Telwin Spare Parts for Superior Plasma 70 230V/400V + ACC.
€4.36
Tax included
Telwin Spare Parts for Superior Plasma 70 230V/400V + ACC.
Telwin Genuine spare parts or replacement parts for to repair Superior Plasma 70 230V/400V + ACC. - 816170.Inverter, compressed air plasma cutting system, with contact striking of pilot arc.
Allows a rapid, distortion-proof cutting, grid cutting and gauging of all conductive materials such as steel, stainless steel, galvanised steel.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Telwin Spare Parts for Superior Plasma 70 230V/400V + ACC.
Telwin Genuine spare parts or replacement parts for to repair Superior Plasma 70 230V/400V + ACC. - 816170.Open PDF Diagram, check your spare part number position and then select it in the following table.
| Superior Plasma 70 230V/400V + ACC. - 816170 Pag.1 | ||
| # | Part Num. | Description |
| 1 | 111017 | SINGLE PHASE BRIDGE |
| 2 | 111094 | IGBT |
| 3 | 111099 | CONDENSER |
| 4 | 111135 | OPTO-COUPLER |
| 5 | 111327 | RESISTANCE 22R 5W 5% |
| 6 | 111475 | RESISTANCE |
| 7 | 113603 | IGBT |
| 8 | 116320 | RELAIS |
| 9 | 116752 | RESISTANCE |
| 10 | 116760 | VARISTOR |
| 11 | 116882 | CONDENSER |
| 12 | 116888 | IGBT |
| 13 | 116909 | OPTO-COUPLER |
| 14 | 116962 | RESISTANCE 10R 2W 5% FUSE |
| 15 | 120203 | AIR PRESSURE REDUCER |
| 16 | 120248 | CABLE 10 MMQ 5 M - 25 |
| 17 | 121750 | PRESSURE SWITCH |
| 18 | 121556 | SWITCH |
| 20 | 121800 | ELECTROVALVE |
| 21 | 125081 | CABLE FOR REMOTE CONTROL |
| 22 | 132237 | MAINS CABLE 4G1.5 2 M |
| 23 | 152230 | CURRENT TRANSFORMER |
| 24 | 152268 | PULSE TRANSFORMER |
| 25 | 152269 | FAN |
| 26 | 152291 | PULSE TRANSFORMER |
| 27 | 169116 | AUTOTRANSFORMER |
| 28 | 169746 | INDUCTANCE |
| 29 | 169747 | FILTER INDUCTOR |
| 30 | 169838 | TRASFO FLYBACK AUX |
| 31 | 169864 | POWER TRAFO |
| 32 | 169926 | INDUCTANCE |
| 33 | 169930 | INDUCTANCE |
| 34 | 321118 | BACK PANEL |
| 35 | 321119 | HANDLE |
| 36 | 321202 | FRONT PANEL |
| 37 | 323101 | SWITCH KNOB SET |
| 38 | 712035 | SOCKET DX 25 |
| 39 | 712231 | TOLEDO 300 WORK CLAMP 300A |
| 40 | 742642 | TORCH CONNECTION |
| 41 | 980520 | ENCODER KNOB KIT |
| 42 | 981408 | BOTTOM KIT |
| 43 | 981678 | FILTER CARD KIT |
| 44 | 981918 | FRONT PANEL CARD KIT |
| 45 | 981919 | POWER BOARD KIT |
| 46 | 981920 | COVER KIT |
| 47 | 981958 | DIODES KIT |
| 48 | 990046 | KIT CABLE BUSHING + RING NUT |
| Torch Parts Pag.2 | ||
| 1 | 804042 | Electrodes 5 pcs kit |
| 1A | 804043 | LONG ELECTRODES PV SET 5 PZ |
| 2 | 804044 | Kit 2 DIFFUSER |
| 3 | 804045 | Kit 5 NOZZLE 20A -50A |
| 3 | 804047 | Nozzles 70A 5 Pcs Kit |
| 3A | 804048 | LONG NOZZLE 70A PV SET 5 PZ |
| 3 | 804062 | GOUGING NOZZLES Kit 5 45A |
| 4 | 804049 | Torch Safety Cap |
| 5 | 804050 | Kit 2 SCREENS |
| 5 | 804061 | Kit 3 GOUGING SCREENS 45A |
| 5A | 804051 | LONG SCREENS PV 2 PZ |
| 6 | 804052 | Kit 10 O-ring |
| 7 | 742746 | TORCHE BODY |
| 8 | 742747 | HANDLE + KNOB |
| 501 | 742712 | TORCHE |
