688085 | SIDE HANDLE |
| 42 | 6685252 | CABLE |
| 43 | 6687838 | CABLE |
| 44 | 6685239 | SWITCH |
| 45 | 6693874 | THROTTLE CABLE |
| 46 | 6688011 | CLAMP |
| 47 | 6691379 | CARTER |
| 48 | 6685153 | SCREW |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.11 | ||
| 601 | 6694396 | NAME PLATE CS30EH (S) (OLD 906-72101 |
| 602 | 6694499 | STARTER MARK CH30EH (S) (OLD 915-721) |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.12 | ||
| 601 | 6694397 | NAME PLATE CS35EH (S) (OLD 906-72102 |
| 602 | 6694500 | STARTER MARK CS35EH (S) (OLD 915-721 |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.13 | ||
| 40 | HGA781122 | CHAIN CONF. 3/8 LP 1.3 45M |
| 40 | HGA781124 | CHAIN CONF. 3/8 LP 1.3 52M |
| 41 | HGA781232 | KIT BARRA-CHAIN 30CM 3/8 1.3 45M |
| 41 | HGA781234 | KIT BARRA-CHAIN 35CM 3/8 1.3 52M |
| CHAINSAW HITACHI CS30EH(S)-CE35EH(S) pag.14 | ||
| 2 | HGA6695736 | FLYWHEEL EXTRACTOR |
| 3 | HGA6695737 | EXTRACTOR FLYWHEEL BOLT |
| 5 | HGA6695740 | PISTON PIN PULLER EXTRACTOR |
| 13 | HGA6695753 | CLUTCH EXTRACTOR |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
