Telwin Spare Parts for Inverter Welding TECHNOLOGY TIG 185 DC
€7.84
Tax included
Telwin Spare Parts for Inverter Welding TECHNOLOGY TIG 185 DC
TELWIN Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Telwin inverter TIG, TECHNOLOGY TIG 185 DC - 815956.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Inverter Welding TECHNOLOGY TIG 185 DC
TELWIN Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Telwin inverter TIG, TECHNOLOGY TIG 185 DC - 815956.In the following table, look for the model of the drill and the respective parts of the code.
| TECHNOLOGY TIG 185 DC 230V KIT ALU CASE-815956 Pag.1 | ||
| # | Description | Part Num. |
| 1 | POTENTIOMETER | 112017 |
| 2 | RESISTANCE | 112048 |
| 3 | DIODE | 112948 |
| 4 | CAPACITOR | 113122 |
| 5 | RELAIS | 111925 |
| 6 | PWM CONTROLLER | 111199 |
| 7 | RELAIS | 113493 |
| 8 | CONTROL BOARD KIT | 980250 |
| 9 | RECTIFIER | 116346 |
| 10 | SOCKET CABLE | 120514 |
| 11 | CONTROL CABLE | 120513 |
| 12 | KNOB FOR POTENTIOMETER | 121064 |
| 13 | SWITCH | 121192 |
| 14 | SWITCH | 121193 |
| 15 | ELECTROVALVE | 122035 |
| 16 | SWITCH | 122381 |
| 17 | MAINS CABLE 3G1.5 2 M SCHUKO PLUG | 132155 |
| 18 | FAN | 152006 |
| 19 | FILTER INDUCTANCE | 164741 |
| 20 | AUXILIARY TRANSFORMER | 164932 |
| 21 | HF TRANSFORMER KIT | 980321 |
| 22 | INDUCTANCE | 169506 |
| 24 | FRONT PANEL | 322688 |
| 25 | BACK PANEL | 322690 |
| 26 | HANDLE | 322691 |
| 27 | HF BASE FRONT PANEL | 322731 |
| 28 | HF BASE BACK PANEL | 322732 |
| 29 | SOCKET DX 25 | 712000 |
| 31 | TORCH PUSHBUTTON CARD KIT | 980020 |
| 32 | HF BOARD KIT | 980021 |
| 33 | COVER KIT | 980243 |
| 34 | POWER TRANSFORMER KIT | 980244 |
| 35 | TRANSFORMER KIT FLYBACK | 980245 |
| 36 | HF BASE COVER KIT | 980246 |
| 37 | BOTTOM KIT | 980247 |
| 38 | COMPLETE CONTROL PCB KIT | 980248 |
| 39 | KIT IGBT + DIODE | 980249 |
| 40 | GAS PIPE CONNECTOR KIT | 990120 |
| 41 | HF BASE BOTTOM KIT | 990917 |
| 42 | ST17 TIG TORCH 4 M 180 A | 742423 |
| 43 | PLUG DX 25 | 712039 |
| 44 | CABLE 16 MMQ 3 M - 25 | 123437 |
| 45 | TOLEDO 300 WORK CLAMP | 712231 |
| 46 | ARGON GAS BOTTLE IT ADAPTOR | 432036 |
| 47 | GAS REGULATOR 2 MANOMETERS | 722119 |
| KIT ALU CASE TECHNOLOGY TIG 185 DC Pag.2 | ||
| 1 | KIT 10 CERAMIC NOZZLES NR.6 | 802245 |
| 1 | KIT 10 CERAMIC NOZZLES NR.4 | 802244 |
| 1 | KIT 10 CERAMIC NOZZLES NR.7 | 802246 |
| 2 | INSULATOR | 722248 |
| 4 | KIT 10 CERIUM-TUNGSTEN ELECTR. D.2,4 MM | 802232 |
| 4 | KIT 10 CERIUM-TUNGSTEN ELECTR. D.1 MM | 802220 |
| 4 | KIT 10 CERIUM-TUNGSTEN ELECTR. D.1,6 MM | 802222 |
| 5 | KIT 3 ELECTRODE HOLDER CLAMPS D.2,4 MM | 802241 |
| 5 | KIT 3 ELECTRODE HOLDER CLAMPS D.1,0 MM | 802239 |
| 5 | KIT 3 ELECTRODE HOLDER CLAMPS D.1,6 MM | 802240 |
| 6 | SHORT CAP | 722192 |
| 7 | LONG CAP | 722193 |
| 8 | CONNECTION KIT 25 | 981442 |
| 12 | 3P PLUG | 722999 |
| 14 | PUSHBOTTON CONTACT | 452089 |
| 16 | OR RING | 722061 |
| 17 | PUSHBOTTOM | 742042 |
| 18 | TORCH BODY | 722204 |
| 19 | KIT 3 ELECTRODE DIFFUSERS D.1,6 MM | 802250 |
| 19 | KIT 3 ELECTRODE DIFFUSERS D.1 MM | 802249 |
| 19 | KIT 3 ELECTRODE DIFFUSERS D.2,4 MM | 802251 |
| 21 | 3/8" CONNECTION KIT TIG TORCH | 990263 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Telwin websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Telwin brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
TECHNOLOGY TIG 185 DC - 815956
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM OR S/N CODE TELWIN:
- TELWIN PRODUCT CODE STARTS WITH (8....) AND HAVE 6 DIGITS
