Volpi & Bottoli Parts for Self Priming Motor Pump Master A1
€24.01
Tax included
Volpi & Bottoli Parts for Self Priming Motor Pump Master A1
Volpi&Bottoli genuine spare parts or replacement parts for to repair Self-priming centrifugal motor pump for irrigation with 2-stroke engine type MASTER.Engine characteristics
- Motor Model : Master
- Displacement : 50cc
- Power : 2 HP
- Fuel Mixture (1/20)
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Volpi & Bottoli Parts for Self Priming Motor Pump Master A1
Volpi&Bottoli genuine spare parts or replacement parts for to repair Self-priming centrifugal motor pump for irrigation with 2-stroke engine type MASTER.In the following table , look for the type of the Motorpump and theirs spare part.
Items will be shipped within 7/10 working days approx.
| Motorpump Master A1 | ||
| 222202 | Intake Manifold Master | |
| 222008 | Cylinder engine with 50cc shirt | |
| 524930 | Intake Manifold Gasket | |
| 220705 | Base conveyor Master | |
| 222404 | Cover cone. Master with recoil | |
| 222405 | Master new type conveyor cover | |
| 222406 | Cover conv. Master old type (*) | |
| 223101 | Spacer tank Master | |
| 224002 | Nylon rope 0 4x1050 starter motors | |
| 225001 | Guide rope recoil Master | |
| 226304 | Stop button Master | |
| 226705 | Piston 0 40 Master complete | |
| 228908 | Support iron tank Master | |
| 229203 | Head Master engine | |
| 520204 | Antivibration tank Master | |
| 521014 | Electronic ignition coil Master Selettra (5) | |
| 521301 | spark Plug | |
| 523703 | Plastic hook flywheel 0100 | |
| 524903 | Exhaust Gasket Ercolino | |
| 524927 | Seal basement Master | |
| 524928 | Crankcase gasket Master | |
| 524929 | Exhaust Gasket Master | |
| 525201 | Starter handle Master | |
| 526302 | Pin mounting hook flywheel 0100 | |
| 526305 | Reference pin crankcase Master | |
| 526705 | Piston 0 40 naked Master | |
| 527105 | Pulley recoil Master | |
| 527611 | tap mixture | |
| 528003 | Segment 0 40 | |
| 528702 | 10x33 pin 0 | |
| 529710 | Flywheel electronic ignition Selettra 0100 (11) | |
| 4001000111 | Circlip inner hole 11 | |
| 4001005110 | Ring stop pin 0 10 - "" "" "W" I'- '' | |
| 4002000221 | Sealing ring 15x30X7 | |
| 4014000122 | Ball Bearing 15x35x11 | |
| 4014001116 | Roller Bearing 10x14x13 | |
| 4056000153 | Spring stop button Master | |
| 4056000250 | Return spring hook flywheel D100 | |
| 4056000254 | Recoil Spring | |
| 4093005185 | Stud M 5x82 | |
| 4093005265 | Stud M 6x125 | |
| AM2MC1 | Crankshaft Master cylindrical complete | |
| AM2ME1 | Crankshaft Master helical complete | |
| AM2MN1 | Crankshaft Master conical complete | |
| CAMM1 | Crankcase Master | |
| CB2018 | carburetor Master | |
| PRLM1 | Sheet protection Master | |
| SRP2MM10 | Tank mixture Master | |
| SRP2MM11 | Fuel tank full Master | |
| TUP081530 | Fuel Tube Master, Ercolino | |
| Body Pump MASTER A1 | ||
| 52 3803 0000 | Flange 1" gas inlet | 1 |
| 52 3804 0000 | Flangia1 1/4" gas extraction | 1 |
| 40 9300 1354 | Screw T.C.I. M5x70 | 2 |
| 40 9300 1316 | Screw T.C.I. M5x16 | 3 |
| 407100 0206 | Rivet. diam. 6 x 5 | 4 |
| 52 4936 0000 | Suction flange gasket | 5 |
| 52 7504 0000 | Washer iron 6x38 | 6 |
| 40 6100 0174 | OR diam. 15,88x2,62 | 7 |
| 52 9014 0000 | Cap 3/8" plastic gas | 8 |
| 52 9015 0000 | Cap 1/8" BSP brass | 9 |
| 40 9300 1325 | Screw T.C.I. M5x25 | 10 |
| 52 2622 0000 | Body pump 1" gas | 11 |
| 40 6100 0135 | OR FLJ 36,09x3,53 | 12 |
| 52 3221 0000 | diffuser | 13 |
| 52 4937 0000 | seal body | 14 |
| 52 4518 0000 | impeller | 15 |
| 40 0300 2222 | Sealing ring moving part 15x32x 13 | 16 |
| 40 9300 1330 | Screw T.C.I. M5x30 | 17 |
| 40 0300 3323 | Sealing ring fixed part 17x38x8 | 18 |
| 52 4938 0000 | Fiber gasket 5.5 x 9 x 0.8 | 19 |
| 52 8913 0000 | pump support | 20 |
| 40 7200 1105 | Notched washer M5 | 21 |
| 40 2100 0205 | nut M5 | 22 |
| 12 1002 0000 | MASTER 50 cc engine. - 2 cv cylindrical shaft | 23 |
| 40 0300 1121 | Mechanical seal compl age (16 + 18) | |
