In the following table, look for the model of the Chain Saw and the respective parts of the code.
| Chain Saw P 500/225020000/04 (2003-2007) Pag.1 | ||
| Engine | ||
| # | Part Num. | Description |
| 1 | 2135030 | SCREW |
| 2 | 4121931 | MUFFLER |
| 3 | 3615180 | MUFFLER GASKET |
| 4 | 2432040 | NUT AUTOLOCK |
| 5 | 2135060 | SCREW |
| 6 | 3L8540970/2 | CIL.-PISTON ASSY Ø 45 |
| 7 | 8540960 | PISTON ASSY Ø 45 (INCL. 8÷10) |
| 8 | 3123110 | PISTON RING Ø 45 |
| 9 | 3158080 | PISTON PIN Ø 45 |
| 10 | 3356020 | CIRCLIP |
| 11 | 3116020 | NEEDLE BEARING |
| 12 | 8251360 | CRANKSHAFT (INCL. 11) |
| 13 | 3151010 | FLYWHEEL KEY |
| 15 | 3724190 | CYLINDER GASKET |
| 16 | 4562417 | HAND-GUARD |
| 17 | 4250720 | CHAIN LINK |
| 18 | 3630660 | PIN |
| 19 | 3657450 | CLAMP |
| 20 | 3657050 | SPARK PLUG SPRING |
| 21 | 3745130 | GROMMET |
| 22 | 3748880 | SPARK PLUG COVER |
| 23 | 3721420 | RUBBER WASHER |
| 24 | 3210024 | PLUG |
| 25 | 3211080 | SPARK PLUG CABLE |
| 26 | 3210690 | ELECTRONIC IGNITION COIL (INCL.25) |
| 27 | 4541220 | FLYWHEEL |
| 31 | 2312080 | WASHER |
| 32 | 2432050 | NUT AUTOBLOCK |
| 33 | 3749837 | CAP |
| 34 | 2123030 | SCREW |
| 35 | 3642680 | BUSHING |
| 36 | 3744250 | SHOCK ABSORBER |
| 37 | 2135130 | SCREW |
| 38 | 2132510 | SCREW |
| 39 | 2321050 | WASHER |
| 40 | 8520940 | CRANKCASE ASSY |
| 41 | 2112460 | BAR SCREW |
| 43 | 3121120 | SEAL RING |
| 44 | 3121070 | SEAL RING |
| 45 | 3112030 | BALL BEARING |
| 46 | 3613760 | BRAKE BAND |
| 47 | 8251590 | OIL PUMP ASSY |
| 48 | 3744730 | GASKET |
| 49 | 3613770 | CLUTCH DISC |
| 50 | 3180310 | WORM SCREW |
| 51 | 4251750 | CLUTCH ASSY |
| 52 | 4121960 | SPROCKET |
| 53 | 3114080 | NEEDLE BEARING |
| 54 | 3612620 | SPROCKET WASHER - DISCONTINUED |
| 55 | 3351110 | CIRCLIP |
| 56 | 4121970 | CHAIN BRAKE LEVER |
| 57 | 3654580 | SPRING |
| 58 | 3630670 | PIN |
| 59 | 4251710 | CHAIN TENSIONER |
| 60 | 3613880 | PLATE |
| 61 | 2132500 | SCREW |
| 62 | 3744710 | INTAKE MANIFOLD |
| 63 | 4251730 | FLANGE ASSY |
| 64 | 2312090 | WASHER |
| 65 | 4520960 | SUPPORT CARBURETTOR |
| 66 | 2135040 | SCREW |
| 67 | 3613900 | BUSHING |
| 68 | 3657140 | CLAMP |
| 69 | 3782850 | CARB. PULSE PIPE |
| 70 | 2123090 | SCREW |
| 71 | 3749840 | AIR FILTER SUPPORT |
| 72 | 3749850 | AIR FILTER HOLDER |
| 73 | 3745650 | GROMMET |
| 74 | 3743407 | CHOKE LEVER |
| 75 | 2135110 | SCREW |
| 76 | 4253650 | CARBURETTOR ASSY |
| 108 | 8724090 | DIAPH.-GASKET SET |
| 109 | 8724230 | GASKET SET (INCL. 3,14,15) |
| 116 | 2125010 | SCREW |
| 117 | 2312120 | WASHER |
| 118 | 3749400 | CHAIN GUARD |
| 119 | 2135050 | SCREW |
| 119 | 2135060 | SCREW |
| 120 | 2432040 | NUT |
| 121 | 2135010 | SCREW |
| 122 | 3L3614510/1 | HINGE |
| 123 | 2360060 | WASHER |
| 124 | 3L4252080/2 | DECOMPRESSOR |
| Housing Pag.2 | ||
| 1 | 4562397 | HANDLE |
| 2 | 2312090 | WASHER |
| 3 | 2123030 | SCREW |
| 4 | 3744250 | SHOCK ABSORBER |
| 5 | 3642680 | BUSHING |
| 6 | 2135030 | SCREW |
| 7 | 3749837 | CAP |
| 9 | 2135040 | SCREW |
| 10 | 4252177 | STARTER ASSY YELLOW |
| 11 | 2382250 | BUSHING |
| 12 | 3749437 | STARTER HANDLE |
| 13 | 4611480 | STARTER SPRING |
| 14 | 3623510 | BUSHING |
| 15 | 3723640 | DISC |
| 16 | 4563040 | STARTER PULLEY |
| 17 | 3784010 | STARTER CORD |
| 18 | 3613420 | WASHER |
| 19 | 2123030 | SCREW |
| 20 | 8211060 | GROUND TERMINAL ASSY |
| 21 | 3210970 | STOP SWITCH |
| 22 | 383300004/0 | HANDLE ASSY GREY - DISCONTINUED |
| 23 | 4250950 | FUEL CAP ASSY (INCL. 24) |
| 24 | 3721300 | OR RING |
| 25 | 4250960 | OIL CAP ASSY (INCL. 26) |
| 26 | 3721330 | OR RING |
| 28 | 4253580 | FUEL TUBE ASSY |
| 32 | 4253690 | OIL TUBE ASSY |
| 33 | 8782880 | OIL FILTER ASSY |
| 34 | 8782870 | INTAKE FILTER ASSY - DISCONTINUED |
| 35 | 3655290 | THROTTLE ROD |
| 36 | 3654180 | SPRING |
| 37 | 3314140 | SPRING BAND PIN |
| 38 | 3743387 | THROTTLE LEVER |
| 39 | 3743397 | SAFETY LEVER |
| 40 | 3320170 | CLAMP |
| 41 | 2412030 | NUT |
| 42 | 3781470 | AIR FILTER |
| 43 | 2653190 | SCREW |
| 44 | 8562300 | FILTER COVER YELLOW - DISCONTINUED |
| 45 | 2123060 | SCREW |
| 46 | 3613890 | PLATE |
| 47 | 4251620 | CLUTCH HOUSING YELLOW |
| 48 | 2670120 | NUT |
| 49 | 4112640 | GUIDE BAR 20” 325" .058" |
| 50 | 4113463 | CHAN 20" |
| 51 | 3750080 | STARTER HOOK |
| 52 | 3750090 | GUIDE |
| 53 | 3654390 | SPRING |
| 54 | 3642980 | BUSHING |
| 55 | 4181307 | CHAIN COVER |
