Alpina Lawnmower AL5 41 A Parts
€21.10
Tax included
Alpina Lawnmower AL5 41 A Spare Parts
For the maintenance and repair of your Self-propelled Lawnmower AL5 41 A – 2L0431044/A21 - 2022, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Alpina Lawnmower AL5 41 A Spare Parts
For the maintenance and repair of your Self-propelled Lawnmower AL5 41 A – 2L0431044/A21 - 2022, it is advisable to purchase original spare parts only. Buy Alpina spare parts at best prices with confidence. Open the PDF on the page to see all the components of the lawnmower. Live your garden by taking care of the lawn.
In the following table, look for the model of the Petrol Lawn Mower and the respective parts of the code.
| Lawnmower AL5 41 A – 2L0431044/A21 Deck pag.1 | ||
| # | Part Num. | Description |
| 1 | 381005195/2 | Bracket-Rh |
| 2 | 381005197/2 | Left Bracket |
| 3 | 112727802/0 | Screw |
| 4 | 322545213/0 | Plate |
| 5 | 322600310/0 | Rear door |
| 6 | 322108329/0 | Rear Conveyor |
| 7 | 112728697/0 | Screw |
| 8 | 322060241/1 | Belt Protection |
| 9 | 112728903/0 | Screw |
| 10 | 322140249/0 | Mulching Deflector |
| 11 | 381005026/0 | Grey Deck |
| 12 | 322820077/1 | Cap |
| 13 | 119035000/0 | Or Ring |
| 14 | 112728450/0 | Screw |
| 15 | 322034002/0 | Washing Connection |
| Lawnmower AL5 41 A - 2L0431044/A21 Height Adjusting pag.2 | ||
| 1 | 381302937/0 | Axle, Front Wheels |
| 1 | 381302937/1 | Axle, Front Wheels |
| 2 | 322785305/1 | Support |
| 3 | 112728697/0 | Screw |
| 4 | 322869731/0 | Rod, Height Adjustment |
| 4 | 322869731/1 | Rod, Height Adjustment |
| 5 | 122519823/0 | Pin |
| 6 | 112436050/0 | Plate |
| 7 | 122450494/0 | Spring |
| 8 | 381302855/1 | Rear Wheel Axle |
| 8 | 381302855/2 | Rear Wheel Axle |
| 9 | 381003356/0 | Wheels Rear Adj. Lever |
| 9 | 381003356/1 | Wheels Rear Adj. Lever |
| 10 | 122534131/0 | Pin |
| 11 | 122446192/0 | Spring |
| 12 | 112154510/0 | Nut |
| 13 | 322785500/0 | Support |
| Lawnmower AL5 41 A - 2L0431044/A21 Mask pag.3 | ||
| 1 | 112735410/0 | Screw |
| 2 | 322226312/0 | Mask, Black |
| 3 | 322393780/0 | Front Handle |
| Lawnmower AL5 41 A - 2L0431044/A21 Handle, Lower Part pag.4 | ||
| 1 | 381006737/0 | Handle, Lower Part Black |
| 2 | 112155000/0 | Nut |
| 3 | 112521350/0 | Washer |
| 4 | 112369500/0 | Elastic Washer |
| 5 | 112760605/0 | Screw |
| 6 | 381008691/0 | Outfit, Screws |
| 7 | 133320504/0 | Fairlead |
| 8 | 118390020/0 | Conduit Clip |
| Lawnmower AL5 41 A - 2L0431044/A21 Handle, Upper Part pag.5 | ||
| 1 | 381007571/2 | Handle,Black Upper Part with sponge handgrip |
| 2 | 122430313/0 | Guide Spring |
| 3 | 112521330/0 | Washer |
| 4 | 112154510/0 | Nut |
| 5 | 118390020/0 | Conduit Clip |
| 6 | 181003363/1 | Lever, Engine Brake Black |
| 7 | 181030054/0 | Cable, Thread Engine Brake |
| 8 | 112727783/0 | Screw |
| 9 | 112154510/0 | Nut |
| 12 | 322551640/0 | Cable Holder |
| 12 | 322551685/0 | Cable Holder ø22 |
| Lawnmower AL5 41 A - 2L0431044/A21 Wheel and Hub Cap pag.6 | ||
| 1 | 381007416/3 | Wheel Ø 200 |
| 2 | 119216035/0 | Bearing |
| 3 | 112521350/0 | Washer |
| 4 | 112155000/0 | Nut |
| 5 | 322110643/0 | Hub Cap Grey |
| 6 | 381007484/2 | Wheel Ø 200 |
| 7 | 112728706/0 | Screw |
| 8 | 322120114/0 | Wheels Crown |
| 9 | 322600145/0 | Protection, Wheel |
| 10 | 322600239/0 | Protection, Wheel |
| Lawnmower AL5 41 A - 2L0431044/A21 Blade pag.7 | ||
| 1 | 112735108/1 | Screw |
| 2 | 1111-9168-01 | Blade Holder |
| 2 | 122463012/4 | Hub, Crankshaft Ø 22.2 |
| 3 | 1111-9142-02 | Mulching Blade |
| 3 | 181004341/3 | Mulching Blade |
| 4 | 122160400/0 | Elastic Disc |
| 5 | 112523080/0 | Washer |
| 6 | 112735698/0 | Screw |
| 7 | 112139100/0 | Key |
| Lawnmower AL5 41 A - 2L0431044/A21 Grass-Catcher pag.8 | ||
| 1 | 322486497/0 | Rear door |
| 2 | 322486496/0 | Grass-Box, Upper Part |
| 3 | 181102422/0 | Black Fabric Box |
| 5 | 122450479/0 | Spring |
| 6 | 122608525/1 | Lower Stiffening |
| 6 | 122608525/2 | Lower Stiffening |
| 7 | 122517884/0 | Pin |
| 8 | 322109594/0 | Stone Guard Support, Black |
| 9 | 112728697/0 | Screw |
| 10 | 322600355/1 | Stone Guard, Black |
| 12 | 381008735/0 | Outfit, Plastic Pin |
| 13 | 381008639/0 | Outfit, Screws |
| Lawnmower AL5 41 A - 2L0431044/A21 Engine - Carburettor, Tank pag.9 | ||
| 2 | 112292102/0 | Nut |
| 3 | 118551467/0 | Starter Assy |
| 4 | 118551619/0 | Starter Handle |
| 5 | 118550779/0 | Starting Rope |
| 6 | 118551621/0 | Starter Spring |
| 7 | 118551620/0 | Starter Pulley |
| 8 | 118551626/0 | Spring |
| 9 | 118551622/0 | Ratchet, Starter |
| 10 | 118551625/0 | Spring |
| 11 | 118551623/0 | Cover |
| 13 | 118551624/0 | Stud |
| 14 | 118550908/0 | Air Guide |
| 15 | 118550907/0 | Pin |
| 16 | 118550906/0 | Pin |
| 17 | 112791500/0 | Screw |
| 18 | 118551475/0 | Elettronic Coil |
| 20 | 9400-0244-00 | Spark Plug |
| 21 | 112789000/0 | Screw |
| 22 | 118551456/0 | Choke Control |
| 23 | 118551459/0 | Control Rod |
| 24 | 118551352/0 | Retainer |
| 25 | 118551489/0 | Carburettor |
| 26 | 118550930/0 | Stud Bolt |
| 27 | 118550929/0 | Gasket |
| 28 | 118550928/0 | Insulator, Carburettor |
| 29 | 118550927/0 | Gasket |
| 30 | 118550924/0 | Gasket |
| 31 | 118551461/0 | Air Cleaner Assy |
| 32 | 118550946/0 | Air Filter |
| 33 | 118550945/0 | Air Filter |
| 34 | 118550944/0 | Air Cleaner Cover |
| 35 | 112292102/0 | Nut |
| 36 | 118551481/0 | Fuel Pipe |
| 37 | 118550918/0 | Pipe Clip |
| 38 | 118550314/0 | Fuel Filter |
| 39 | 118551454/0 | Tank |
| 40 | 118550943/0 | Fuel Cap |
| 41 | 112792099/0 | Screw |
| 42 | 118550920/0 | Breather Fuel Pipe |
| 43 | 118550933/0 | Arm Governor |
| 44 | 118550931/0 | Plate |
| 45 | 112789000/0 | Screw |
| 46 | 118550932/0 | Spring |
| 47 | 118550805/0 | Screw |
| 48 | 118550806/0 | Nut |
| 49 | 118550925/0 | Governor Link |
| 50 | 118550898/0 | Gasket, Muffler |
| 51 | 118551464/0 | Muffler |
| 52 | 112792425/0 | Screw |
| 53 | 118550900/0 | Muffler Guard |
| 54 | 118551277/0 | Bolt |
| Lawnmower AL5 41 A - 2L0431044/A21 Engine - Piston, Crankshaft pag.10 | ||
| 1 | 118550336/0 | Nut |
| 2 | 118550905/0 | Flywheel Ass.Y |
| 3 | 118551277/0 | Bolt |
| 4 | 112791500/0 | Screw |
| 5 | 118551483/0 | Flywheel Brake/Stop Switch Assy |
| 6 | 118550911/0 | Spring |
| 7 | 118550300/0 | Oil Seal |
| 9 | 112789000/0 | Screw |
| 10 | 118550904/0 | Cover |
| 11 | 118550903/0 | Gasket, Breath Groove |
| 12 | 118550902/0 | Valve |
| 13 | 118551488/0 | Crankshaft |
| 14 | 118550288/0 | Woodruff Key |
| 15 | 118550283/0 | Washer |
| 16 | 118550890/0 | Camshaft Assy |
| 18 | 112789000/0 | Screw |
| 19 | 118550888/0 | Speed Governor Assy |
| 20 | 118550936/0 | Shaft, Governor Arm |
| 21 | 118550666/0 | Washer |
| 22 | 118550935/0 | Oil Seal |
| 23 | 118550856/0 | Cotter Pin |
| 24 | 118550379/0 | Oil Seal |
| 25 | 118551209/0 | Crankcase Cover |
| 26 | 118550887/0 | Tank Cap |
| 27 | 112791500/0 | Screw |
| 28 | 118551276/0 | Bolt |
| 29 | 118550891/0 | Cover Comp., Head |
| 30 | 118550892/0 | Packing Head Cover |
| 31 | 118550893/0 | Valve Arm Set |
| 32 | 118550894/0 | Plate |
| 33 | 118550895/0 | Retainer |
| 34 | 118550896/0 | Spring |
| 35 | 118550910/0 | Valve Assy, Intake + Exhaust |
| 36 | 118550291/0 | Valve Lifter Assy |
| 37 | 118550912/0 | Push Rod |
| 38 | 118551482/0 | Piston |
| 39 | 118551445/0 | Piston, Ring Set |
| 40 | 118550915/0 | Piston Pin |
| 41 | 118550914/0 | Washer, Piston Pin |
| 42 | 118551487/0 | Connecting Rod Assy |
| 43 | 118551223/0 | Grub Screw |
| 45 | 118550940/0 | Engine Gasket Set |
| Lawnmower AL5 41 A - 2L0431044/A21 Engine Cover pag.11 | ||
| 1 | 322055629/0 | Grey Cover |
| 2 | 322055630/0 | Hood, Yellow |
| 3 | 322055627/0 | Grey Cover |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Alpina websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Alpina brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AL5 41 A - 2L0431044/A21
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10/15 BUSINESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK S/N ALPINA:
- STIGA GROUP S/N START WITH (1 or 2) and have 9 DIGITS
