ABAC Air Compressors Line Filter Cartridges
search
  • ABAC Air Compressors Line Filter Cartridges

ABAC Air Compressors Line Filter Cartridges

€60.88
Tax included

ABAC Air Compressors Line Filter Cartridges

The atmospheric air originally contains various impurities, such as dust, various forms of hydrocarbons and water in the form of humidity, which, once sucked by the compressor, are compressed and transmitted to the system together with any oily particles
ITEM CODE: 2258290101
Quantity
on 10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

ABAC Air Compressors Line Filter Cartridges

The atmospheric air originally contains various impurities, such as dust, various forms of hydrocarbons and water in the form of humidity, which, once sucked by the compressor, are compressed and transmitted to the system together with any oily particles.
Use Original parts to keep your compressor performance reliable. Compliance with maintenance intervals and the use of original ABAC spare parts increase the life of your compressed air equipment by reducing the risk of malfunctions and technical efficiency.

In addition to quality spare parts and Accessories, this includes professional service by professionals

In the following table, look for the spare parts of the ABAC Air Compressor and the corresponding code.
Line Filter Cartridges
Line Filter Cartridges
Filter Type Nominal capacity * P G/S C/D V
l/min m3/h kit code kit code kit code kit code
FILTRO 45 720 43 2258290101 2258293101 2258293201 2258290134
FILTRO 90 1500 90 2258290102 2258293102 2258293202 2258290135
FILTRO 125 2100 126 2258290103 2258293103 2258293203 2258290136
FILTRO 180 3000 180 2258290104 2258293104 2258293204 2258290137
FILTRO 180 3000 180 2258290104 2258293104 2258293204 2258290137
FILTRO 290 4800 288 2258290105 2258293105 2258293205 2258290138
FILTRO 505 8400 504 2258290106 2258293106 2258293206 2258290139
FILTRO 685 11400 684 2258290107 2258293107 2258293207 2258290140
FILTRO 935 15600 936 2258290108 2258293108 2258293208 2258290141
FILTRO 1295 21600 1296 2258290109 2258293109 2258293209 2258290142
FILTRO 1295 21600 1296 2258290109 2258293109 2258293209 2258290142
FILTRO 1890 31500 1890 2258290110 2258293110 2258293210 2258290143
FILTRO 2430 40500 2430 2258290111 2258293111 2258293211 2258290144
* Reference conditions: pressure 7 bar. Maximum operating temperature 66 ° and 35 ° only for the V series The minimum operating temperature is 1° C.

Line Filters Application
S D G C P V
Filter Type Solid Particles Solid Particles Oil Aerosol and Solid Particles Oil Aerosol and Solid Particles Oil Aerosol and Solid Particles Oil Steam
Normativa di riferimento per i test ISO 12500-3 ISO 12500-3 ISO 12500-1 / ISO 8573-2 ISO 12500-1 / ISO 8573-2 ISO 12500-1 / ISO 12500-3 /ISO 8573-2 ISO 8573-5
Concentrazione di olio in entrata (mg/m³) NA NA 10 10 10 0,01
Efficienza di filtrazione particolato (% a MPPS) (MPPS=0,1 μm) 99,81 (MPPS=0,06 μm) 99,97 NA NA (MPPS=0,1 µm) 89,45 NA
Efficienza di filtrazione (% a 1 µm) 99,97 99,999 NA NA 94,19 NA
Efficienza di filtrazione (% a 0,01 µm) 99,87 99,992 NA NA 93,63 NA
Trascinamento d'olio massimo (mg/ m³) NA NA 0,1 0,01 1 0,003
Caduta di pressione a secco (mbar) 120 140 NA NA 85 160
Caduta di pressione in esercizio (mbar)* NA NA 205 240 115 NA
Caduta di pressione in esercizio (mbar), in una tipica installazione di compressori NA NA 185 200 NA NA
Manutenzione elemento After 4,000 operating hours or 1 year or with pressure drop> 350 mbar After 4,000 operating hours or 1 year or with pressure drop> 350 mbar After 4,000 operating hours or 1 year After 4,000 operating hours or 1 year After 4,000 operating hours or 1 year After 1000 hours of WORK

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s ABAC websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to ABAC brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
