AEG PN3500X Rotary Hammer Parts
€14.22
Tax included
AEG PN3500X Rotary Hammer Spare Parts
Fix Your Combi Rotary Hammer PN3500X. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
AEG PN3500X Rotary Hammer Spare Parts
Fix Your Combi Rotary Hammer PN3500X. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill Driver and their spare part.
| PN3500X COMBI HAMMER IN2 4935412210 - PN3500X - 4000432329 |
||
| # | Part Num. | Description |
| 3 | 4931432929 | RATING PLATE |
| 4 | 4931250832 | CONNECTION CABLE |
| 5 | 4931392174 | PROTECTING COVER |
| 6 | 4931389915 | NAME PLATE |
| 7 | 4931623456 | GROOVED DOWEL PIN |
| 8 | 4931623094 | WASHER |
| 9 | 4931621834 | WASHER |
| 10 | 4931412166 | GEAR COVER |
| 102 | 4931412165 | COVER |
| 105 | 4931442733 | ELECTRIC FIELD |
| 116 | 4931353230 | AIR DEFLECTOR RING |
| 117 | 4931405705 | HOLDING-DOWN DEVICE |
| 120 | 4931382268 | BRUSH HOLDER |
| 122 | 4931624518 | SCREW |
| 123 | 4931342808 | CENTERING LEDGE |
| 125 | 4931256500 | CABLE COLLAR |
| 126 | 4931624516 | SCREW |
| 127 | 4931624515 | SCREW N874101-1 SHR H-K4X18 T15 |
| 128 | 4931623541 | WIRE |
| 129 | 4931622153 | SCREW |
| 130 | 4931356869 | BEARING COVER |
| 135 | 4931384896 | SWITCH BOARD |
| 140 | 4931624270 | CAPACITOR |
| 141 | 4931624269 | WIRE |
| 200 | 4931412176 | GEAR BOX |
| 204 | 4931331685 | LOCKING RING |
| 206 | 4931412124 | GEAR BOX |
| 208 | 4931623637 | WASHER |
| 209 | 4931941082 | O-RING N874701 5X1 |
| 210 | 4931360041 | THRUST BEARING |
| 214 | 4931621983 | DISC |
| 215 | 4931379589 | PRESSURE SPRING |
| 216 | 4931379649 | COUPLING SLEEVE |
| 219 | 4931426234 | REDUCTION GEAR |
| 220 | 4931384917 | PLANET GEAR |
| 221 | 4931331769 | INTERN.GEARED WHEEL |
| 222 | 4931455430 | PERCUSSION BODY |
| 223 | 4931379587 | CYLINDER |
| 224 | 4931331623 | CYLINDRICAL BOLT |
| 225 | 4931400589 | WASHER |
| 226 | 4931331752 | SLIDER |
| 228 | 4931623081 | PIN |
| 229 | 4931331787 | LATCH PLATE |
| 232 | 4931417464 | SPINDLE SLEEVE |
| 233 | 4931379071 | CUP SPRING |
| 234 | 4931379110 | CLUTCH DISC |
| 235 | 4931392752 | SPINDLE GEAR |
| 236 | 4931384919 | SPRING RING |
| 237 | 4931623199 | WASHER |
| 238 | 4931331713 | THRUST BEARING |
| 239 | 4931343187 | LOCKING WASHER |
| 243 | 4931387328 | THRUST COLLAR |
| 248 | 4931343049 | WASHER |
| 251 | 4931219424 | NEEDLE BEARING |
| 252 | 4931382921 | SLEEVE |
| 253 | 4931409774 | RING STOP |
| 254 | 4931805437 | BALL |
| 255 | 692737001 | PRESSURE SPRING |
| 256 | 4931945764 | SPRING RING |
| 257 | 4931379739 | ADAPTER |
| 259 | 4931623200 | WASHER |
| 260 | 4931623234 | WASHER |
| 261 | 4931392506 | SWITCH HANDLE |
| 262 | 4931379108 | LATCH PLATE |
| 265 | 4931624045 | CYLINDER PULLEY |
| 266 | 4931805390 | BALL |
| 268 | 4931624096 | DISC N874237 |
| 269 | 4931379420 | SPACER |
| 270 | 4931409756 | SUPPORTING PLATE |
| 271 | 4931624098 | DISC N874237 |
| 272 | 4931624097 | DISC N874237 |
| 273 | 4931624096 | DISC N874237 |
| 275 | 4931623602 | SCREW |
| 276 | 4931379708 | SCREW |
| 401 | 4931412170 | MOTOR CAP |
| 405 | 4931384337 | MOTOR HOUSING |
| 406 | 4931449968 | ARMATURE |
| 407 | 4931342793 | FAN |
| 408 | 4931341740 | GROOVED BALL BEAR. |
| 409 | 4931624101 | BALL BEARING |
| 410 | 4931353260 | INSULATING DISC |
| 411 | 4931384561 | REPAIR KIT |
| 412 | 4931384864 | REDUCT. GEAR SHAFT |
| 413 | 4931442301 | SEAL RING |
| 414 | 4931353238 | SPACER |
| 415 | 4931384557 | BUSHING |
| 416 | 4931624264 | DISC N874237 A 10,1X18X1 |
| 418 | 4931384560 | REPAIR KIT |
| 420 | 4931432300 | PINION SHAFT |
| 426 | 4931616614 | LOCKING RING |
| 427 | 4931622564 | DISC N874237 A16,1X26X1 |
| 430 | 4931379881 | REPAIR KIT |
| 444 | 4931407945 | SPINDLE SLEEVE |
| 467 | 4931400216 | REPAIR KIT |
| 605 | 4931384434 | DEPTH GAUGE |
| 606 | 4931409790 | CHUCK ADAPTER |
| 700 | 4931415330 | CARRYING CASE |
| 702 | 4932265320 | DUST CATCHER Dust coll ring P1AM |
| 705 | 4931412160 | HANDLE |
| 1100 | 4931412169 | HANDLE COMPL. |
| 1200 | 4931384723 | MAINTENANCE SET |
| 1201 | 4931369477 | CARBON BRUSH SET |
| 1204 | 4931623124 | O-RING |
| 1205 | 4931360781 | RUBBER SLEEVE |
| 1207 | 4931331735 | GASKET |
| 1209 | 4931379705 | SEAL RING |
| 1210 | 4931624492 | SEAL RING |
| 1211 | 562597001 | O-RING |
| 1212 | 4931623135 | O-RING |
| 1213 | 4931623232 | SEAL RING |
| 1214 | 4931412209 | SLEEVE |
| 1215 | 4931392502 | DAMPING ELEMENT |
| 1216 | 4931331549 | HOLDING-DOWN DEVICE |
| 1218 | 4931623636 | RING |
| 1219 | 4931945764 | SPRING RING |
| 1220 | 4931623521 | SCREW |
| 1221 | 4931623520 | SCREW |
| 1222 | 4931623519 | SCREW |
| 1223 | 4931379109 | SCREW |
| 1224 | 4931623293 | O-RING |
| 1225 | 4931379585 | FELT WASHER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s AEG websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to AEG brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
AEG PN3500X
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 7/10 BUSINESS DAYS APPROX
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK AEG S/N:
- AEG S/N START WITH (4) or (5) AND HAVE 10 DIGITS
